Interpolation and Extrapolation method can be used to get the total capacity, TC and sensible capacity, SC at
those temperatures which are not stated out in the table.
Example:
Model: AWM 10G / ALC 10C
Indoor Condition: 23°C DB, 15°C WB
Outdoor Condition: 37°C DB
Solution:
Overall
Based on the Performance table of AWM 10G / ALC 10C
1. Refer to the Indoor DB column,
- 23°C is located between 20°C and 24°C (Thus, Interpolation need to be applied)
2. Refer to the Indoor WB column,
- 15°C only available in the case of Indoor DB = 20°C. (Thus, Extrapolation between 16°C WB
and 17°C WB during 24°C indoor DB is required)
3. Refer to the Outdoor DB column,
- 37°C is located between 35°C and 40°C. (Thus, Interpolation need to be applied)
Please follow the steps below in order to get the required capacity.
1 st Step
Extrapolation of Indoor WB
Find TC, SC for
(a) Indoor : 24°C DB,
Outdoor : 35°C DB
(b) Indoor : 24°C DB,
Outdoor : 40°C DB
Downloaded from AC-Manual.com Manuals

6. PERFORMANCE DATA

2 Step
nd
Interpolation of Indoor DB
Find TC, SC for
15°C WB
(a) Indoor :
Outdoor : 35°C DB
15°C WB
(b) Indoor :
Outdoor : 40°C DB
23°C DB, 15°C WB
23°C DB, 15°C WB
75
3 Step
rd
Interpolation of Outdoor DB
Find TC, SC for
(a) Indoor : 23°C DB, 15°C WB
Outdoor : 37°C DB
