Models:
AWM 07 F/FR
AWM 10 F/FR
AWM 15 F/FR
AWM 20 F/FR
AWM 25 F/FR
AWM 301/301R
Wall Mounted Split Systems
REGISTERED
AWM-2005
ISO 9002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the awm07f and is the answer not in the manual?

Questions and answers

Related Manuals for Acson awm07f

Summary of Contents for Acson awm07f

  • Page 1 Models: AWM 07 F/FR AWM 10 F/FR AWM 15 F/FR AWM 20 F/FR AWM 25 F/FR AWM 301/301R Wall Mounted Split Systems REGISTERED AWM-2005 ISO 9002...

  • Page 2: Table Of Contents

    CONTENTS 1. FEATURES ........................ 1 2. NOMENCLATURE...................... 2 3. SPECIFICATIONS ..................... 3 4. PERFORMANCE TABLE ..................11 5. OPERATING RANGE ....................33 6. NOISE LEVEL ......................34 7. OUTLINES AND DIMENSION ................. 38 8. REFRIGERATION CYCLE DIAGRAM..............42 9. WIRING DIAGRAMS ....................47 10.

  • Page 3: Features

    1. FEATURES • EASY INSTALLATION - The wall mounted fan coil unit is easily installed because of its compact size, slimness and light weight. - Slim and short outdoor unit can be easily installed even in a narrow balcony and passageway and yet have a stable profile.

  • Page 4: Nomenclature

    2. NOMENCLATURE Model Type R : Heatpump Omitted if Cooling Series F : F Series Capacity 25 : 25,000 Btu/h Model Name WM : Wall Mounted Brand A : Acson...

  • Page 5: Specifications

    3. SPECIFICATIONS R22 MODELS (COOLING ONLY) INDOOR UNIT AWM 10F AWM 15F AWM 20F AWM 25F MODEL ALC 10C ALC 15C ALC 20B ALC 25B OUTDOOR UNIT 2840 3520 5569 7034 NOMINAL COOLING CAPACITY 9700 12000 19000 24000 Btu/h INPUT POWER (W) - 1∅ [3∅] 1132 1730 [2136] 2480 [2715]...
  • Page 6 R22 MODELS (COOLING ONLY) AWM 301 INDOOR UNIT MODEL OUTDOOR UNIT ALC 30B ALC 30C 7913 8792 NOMINAL COOLING CAPACITY Btu/h 27000 30000 INPUT POWER 3010 2,690 RUNNING CURRENT 14.4 12.6 220 - 240 / 1 / 50 POWER SOURCE V / Ph / Hz REFRIGERANT / CONTROL R22 / EXTERNAL ORIFICE KIT...
  • Page 7 R22 MODELS (HEATPUMP) INDOOR UNIT AWM 10FR AWM 15FR AWM 20FR AWM 25FR MODEL OUTDOOR UNIT ALC 10CR ALC15CR ALC 20BR ALC 25BR 2780 3520 5569 7034 NOMINAL COOLING CAPACITY Btu/h 9500 12000 19000 24000 2780 3520 5569 7327 NOMINAL HEATING CAPACITY Btu/h 9500 12000...
  • Page 8 R22 MODELS (HEATPUMP) INDOOR UNIT AWM 301R MODEL OUTDOOR UNIT ALC 30BR ALC 30CR 7620 8790 NOMINAL COOLING CAPACITY Btu/h 26000 30000 8206 8790 NOMINAL HEATING CAPACITY Btu/h 28000 30000 INPUT POWER (COOLING) - 1∅ <3∅> 2992 2944 < 3204 > INPUT POWER (HEATING) - 1∅...
  • Page 9 R407C MODELS (COOLING ONLY) INDOOR UNIT AWM 07F AWM 10F AWM 15F AWM 20F MODEL OUTDOOR UNIT A4LC 07B A4LC 10B A4LC 15B A4LC 20B 2170 2637 3223 5363 NOMINAL COOLING CAPACITY Btu/h 7400 9000 11000 18300 INPUT POWER 1∅ < 3∅ > 1438 2298 <...
  • Page 10 R407C MODELS (COOLING ONLY) INDOOR UNIT AWM 25F AWM 301 MODEL OUTDOOR UNIT A4LC 25B A4LC 30C 6155 8499 NOMINAL COOLING CAPACITY Btu/h 21000 29000 INPUT POWER - 1∅ / < 3∅ > 2850 < 2698 > 2877 / < 2877 > 13.30 <...
  • Page 11 R407C Models (HEATPUMP) INDOOR UNIT AWM 07FR AWM 10FR AWM 15FR AWM 20FR MODEL OUTDOOR UNIT A4LC 07BR A4LC 10BR A4LC 15BR A4LC 20BR 2227 2637 3223 5129 NOMINAL COOLING CAPACITY Btu/h 7600 9000 11000 17500 2169 2784 3663 5569 NOMINAL HEATING CAPACITY Btu/h 7400...
  • Page 12 R407C Models (HEATPUMP) INDOOR UNIT AWM 25FR AWM 301R MODEL OUTDOOR UNIT A4LC 25BR A4LC 30CR 6008 8499 NOMINAL COOLING CAPACITY Btu/h 20500 29000 7034 8792 NOMINAL HEATING CAPACITY Btu/h 24000 30000 INPUT POWER (COOLING) - 1∅ / < 3∅ > 2571 <...

  • Page 13: Performance Table

    4. PERFORMANCE TABLE Interpolation and Extrapolation method can be used to get the total capacity, TC and sensible capacity, SC at those temperatures which are not stated out in the table. Example: Model: AWM 10F / ALC 10C Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 37°C DB Solution: Overall...
  • Page 14 Details: Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 24°C DB, 15°C WB Outdoor Condition: 35°C DB Outdoor DB, °C Indoor DB Indoor WB °C °C TC (kW) SC (kW) 2.582 1.835 2.659 1.739 Total capacity, TC =>...
  • Page 15 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 35°C DB Outdoor DB, °C Indoor DB Indoor WB °C °C TC (kW) SC (kW) 2.506 1.363 2.506 1.931 Total capacity, TC ⇒...
  • Page 16 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 37°C DB Outdoor DB, °C Indoor DB Indoor WB °C °C TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) 2.506 1.789...
  • Page 17 R22 MODELS (COOLING ONLY) MODEL : AWM 10F / ALC 10C Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 3.090 1.839 2.895 1.680 2.700 1.522 2.506 1.363 2.311 1.205 2.078 1.015 3.197 1.675...
  • Page 18 R22 MODELS (COOLING ONLY) MODEL : AWM 20F / ALC 20B Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 5.371 3.206 5.139 3.040 4.908 2.875 4.676 2.709 4.232 2.307...
  • Page 19 R22 MODELS (COOLING ONLY) MODEL : AWM 301 / ALC 30B Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 7.743 4.459 7.364 4.208 6.985 3.957 6.606 3.706 6.290 3.416...
  • Page 20 R22 MODELS (HEATPUMP) MODEL : AWM 10FR / ALC 10CR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 3.165 1.854 2.945 1.677 2.725 1.500 2.505 1.323 2.285 1.147 2.021 0.934 3.260...
  • Page 21 R22 MODELS (HEATPUMP) MODEL : AWM 15FR / ALC 15CR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 3.521 2.168 3.335 2.021 3.149 1.874 2.963 1.727 2.778 1.580 2.555 1.403 3.747...
  • Page 22 R22 MODELS (HEATPUMP) MODEL : AWM 20FR / ALC 20BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 5.685 3.279 5.363 3.031 5.042 2.784 4.720 2.536 4.272...
  • Page 23 R22 MODELS (HEATPUMP) MODEL : AWM 25FR / ALC 25BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 6.472 3.547 6.177 3.440 5.882 3.333 5.586 3.226 5.414...
  • Page 24 R22 MODELS (HEATPUMP) MODEL : AWM 30FR / ALC 30BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 8.004 4.615 7.551 4.231 7.097 3.847 6.644 3.462 6.326...
  • Page 25 R22 MODELS (HEATPUMP) MODEL : AWM 30FR / ALC 30CR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 8.826 4.927 8.373 4.647 7.920 4.366 7.467 4.085 7.109...
  • Page 26 R407C MODELS (COOLING ONLY) MODEL : AWM 07F / A4LC 07B Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 2.602 1.456 2.406 1.285 2.210 1.114 2.014 0.942 1.818 0.771 1.582 0.565 2.633 1.332...
  • Page 27 R407C MODELS (COOLING ONLY) MODEL : AWM 15F / A4LC 15B Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 3.138 1.749 2.984 1.639 2.831 1.529 2.677 1.420 2.523 1.310 2.339 1.178 3.370 1.645...
  • Page 28 R407C MODELS (COOLING ONLY) MODEL : AWM 25F / A4LC 25B Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 5.842 3.251 5.577 3.075 5.313 2.898 5.048 2.722 4.784 2.546 4.466 2.334 6.317 3.027...
  • Page 29 R407C MODELS (HEATPUMP) MODEL : AWM 07FR / A4LC 07BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 2.685 1.492 2.486 1.314 2.288 1.137 2.089 0.959 1.890 0.782 1.652 0.568 2.673...
  • Page 30 R407C MODELS (HEATPUMP) MODEL : AWM 10FR / A4LC 10BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 2.848 1.622 2.669 1.476 2.490 1.330 2.311 1.184 2.132 1.038 1.918 0.863 2.968...
  • Page 31 R407C MODELS (HEATPUMP) MODEL : AWM 15FR / A4LC 15BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 3.144 1.817 3.001 1.708 2.858 1.599 2.715 1.490 2.572 1.382 2.400 1.251 3.280...
  • Page 32 R407C MODELS (HEATPUMP) MODEL : AWM 20FR / A4LC 20BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 5.236 2.879 4.940 2.651 4.644 2.423 4.347 2.195 4.051 1.966 3.696 1.693 5.589...
  • Page 33 R407C MODELS (HEATPUMP) MODEL : AWM 25FR / A4LC 25BR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 5.528 2.786 5.276 2.695 5.024 2.603 4.772 2.512 4.519 2.421 4.217 2.311 6.253...
  • Page 34 R407C MODELS (HEATPUMP) MODEL : AWM 30FR / A4LC 30CR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 8.532 4.673 8.094 4.402 7.656 4.131 7.218 3.859 6.780 3.588 6.254 3.262 8.948...

  • Page 35: Operating Range

    5. OPERATING RANGE Ensure the operating temperature is in allowable range. Cooling only Cooling Caution : HIGH AMBIENT UNIT The use of your air conditioner outside the range of working temperature and humidity can result in serious failure. LOW AMBIENT Indoor temp.

  • Page 36: Noise Level

    6. NOISE LEVEL SOUND PRESSURE LEVEL (MEASURED IN ANECHOIC ROOM) WALL MOUNTED FAN COIL UNIT Model Speed Overall Noise 1/1 Octave A-weighted Sound Pressure (dBA), ref 20µPa A(dBA) Criteria 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz AWM 07F/FR High Medium AWM 10F/FR High Medium...
  • Page 37 AWM 07F/FR NC CURVES AWM 10F/FR NC CURVES...
  • Page 38 AWM 15F/FR NC CURVES AWM 20F/FR NC CURVES...
  • Page 39 AWM 25F/FR NC CURVES AWM 301/301R NC CURVES...

  • Page 40: Outlines And Dimension

    7. OUTLINES AND DIMENSION INDOOR UNIT MODEL: AWM 10F / 10FR / 15F / 15FR 815.0 180.8 TOP VIEW TOP VIEW FRONT VIEW SIDE VIEW SIDE VIEW FRONT VIEW 721.0 Note : Dimension in mm INSTALLATION PLATE INSTALLATION PLATE OUTDOOR UNIT MODEL: A4LC 07B/ 07BR / 10B / 10BR / 15B / 15BR 740.0 129.0 ±...
  • Page 41 INDOOR UNIT MODEL : AWM 20F / 20FR / 25F / 25FR TOP VIEW SIDE VIEW FRONT VIEW 293.9 133.9 Note : Dimension in mm INSTALLATION PLATE OUTDOOR UNIT MODEL : ALC 20B / 20BR / 25B / 25BR / 30B / 30BR A4LC 20B / 20BR / 25B / 25BR Note : Dimension in mm...
  • Page 42 INDOOR UNIT MODEL : AWM 301/ 301R 1200.0 TOP VIEW FRONT VIEW SIDE VIEW INSTALLATION PLATE Note : Dimension in mm OUTDOOR UNIT MODEL : ALC 30C, ALC 30CR A4LC 30C, A4LC 30CR Note : Dimension in mm...
  • Page 43 INDOOR UNIT MODEL: AWM 10F / 10FR / 15F / 15FR 815.0 180.8 TOP VIEW FRONT VIEW SIDE VIEW 721.0 Note : Dimension in mm INSTALLATION PLATE OUTDOOR UNIT MODEL : ALC 10C / 10CR / 15C / 15CR Note : Dimension in mm...

  • Page 44: Refrigeration Cycle Diagram

    8. REFRIGERATION CYCLE DIAGRAM COOLING ONLY MODELS MODEL : A4LC 07B/ 10B / 15B / 20B ALC 10C/15C MODEL : ALC/A4LC 25B, ALC 30B...
  • Page 45 MODEL : ALC 30B MODEL : ALC / A4LC 30C...
  • Page 46 HEATPUMP MODELS MODEL : A4LC 07BR / 10BR, ALC 10CR MODEL : A4LC 15BR...
  • Page 47 MODEL : ALC 15CR MODEL : ALC /A4LC 20BR...
  • Page 48 MODEL : ALC / A4LC 25BR, ALC 30BR MODEL : ALC / A4LC 30CR...

  • Page 49: Wiring Diagrams

    9. WIRING DIAGRAM COOLING ONLY MODELS INDOOR UNIT MODEL : AWM 07F / 10F / 15F (D2.0 I.C.) 1 PHASE 220 - 240V 50Hz OUTDOOR UNIT MODEL :A4LC 07B / 10B / 15B...
  • Page 50 INDOOR UNIT MODEL : AWM 20F / 25F (D2.0 I.C.) 1 PHASE 220 - 240V 50Hz OUTDOOR UNIT MODEL : ALC 20B / 25B A4LC 20B / 25B...
  • Page 51 INDOOR UNIT MODEL : AWM 20F / 25F (D2.0 I.C.) OUTDOOR UNIT MODEL : ALC 20B / 25B A4LC 20B / 25B 3 PHASE 380 - 415V 50Hz...
  • Page 52 OUTDOOR UNIT MODEL : ALC30B INDOOR UNIT MODEL : AWM301 (D2.0 I.C.)
  • Page 53 INDOOR UNIT MODEL : AWM 301 (D2.01.C) OUTDOOR UNIT MODEL : ALC/ A4LC 30C...
  • Page 54 INDOOR UNIT MODEL : AWM 301 (D2.01.C.) OUTDOOR UNIT MODEL : ALC/ A4LC 30C...
  • Page 55 INDOOR UNIT MODEL : AWM 15F (D2.0 I.C.) 1 PHASE 220 - 240V 50 Hz OUTDOOR UNIT MODEL : ALC 15C...
  • Page 56 INDOOR UNIT MODEL : AWM 10F (D2.0 I.C.) 1 PHASE 220 - 240V 50 Hz OUTDOOR UNIT MODEL : ALC 10C...
  • Page 57 HEATPUMP MODELS INDOOR UNIT MODEL : AWM 07FR / 10FR / 15FR (U1.4 I.C.) 1 PHASE 220 - 240V 50 Hz OUTDOOR UNIT MODEL : A4LC 07BR / 10BR / 15BR...
  • Page 58 INDOOR UNIT MODEL : AWM 20FR / 25FR (U1.4 I.C.) 1 PHASE 220 - 240V 50 Hz OUTDOOR UNIT MODEL : ALC 20BR / 25BR A4LC 20BR / 25BR...
  • Page 59 INDOOR UNIT MODEL : AWM 20FR / 25FR (U1.4 I.C.) 3 PHASE 380 - 415V 50 Hz OUTDOOR UNIT MODEL : ALC 20BR / 25BR A4LC 20BR / 25BR...
  • Page 60 INDOOR UNIT MODEL : AWM 301R (U1.4 1.C.) OUTDOOR UNIT MODEL : ALC / A4LC 30CR...
  • Page 61 INDOOR UNIT MODEL : AWM 301R (U1.4 1.C.) OUTDOOR UNIT MODEL : ALC / A4LC 30CR...
  • Page 62 INDOOR UNIT MODEL : AWM 301R OUTDOOR UNIT MODEL : ALC 30BR...
  • Page 63 INDOOR UNIT MODEL : AWM 10FR (U1.4 I.C.) 1 PHASE 220 - 240V 50 Hz OUTDOOR UNIT MODEL : ALC 10CR...
  • Page 64 INDOOR UNIT MODEL : AWM 15FR (U1.4 I.C.) OUTDOOR UNIT 1 PHASE MODEL : ALC 15CR 220 - 240V 50 Hz...
  • Page 65 HIGH AMBIENT UNIT (OPTIONAL) COOLING ONLY MODELS OUTDOOR UNIT MODEL : ALC 20B / 25B 50HZ / 1 PHASE / 220 – 240V OUTDOOR UNIT MODEL : ALC 30C 50HZ / 1 PHASE / 220 – 240V...
  • Page 66 HEATPUMP MODELS OUTDOOR UNIT MODEL : ALC 20BR / 25BR 50HZ / 1 PHASE / 220 – 240V OUTDOOR UNIT MODEL : ALC 30CR 50HZ / 1 PHASE / 220 – 240V...
  • Page 67 LOW AMBIENT UNIT (OPTIONAL) COOLING ONLY MODELS OUTDOOR UNIT MODEL : ALC 10C 50Hz/ 1 PHASE/ 220-240V OUTDOOR UNIT MODEL : ALC 15C 50Hz / 1 PHASE / 220 - 240V...
  • Page 68 COOLING ONLY MODELS OUTDOOR UNIT MODEL : ALC 10B / 15B 50HZ / 1 PHASE / 220~240V OUTDOOR UNIT MODEL : ALC 20B / 25B 50HZ / 1 PHASE / 220~240V...
  • Page 69 HEATPUMP MODELS OUTDOOR UNIT MODEL : ALC 10BR / 15BR 50HZ / 1 PHASE / 220 – 240V OUTDOOR UNIT MODEL : ALC 20BR 50HZ / 1 PHASE / 220 – 240V OUTDOOR UNIT MODEL : ALC 25BR 50HZ / 1 PHASE / 220 – 240V...

  • Page 70: Safety Precautions Before Installation

    10. SAFETY PRECAUTION BEFORE INSTALLATION Before operating, please read the following “Safety Precautions” carefully. To prevent injury to the user or other people and properties damage, the following instructions must be followed. Incorrect operation due to ignoring of instruction will cause harm or damage, the seriousness is classified by the following indications.
  • Page 71 Symbol (with white background) denotes item that is PROHIBITED from doing. Symbol (with black background) denotes item that is COMPULSORY to be carried out. Caution Please confirm the following important points when installation • Grounding is necessary It may cause electrical shock if grounding is not perfect. Do not install the unit where leakage of flammable gas may occur •...

  • Page 72: Special Precautions For R407C

    11. SPECIAL PRECAUTIONS FOR R407C SPECIAL PRECAUTIONS WHEN DEALING WITH REFRIGERANT R407C UNIT 1) What is new refrigerant R407C? R407C is a zeotropic refrigerant mixture which has Zero Ozone Depletion Potential (ODP = 0) and thus conformed to the Montreal Protocol regulation. It requires Polyol-ester oil (POE) oil for its compressor’s lubricant.
  • Page 73 b) Ensure that the compressor is not expose to open air for more than the recommended time specified by its manufacturer (typically less than 10 minutes). Removed the seal-plugs only when the compressor is about to be brazed. c) The system should be thoroughly vacuumed to 1.0 Pa (-700mmHg) or lower. This vacuuming level is more stringent than R22 system so as to ensure no incompressible gas and moisture in the system.

  • Page 74: Installation

    12. INSTALLATION INSTALLATION DIAGRAM...
  • Page 75 CAUTION: Before installing the unit, ensure that the power supply matches the power requirement of the air conditioner. 1) SELECTION OF LOCATION AND SPACE (A) INDOOR UNIT Install the fan coil (indoor) unit at a location with the following requirements ·...
  • Page 76 (B) OUTDOOR UNIT As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected for outdoor unit should fulfill the following requirements : • Install the condensing (outdoor) unit in away such that hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air).
  • Page 77 CONDENSED WATER DISPOSAL OF OUTDOOR UNIT (HEATPUMP UNIT ONLY) • There are 2 holes on the base of outdoor unit for condensed water to flow out. Insert the drain elbow to one of the holes. • To install the drain elbow, first insert one portion of the hook to the base (portion A), then pull the drain elbow in the direction shown by the arrow while inserting the other portion to the base.
  • Page 78 2) DRILLING HOLES AND MOUNTING INSTALLATION PLATE CAUTION: i) Please check the unit weight for each model. Always ensure that the wall is sufficiently strong to withstand the weight. If not, it is necessary to reinforce the wall with plate, beams or pillars.
  • Page 79 3) INDOOR UNIT PREPARATION • The refrigerant piping can be routed to • Carefully bend the pipes to the required the unit in 5 direction, by using the cut position to align with the hole. For right outs in the unit casing. (See fig. 1) hand and rear side draw out, hold the bottom of the piping and fix direction before shaping it to the desired position...
  • Page 80 5) WATER DRAINAGE PIPING The indoor drain pipe must be downward gradient for smooth drainage. Avoid situation as shown in figure below. 6) WIRING ELECTRICAL CONNECTION • Wiring regulation on wire diameters differ from country to country. Please refer to your LOCAL ELECTRICAL CODES for field wiring rules.
  • Page 81 7) INSTALLATION OF SEPARATE ORIFICE KIT AT OUTDOOR i) Outdoor Unit Installation Space Is Wide Enough STEP 2 OFIFICE PIPE STEP 1 Steps: a) Directly conncet the “Female” nut of orifice pipe to the liquid pipe. b) Flare the liquid pipe and connect it to the “Male” joint of the orifice pipe. Orifice Pipe Liquid Pipe...
  • Page 82 ii) Outdoor Installation Space Is Limited Step 4 If the orifice pipe cannot be connected Orifice Pipe directly to the liquid valve due to limitation Step 3 space, it can be connected between the liquid Step 2 pipes. Step 1 Steps : a) Flare the liquid pipe and connect it to the liquid valve.
  • Page 83 8) REFRIGERANT PIPING MAXIMUM PIPE LENGTH AND MAXIMUM NUMBER OF BENDS Always choose the shortest path for refrigerant piping and follow the recommendations as tabulated below: MODEL AWM 301/R DATA 10F/FR 15F/FR 20F/FR 25F/FR ALC30B/BR ALC30C/CR Max. Length (m) Max. Elevation (m) Max.

  • Page 84: Additional Charge

    4) After evacuation, unscrew the spindle (diagram B) for the gas to run to indoor unit. 5) Decision by low side pressure. Turn compressor on for 10 or 15 min. STANDARD CONDITION HEAVY LOAD CONDITION Indoor 27°C / Outdoor 35°C Indoor 32°C / Outdoor 43°C kg/cm psig...
  • Page 85 Diagram shows typical charging method. CAUTION FOR R407C Avoid prolong exposure of an opened compressor, or the internal part of refrigerant piping to moist air. The POE oil in the compressor and piping can absorb moisture from air 10) FINAL CHECKING •...

  • Page 86: Remote Controller Operation Guide

    13. REMOTE CONTROLLER OPERATION GUIDE G8 REMOTE CONTOLLER 1. Transmission source • The source where the signal will be transmitted. • Set the desired off time by pressing the SET button continuosly. • 2. Signal Transmission indication Press the CLR button to cancel the off timer setting. •...
  • Page 87 G12 REMOTE CONTROLLER Temperature Setting ON/OFF Logo Personalised Setting • To set the desired room temperature, • Green colour for cooling model. • Press and hold the button for 3s to press the button to increase or decrease initial personalized setting. the set temperature.
  • Page 88 INDICATOR LIGHTS (cooling only unit) IR signal receiver When there is infrared remote control operating signal, the signal receiver on indoor unit will made a (beep) for signal acceptance confirmation. LED Indicator Lights The table below shows the LED indicator light for air conditioner unit under normal operation and fault condition.
  • Page 89 Heatpump unit : LED Indicator Lights Display Cooling mode Dry mode (Green) (Orange) Heat/Fan Sleep mode mode (Red) (Red/Green) The heat pump units is equipped with an "auto" mode, whereby the unit will provide reasonable room temperature by switching the unit automatically to either "cool" mode or "heat" mode, according to the temperature setting set by the user.

  • Page 90: Special Function

    14. SPECIAL FUNCTION (A) 3 HOT SYSTEM (Heating cycle) a) Hot start At the beginning of heating operation (cold start, after defrosting or thermostat resumes operation) the indoor fan operation is controlled in accordance with the temperature of the indoor heat exchanger to send warm air from the start.
  • Page 91 c) Hot spurt During cold start, the set temperature of controller is increased by 2 C to stabilize the room temperature ° quickly. After the first stop of compressor or 30 minutes following the start of operation, the temperature setting will be restored to the original value.
  • Page 92 (D) OVERLOAD PROTECTION IN COOLING OPERATION When outdoor and indoor air temperature raise beyond the operation limit, or when the outdoor coil choked with dirt, the M.C. controller detects abnormal increase in condensing temperature. It will stop the operation to prevent compressor burn out. (E) FROST PREVENTION AND FILTER CHECK In order to prevent the freezing of indoor coil, the controller will operate as follow.

  • Page 93: Servicing And Maintenance

    15. SERVICING AND MAINTENANCE CAUTION: After installing or servicing the unit, please ensure that the front panel is secured by the 1 hook underneath the front panel. The unit is designed to give a long life operation with minimum maintenance required. However, it should be regularly checked and the following items should be given due attention.

  • Page 94: After Extended Shutdown

    PRE-START UP MAINTENANCE (AFTER EXTENDED SHUTDOWN) Inspect thoroughly and clean indoor and outdoor units. Clean or replace air filters. Clean condensate drain line. Clean clogged indoor and outdoor coils. Check fan imbalance before operation. Tighten all wiring connections and panels. Check for refrigerant leakage.

  • Page 95: Troubleshooting

    16. TROUBLESHOOTING By means of pressure readings : PRESSURE PROBABLE CAUSE Data Circuit ● 1. Overcharged with refrigerant. High Side ● 2. Non-condensable gases in refrigerant circuit (e.g.oil) Low Side 3. Obstructed air-intake / discharge. 4. Short circuiting of hot air outdoor unit. ●...
  • Page 96 The most common causes of air conditioner failure to “start” are : a) Voltage not within +/- 10% of rated voltage. b) Power supply interrupted. c) Control settings improper d) Air Conditioner is disconnected from main power source. e) Fuse blown or circuit breaker off. ii) Diagnosis Of Refrigerant Circuit /Application There might be some cases where the unit starts running but does not perform satisfactory, i.e.

  • Page 97: Parts List

    17. PARTS LIST INDOOR UNIT MODEL: AWM 10F / 10FR / 15F / 15FR 1. ASSY. MOUNTING PLATE 10. BUSH, FAN 2. CLAMP. PIPING 11. ASSY. EVAPORATOR COIL 3. ASSY. CHASIS 12. ASSY. FRONT FRAME A 4. ASSY. FAN MOTOR 13.
  • Page 98 MODEL : AWM 20F / 20FR / 25F / 25FR / 301/ 301R 1. ASSY. CHASIS 8. ASSY. EVAPORATOR COIL 2. PIPING, CLAMP 9. ASSY. AIR DISCHARGE HOUSING 3. ASSY. CONTROL BOX 10. CROSS FLOW FAN 4. ASSY. CONTROL BOX COVER 11.
  • Page 99 OUTDOOR UNIT MODEL: A4LC 07B / 10B / 15B 1. ASSY., BACK PANEL 14. ASSY., BASE PAN 2. ASSY., TOP PANEL 15. ASSY., CAPILLARY TUBE 3. ASSY., CONDENSER COIL 16. ASSY., PARTITION 4. BRACKET, MOTOR MOUNTING 17. ASSY., TERMINAL PANEL W/O CONT. 5.
  • Page 100 MODEL: ALC 20B / 25B A4LC 20B / 25B 1. ASSY., BACK PANEL 16. GROMMET, RUBBER 2. ASSY., TOP PANEL 17. NUT, WITH WASHER 3. ASSY., CONDENSOR COIL 18. ASSY., BASE PAN 4. BRACKET, MOTOR MOUNTING 19. ASSY., CAPILLARY TUBE 5.
  • Page 101 MODEL: ALC 30B 1. ASSY., BACK PANEL 16. GROMMET, RUBBER 2. ASSY., TOP PANEL 17. NUT, WITH WASHER 3. ASSY., CONDENSOR COIL 18. ASSY., BASE PAN 4. BRACKET, MOTOR MOUNTING 19. TUBE, COIL TO DISCHARGE VALVE 5. MOTOR, FAN 20. ASSY., PARTITION 6.
  • Page 102 MODEL: ALC / A4LC 30C 1. BASE PAN 11. MOTOR BRACKET ASSY 2. FLARE VALVE 12. SIDE PANEL LEFT 3. FLARE VALVE 13. FAN MOTOR 4. PARTITION 14. FAN BLADE 5. COMPRESSOR 15. FRONT PANEL ASSY 6. ACCESS PANEL 16. TERMINAL BOX ASSY 7.
  • Page 103 MODEL: A4LC 07BR / 10BR / 15BR 1. ASSY., BACK PANEL 13. NUT, COMPRESSOR 2. ASSY., TOP PANEL 14. ASSY., BASE PAN 3. ASSY, COIL OUTDOOR 15. ASSY., CAPILLARY TUBE 4. BRACKET, MOTOR MOUNTING 16. ASSY., PARTITION 5. FAN MOTOR 17.
  • Page 104 MODEL: ALC 20BR / 25BR / 30BR A4LC 20BR / 25BR 1. ASSY., BACK PANEL 15. WASHER, FLAT 2. ASSY., TOP PANEL 16. NUT, COMPRESSOR 3. ASSY, COIL OUTDOOR 17. ASSY., BASE PAN 4. BRACKET, MOTOR MOUNTING 18. ASSY., CAPILLARY TUBE 5.
  • Page 105 MODEL: ALC / A4LC 30CR 1. ASSY., BASE PAN 14. PANEL, SERVICE 2. ASSY., COIL 15. ASSY., FRONT PANEL 3. ASSY., VAVLE PLATE 16. PANEL, TOP 4. ASSY., COMPRESSOR 17. ASSY., TXV 5. ACCUMULATOR 18. COVER TERMINAL BOARD 6. ASSY., ACCUMULATOR CLIP 19.
  • Page 106 MODEL: ALC 10C / 15C 1. ASSY. BASE PAN 9. ASSY. PANEL LEFT INS. 2. ASSY. CONDENSER COIL 10. ASSY. PANEL RIGHT INS. 3. ASSY. COMPRESSOR 11. BRACKET, MOTOR 4. ASSY. VALVE BRCKET 12. MOTOR 5. ASSY. PARTITION INS. 13. ASSY. CONTROL PANEL 6.
  • Page 107 MODEL: ALC 10CR / 15CR 1. ASSY. BASE PAN 9. MOTOR 2. ASSY. CONDENSER COIL 10. FAN, 16" 3. ASSY. VALVE BRACKET 11. ASSY. PANEL LEFT INS. 4. ASSY. COMPRESSOR 12. ASSY. PANEL RIGHT INS. 5. ASSY. 4 WAYS VALVE 13.
  • Page 108 While upmost care is taken in ensuring that all details in the publication are correct at time of going to press, we are constantly striving for improvement and therefore reserve the rights to alter model specifications and equipment without prior notice. Details of specifications and equipment are also subject to change to suit local conditions and equipments and not all models are available in every market.
