INSTALLATION MANUAL
Model: IM-5ACV210CR-0706-ACSON
AIR COOLED CHILLER
(R410A INVERTER MODEL)
MINI CHILLER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5ACV210CR and is the answer not in the manual?

Questions and answers

Summary of Contents for Acson 5ACV210CR

  • Page 1 INSTALLATION MANUAL Model: IM-5ACV210CR-0706-ACSON AIR COOLED CHILLER (R410A INVERTER MODEL) MINI CHILLER...
  • Page 3: Outline And Dimensions

    OUTLINE AND DIMENSIONS 5ACV 210CR DETAIL A WATER OUTLET WATER INLET 1998.4 2092.5 1199.2 SEE DETAIL A 30.0 98.7 50.0 1992.5 50.0 1192.2 Sharp edges and coil surfaces are potential locations which may cause ! Caution injury hazards. Avoid from being in contact with these places. Les bords coupants et les surfaces du refroidisseur tuulaire prŽsentent ! Avertissement un risque de blessure.
  • Page 4: Unit Installation

    UNIT INSTALLATION 5ACV 210CR 500.0 500.0...
  • Page 5 ! ! ! ! ! CAUTION • Improper handling of unit during installation could result in leaks, electrical shock or unit malfunction. • Contact your dealer for reinstallation or dismantling of unit. • Do not introduce foreign objects such as fingers, sticks etc. into the air inlet and air outlet. •...
  • Page 6: Electrical Wiring Diagram

    ELECTRICAL WIRING DIAGRAM MODEL : 5ACV 210CR...
  • Page 7: Installation Manual

    AIR COOLED INVERTER CHILLER MODEL HEAT PUMP R410A 5ACV210CR / A5ACV210CR ! ! ! ! ! WARNING Installation and maintenance should be performed by qualified persons who are familiar with local code and regulation, and experienced with this type of appliance.
  • Page 8: Installation Location

    INDEX - Outline And Dimensions page i - Recommended Fuse And Calbe Sizes page 3 - Unit Installation page ii - Refrigerant Circuit page 4 - Electrical Wiring Diagram page iv - Special Precautions When Dealing With R410A Unit page 4 - Transportation page 1 - Refrigerant Circuit Diagrams...
  • Page 9: Physical Data

    PHYSICAL DATA Table A-1 : R410A - Heat Pump Model 5ACV210CR Nominal cooling capacity 58.56 Nominal heating capacity 61.49 Operating Weight 682.0 Refrigerant charge R410A 9.5 / 8.5 Compressor 2 Scroll + 1 Inverter Compressor Control system LCD Electronic Control...
  • Page 10: Electrical And Wiring

    Refer to the wiring diagram provided on the unit when making electrical wiring. Do not ground any electrical equipment to the water piping. ELECTRICAL DATA Table B-1 : R410A - Heat Pump Model 5ACV210CR Power supply V-ph-Hz 400 / 3 / 50 Voltage range...
  • Page 11: Refrigerant Circuit

    ! ! ! ! ! CAUTION • All field wiring must be installed in accordance with the national wiring regulation. • All the terminals and connections must be tightened. Improper connection and fastenings could cause electric shock, short circuit and fire. •...
  • Page 12: Refrigerant Circuit Diagram

    5ACV 210CR Refrigerant Circuit Diagram FIN TUBE FIN TUBE HEAT EXCHANGER HEAT EXCHANGER (SYSTEM 1) (SYSTEM 2) FILTER FILTER 4-WAY VALVE 4-WAY VALVE DRIER TWIN DRIER TUBE JOINT CHECK CHECK VALVE VALVE SEPARATOR SEPARATOR COMPRESSOR RETURN SUCTION TUBE ACCUMULATOR LIQUID LIQUID RECEIVER RECEIVER...
  • Page 13: Lcd Panel Installation

    CONTROL OPERATION GUIDE The unit is equipped with a microprocessor controller board. The microprocessor controller is provided to give temperature control for the system by accurately measuring and controlling the water entering and water leaving temperature. The tem- perature setting in the unit is preset in the factory. It is not recommended to change the setting unless necessary. A wired controller handset is connected to the microprocessor board.
  • Page 14: Maintenance

    1. A 3V DC battery is supplied with the LCD. It is used to ensure that the LCD displays real time once the timer is set. 2. The LCD is wired to the main board via CN8 connection. (This is factory installed) If the wiring between the LCD and PCB must be longer, an alternative is used.
  • Page 16 • In the event that there is any conflict in the interpretation of this manual and any translation of the same in any language, the English version of this manual shall prevail. • The manufacturer reserves the right to revise any of the specification and design contain herein at any time without prior notification.

This manual is also suitable for:

A5acv210cr
