Acson AWM 07G' AWM 07GR User Manual page 103

R410A Models
(Cooling only)
MODEL : A5WM 20G / A5LC 20C (3 PHASE)
ID DB°C ID WB°C
TC(kW)
15 5.206
20
5.402
16
16 5.402
17 5.597
24
18 5.809
6.025
19
20 6.229
18 5.809
19 6.025
6.229
20
28 21 6.437
22 6.646
23 6.854
24 7.062
20 6.229
21 6.437
30
22 6.646
23 6.854
24 7.062
MODEL : A5WM 25G/ A5LC 25C (3 PHASE)
ID DB°C ID WB°C
TC(kW)
15 6.762
20
16 6.971
16 6.971
7.180
17
24 18 7.418
19 7.663
20 7.889
7.418
18
19 7.663
20 7.889
28
21 8.121
22 8.354
23 8.587
24 8.819
20 7.889
21 8.121
30 22 8.354
23 8.587
24 8.819
