Beam IsatDock2 LITE Quick Start Manual

1. IsatDock2 LITE Equipment Overview
1
1. IsatPhone 2 Eject Button
2. IsatPhone 2 (not included)
3. IsatPhone 2 Docking Tray
4. Function Buttons
2
5. Status Indication Light
6. Power Cable Loom
a. Power Supply
b. Satellite Connector (TNC-Female)
c. GPS Connector (SMA-Female)
7. RAM® Mounting
8. RJ9 Privacy Handset Connection
9. Micro USB Data Connection
10. IsatDock2 Adapter
3
4
5
10
2. Specif ication Summary
Average Power Average
Consumption
Current @ 12V
Power w/o 130mA
IsatPhone 2
Standby + Charging 360mA
Transmit + Charging 875mA
Sleep Mode 5mA
Peak Current 3.5A
Physical Specifications Metric
Dimensions 229 x 99 x 76 9.0 x 3.9 x 3.0
(mm)
Weight - dock 565g
Total Kit Weight 1.35kg
Watts Environmental Specifications
Operating Range -30 o C to +70 o
Storage -35 o C to +85 o
1.6W
Battery Charging Temp* 0 C to +45 C
o o
Humidity
4.3W
Connectors / Interfaces
10.5W
BEAM Antenna TNC-Female
60mW
GPS Antenna SMA-Female
42W
10-32V DC 4-way microFit (AC/DC adapter,
or DC lead)
Imperial
Privacy Handset Port RJ9 connector
(inches)
* It is ideal for the ambient temperature to be approximately
1.24lbs
18 degrees below the 45 o C upper limit for the handset to
charge the battery whilst docked.
2.98lbs
6
7
8
9
a
b
c
C -22 o F to +158 o F
C -31 o F to +185 o F
+32 F to +113 F
o o
<=75% RH
www.beamcommunications.com
BEAM Communications
5/8 Anzed Court, Mulgrave
Victoria, 3170, AUSTRALIA
Tel: +61 3 8588 4500 Fax: +61 3 9560 9055
Information: info@beamcommunications.com
Support: support@beamcommunications.com
Suitable for the IsatPhone 2
IsatDock2 LITE
Quick Start Guide
