Acson AWM 07G' AWM 07GR User Manual page 162

Model : A5LC 20CR (3 PHASE)
No Descriptions
1 ASSY,PAN BASE (5SL20C/CR)
ASSY,OUTDOOR COIL (5SL20C/CR-
2
2RX28TH)
3 BRACKET MOTOR (SL20C/CR)
MOTOR,YDK64-6C/MSL25C-501-
4
WL
FAN PROPELLER, ¥460 0Z40700
5
SUNWILL CHIN
ASSY,VALVE BRACKET
6
(5SL20C/CR)
7 PANEL RIGHT BACK (SL20C/CR)
8 COMPRESSOR, 5KS205PAB01 MAT R04019029246
9 PANEL FRONT/LEFT (SL20C/CR)
10 PANEL SERVICE (SL20C/CR)
ASSY CONTROL PANEL (5SL20CR
11
3PH)
12 PANEL TOP (SL20C/25C/28C/CR)
ASSY FRONT GRILLE
13
(SL20C/25C/28C/CR)
PLASTIC,HANDLE
14
SL07C/09C/10C/15C/CR
Downloaded from AC-Manual.com Manuals
Part No No Descriptions
R50014078281
R50024075143
R01014070601
R03039023391
Parts Not In The Diagram
R03019023393
R50014078280
R01014070599
R01014070597
R01014070598
R50044092275
R01014070596
R50124072880
R12014057948
160
15 ASSY VALVE COVER (SL20C/CR)
16 ASSY,CAPILLARY TUBE (5SL20CR)
ASSY,TUBING 4-WAY VALVE
17
(5SL20CR)
18 ASSY PARTITION (SL20C/CR)
ASSY,VALVE 3-WAY(1/2")JB48420-
1MA(R410A)
ASSY,VALVE 2-WAY(1/4")JA28493-
2MA(R410A)
PANEL TERMINAL COVER
(SL20C/25C/28C/CR)
CAPACITOR, CMPSR
3.5uF/450V(TAB250)Shizu
CAPACITOR, CMPSR 50uF/450VAC
Shizuki
CLAMP, CAPACITOR 126.0mm
ASSY TERMINAL PANEL
(SL20C/25C/28C/CR)
VALVE, REV 4 WAY SHF-7H-
34U(RK) SHANHUA
PHASE PROTECTOR, PP1.03 NO
SENSOR EXPORT
Part No
R50124072885
R50024081904
R50024080655
R50064072871
R50059023335
R50059023334
R01014070838
R04029026759
R04029026779
R07054028872
R50014072877
R05019016937
R04089018834
