  • Page 1 Technical Manual DUCTED BLOWER SERIES R22 COOLING...
  • Page 2 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Content Page Nomenclature ---------------------------------------- Product Line Up Application Information ---------------------------------------- Operating Range Refrigerant Circuit Diagrams Installation Guideline Sound Data ---------------------------------------- Sound Pressure Level NC Curve Selection Process ---------------------------------------- Engineering and Physical ---------------------------------------- Data Performance Data ---------------------------------------- Outline and Dimension ---------------------------------------- Wiring Diagrams ----------------------------------------...
  • Page 3 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Nomenclature Indoor A D B 2 0 0 B 2– A F A A Product Specification Brand Variation A :Acson AA: Revision Type of Connection Refrigerant “ ”: R22 B: Brazed F: Flare 4: R407C Product Type...
  • Page 4 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Outdoor A M C 1 0 0 B – F B C A Product Specification Variation Brand CA: Revision A: Acson Type of Connection Refrigerant B: Brazed “ ”: R22 F: Flare 4: R407C Product Type Electrical Characteristics...
  • Page 5 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Product Line-Up Indoor Unit ADB-B Classification ADB-B AFAA AFCA AFAA AFCA AFAA AFCA ABJA 100B ABJA 125B FBJA 150B1 FBJA FBAE 150B2 FBAF FBAE FBCB 200B2 FBAF FBCC FBAB 250B2 FBCB FBCA FBAB 300B2 FBCB FBCA...
  • Page 6 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Classification ADB-B FBAB 300B3 FBCB FBCA FBAB 350B3 FBCB FBCA FBAB 400B4 FBCB FBCA FBAB 450B3 FBCB FBCA FBAB 500B4 FBCB FBCA FBAB 600B4 FBCA FBAB 750B5 FBCA...
  • Page 7 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor ADB-D Classification ADB-D ABAD 100D ABAD 125D FBAA 150D1 FBAD 150D2 FBAA 200D2 FBAD 300D2 FBAD 400D4 FBAD 500D4 FBAA...
  • Page 8 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Outdoor ALC-D Classification AMCOA AMCIA FMDOB FMDIB FMDOB FMDIB FMYOB FMYIB...
  • Page 9 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 AMC-B/C Classification FBDA FBJA FBDA FBDB FBJA FBCA 100B FBCB FBJA FBCA 125B FBCB FBJA FBCC 150C FBCB FBJA...
  • Page 10 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Outdoor A4MC-D Classification A4MC FBCA 100D FBCA 125D FBCA 150D FBCA...

  • Page 11: Application Information

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Application Information Operating Range Ensure the operating temperature is in allowable range. Caution : Outdoor DB (°C) The use of your air conditioner outside the range of working temperature and humidity can result in serious failure. Indoor WB (°C)
  • Page 12 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Refrigerant Circuit Diagram Cooling Only Models...
  • Page 13 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Installation Guideline INDOOR PRELIMINARY SITE SURVEY a) Electrical supply and installation is to confirm to local authority’s (e.g. National Electricity Board) codes and regulations. b) Voltage supply fluctuation must not exceed +/- 10% of rated voltage. Electricity supply line must be independent of welding transformers which can cause supply fluctuation.
  • Page 14 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR CLEARANCE Mounting Ensure that the overhead supports are Provide clearance for servicing and optimal strong enough to hold the unit’s weight. air flow as shown in the diagram. Position hanger rods and check for alignment with the unit. Check that hangers The indoor unit must be installed such that are secure and that the base of fan-coil unit there is no short circuit of cool discharge with...
  • Page 15 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 OUTDOOR LOCATION FOR INSTALLATION OF THE CONDENSING UNITS As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected should fulfil the following requirements:- a) Install the condensing (outdoor) unit in a way such that hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air).
  • Page 16 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 OUTDOOR CLEARANCE AMC100B/125B ALC35/40/50/61D Model AMC150C AMC72/80/100C A4MC75/100/125/150D A (mm) B (mm) 1200 1500 C (mm) 1000 D (mm)

  • Page 17: Cable Size

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Cable Size Indoor ADB40B ADB40B ADB50B Model Outdoor ALC35D ALC40D ALC50D Indoor 220 - 240V /1Ph /50Hz + N + Voltage Range** Outdoor 380 - 415V /3Ph /50Hz + N + Power supply cable size* A) Indoor mm²...
  • Page 18 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor ADB125B ADB150B1 ADB200B2 Model Outdoor AMC125B AMC150C AMC100B x 2 Indoor 380 - 415V /3Ph /50Hz + N + Voltage Range** Outdoor 380 - 415V /3Ph /50Hz + N + Power supply cable size* A) Indoor mm²...
  • Page 19 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor ADB350B3 ADB400B4 Model Outdoor AMC100B AMC125B x 2 AMC100B x 4 Indoor 380 - 415V /3Ph /50Hz + N + Voltage Range** Outdoor 380 - 415V /3Ph /50Hz + N + Power supply cable size* A) Indoor mm²...
  • Page 20 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor ADB75D ADB100D Model Outdoor A4MC75D A4MC100D Indoor 220 - 240V /1Ph /50Hz + N + Voltage Range** Outdoor 380 - 415V /3Ph /50Hz + N + Power supply cable size* A) Indoor mm² B) Outdoor mm² C) Total mm²...
  • Page 21 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model Indoor ADB200B2 ADB250B2 ADB300B2 A4MC100D A4MC125D A4MC150D Outdoor Voltage Range** Indoor 380 - 415V /3Ph /50Hz + N + Outdoor 380 - 415V /3Ph /50Hz + N + Power supply cable size* A) Indoor mm² B) Outdoor mm²...
  • Page 22 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Refrigerant Piping Maximum Piping Length and Maximum Number of Bends When the pipe length becomes too long, both the capacity and reliability will drop and as the number of bends increases, system piping resistance to the refrigerant flow increases, thus lowering the cooling capacity.
  • Page 23 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Additional Charge For ball valve type, the refrigerant is pre-charge in the outdoor unit. If the piping length is less than 7.5m, then additional charge after vacuuming is not necessary. When the piping length is more than 7.5m, use the table below. For Brazed type, if the piping is less than 7.5m, follow the charge level on serial number sticker.

  • Page 24: Sound Data

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Sound Data Indoor Sound Pressure Level Overall Noise 1/1 Octave Sound Pressure Level (dB) ref 20 Pa Model Speed 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz (dBA) Criteria High ADB40B High ADB50B High ADB60B High ADB80B High ADB100B ADB125B High...
  • Page 25 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Model Measuring Location UNIT 2m discharge duct length 1m return duct length ADB40B ADB50B ADB60B ADB80B ADB100B ADB125B 1.5m ADB150B1 ADB200B2 Microphone position: 1.5m below centre of the unit. (Tested with 2m length duct at the air discharge outlet and 1m length air return inlet) Standard: JIS B 8615 UNIT...
  • Page 26 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Sound Power Level 1/1 Octave Sound Power Level (dB) ref 1pW Overall Model Speed (dBA) 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz High *ADB40B High *ADB50B High *ADB60B High *ADB80B High *ADB100B *ADB125B High *ADB150B1 High *ADB200B2 High ADB250B2...
  • Page 27 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 NC Curve...
  • Page 28 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 29 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 30 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 31 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 32 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 33 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 34 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 35 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 36 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 37 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 38 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 39 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Selection Process Fan Performance Chart Example 1: The following are the design requirements for ADB300B2 unit: Model ADB300B2 Supply Air Quantity 9500 External Static Pressure Step 1: From the fan curve (at 9500 CFM) Standard operating system: Total Static Pressure Internal Static Pressure External Static Pressure...
  • Page 40 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 When the pulley is changed, the V-belt length must be rechecked. We have for horizontal Step 4: air throw configuration: V-belt length, L 2C + 1.57 (Db + Dm) (2 x 599) + 1.57 (95 + 160) 1598.35 We thus can use a belt with a length of 1600mm: Where,...
  • Page 41 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 V-Belt Motor Pulley, Dm Blower Pulley, Db Length (mm) Model Diameter Diameter Type Type Type (mm) (mm) Horizontal Vertical ADB125B SPZ 1 SPZ 1 1060 1080 ADB150B1 SPZ 1 SPZ 2 1000 1060 ADB150B2 SPZ 2 SPZ 1 1060 1080 ADB200B2...
  • Page 42 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Example 1:...
  • Page 43 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Fan Performance Curve...
  • Page 44 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 45 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 46 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 47 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 48 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 49 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 50 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 51 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 52 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 53 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 54 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 55 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 56 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 57 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 58 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 59 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 60 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 61 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 62 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 63 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 64 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 65 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 66 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...
  • Page 67 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1...

  • Page 68: Engineering And Physical Data

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Engineering and Physical Data Engineering Data - R22 MODEL INDOOR UNIT ADB40B ADB40B MODEL OUTDOOR UNIT ALC35D ALC40D Btu/h 35,000 40,000 NOMINAL COOLING CAPACITY 10,260 11,720 NOMINAL TOTAL INPUT POWER (COOLING) 3,155 3,942 NOMINAL RUNNING CURRENT (COOLING) 15.1 3.25 2.97...
  • Page 69 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB50B ADB60B MODEL OUTDOOR UNIT ALC50D ALC61D Btu/h 50,000 61,000 NOMINAL COOLING CAPACITY 14,650 17,880 NOMINAL TOTAL INPUT POWER (COOLING) 5,608 5,954 NOMINAL RUNNING CURRENT (COOLING) 2.61 REFRIGERANT CONTROL (EXPANSION DEVICE) CAPILLARY TUBE CAPILLARY TUBE REFRIGERANT CHARGE 2.55 ID: 220 ~ 240/1/50...
  • Page 70 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB80B ADB80B MODEL OUTDOOR UNIT AMC72C AMC80C Btu/h 70,000 80,000 NOMINAL COOLING CAPACITY 20,515 23,450 NOMINAL TOTAL INPUT POWER (COOLING) 7,109 8,760 NOMINAL RUNNING CURRENT (COOLING) 13.6 15.2 2.89 2.68 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE ID: 220 ~ 240/1/50...
  • Page 71 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB100B ADB100B MODEL OUTDOOR UNIT AMC100B AMC100C Btu/h 100,000 100,000 NOMINAL COOLING CAPACITY 29,310 29,310 NOMINAL TOTAL INPUT POWER (COOLING) 10,334 10,914 NOMINAL RUNNING CURRENT (COOLING) 19.4 19.7 2.84 2.69 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE ID: 220 ~ 240/1/50...
  • Page 72 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB125B ADB150B1 MODEL OUTDOOR UNIT AMC125B AMC150C Btu/h 125,000 150,000 NOMINAL COOLING CAPACITY 36,640 43,960 NOMINAL TOTAL INPUT POWER (COOLING) 12,344 16,200 NOMINAL RUNNING CURRENT (COOLING) 21.4 31.8 2.97 2.71 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE 7.95...
  • Page 73 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB200B2 ADB200B2 MODEL OUTDOOR UNIT AMC100B X 2 AMC100C X 2 Btu/h 200,000 200,000 NOMINAL COOLING CAPACITY 58,620 58,620 NOMINAL TOTAL INPUT POWER (COOLING) 20,118 21,158 NOMINAL RUNNING CURRENT (COOLING) 39.3 43.3 2.91 2.77 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 74 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB250B2 ADB300B2 MODEL OUTDOOR UNIT AMC125B X 2 AMC150C X 2 Btu/h 250,000 300,000 NOMINAL COOLING CAPACITY 73,270 87,920 NOMINAL TOTAL INPUT POWER (COOLING) 25,658 34,190 NOMINAL RUNNING CURRENT (COOLING) 44.5 66.4 2.86 2.57 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 75 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB300B3 ADB300B3 MODEL OUTDOOR UNIT AMC100B X 3 AMC100C X 3 Btu/h 300,000 300,000 NOMINAL COOLING CAPACITY 87,920 87,920 NOMINAL TOTAL INPUT POWER (COOLING) 30,832 32,392 NOMINAL RUNNING CURRENT (COOLING) 59.8 65.8 2.85 2.71 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 76 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB350B3 MODEL OUTDOOR UNIT AMC100B AMC125B X 2 Btu/h 350,000 NOMINAL COOLING CAPACITY 102,580 NOMINAL TOTAL INPUT POWER (COOLING) 36,621 NOMINAL RUNNING CURRENT (COOLING) REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV REFRIGERANT CHARGE 7.95 (x2) POWER SOURCE V/Ph/Hz 380 ~ 415/3/50 REFRIGERANT TYPE...
  • Page 77 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB400B4 ADB400B4 MODEL OUTDOOR UNIT AMC100B X 4 AMC100C X 4 Btu/h 400,000 400,000 NOMINAL COOLING CAPACITY 117,230 117,230 NOMINAL TOTAL INPUT POWER (COOLING) 39,773 41,853 NOMINAL RUNNING CURRENT (COOLING) 77.4 85.4 2.95 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 78 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB450B3 ADB500B4 MODEL OUTDOOR UNIT AMC150C X 3 AMC125B X 4 Btu/h 450,000 500,000 NOMINAL COOLING CAPACITY 131,890 146,540 NOMINAL TOTAL INPUT POWER (COOLING) 50,236 51,734 NOMINAL RUNNING CURRENT (COOLING) 97.3 89.7 2.63 2.83 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 79 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB600B4 ADB750B5 MODEL OUTDOOR UNIT AMC150C X 4 AMC150C X 5 Btu/h 600,000 750,000 NOMINAL COOLING CAPACITY 175,850 219,810 NOMINAL TOTAL INPUT POWER (COOLING) 67,577 85,981 NOMINAL RUNNING CURRENT (COOLING) 131.9 166.9 2.56 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 80 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB80B ADB80B ADB100B MODEL OUTDOOR UNIT AMC72C (PFC) AMC80C (PFC) AMC100B (PFC) Btu/h 70,000 80,000 100,000 NOMINAL COOLING CAPACITY 21,100 23,450 29,310 NOMINAL TOTAL INPUT POWER (COOLING) 6,400 8,000 10,460 NOMINAL RUNNING CURRENT (COOLING) 11.6 14.1 17.8 2.93...
  • Page 81 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB125B ADB150B1 MODEL OUTDOOR UNIT AMC125B (PFC) AMC150C (PFC) Btu/h 125,000 150,000 NOMINAL COOLING CAPACITY 36,640 43,960 NOMINAL TOTAL INPUT POWER (COOLING) 11,850 15,760 NOMINAL RUNNING CURRENT (COOLING) 20.8 30.8 3.09 2.79 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 82 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB200B2 ADB250B2 MODEL OUTDOOR UNIT AMC100B X 2 (PFC) AMC125B X 2 (PFC) Btu/h 200,000 250,000 NOMINAL COOLING CAPACITY 58,620 73,270 NOMINAL TOTAL INPUT POWER (COOLING) 20,250 24,430 NOMINAL RUNNING CURRENT (COOLING) 35.9 42.7 2.89 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV...
  • Page 83 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB300B2 ADB300B3 MODEL OUTDOOR UNIT AMC150C X 2 (PFC) AMC100B X 3 (PFC) Btu/h 300,000 300,000 NOMINAL COOLING CAPACITY 87,920 87,925 NOMINAL TOTAL INPUT POWER (COOLING) 32,750 31,030 NOMINAL RUNNING CURRENT (COOLING) 62.5 54.6 2.68 2.83 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV...
  • Page 84 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB350B3 ADB400B4 MODEL OUTDOOR UNIT AMC100B (PFC) AMC125B X 2 (PFC) AMC100B X 4 (PFC) Btu/h 350,000 400,000 NOMINAL COOLING CAPACITY 102,580 117,230 NOMINAL TOTAL INPUT POWER (COOLING) 35,459 40,037 NOMINAL RUNNING CURRENT (COOLING) 61.5 70.5 2.89 2.93...
  • Page 85 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB450B3 ADB500B4 MODEL OUTDOOR UNIT AMC150C X 3 (PFC) AMC125B X 4 (PFC) Btu/h 450,000 500,000 NOMINAL COOLING CAPACITY 131,890 146,540 NOMINAL TOTAL INPUT POWER (COOLING) 48,076 49,278 NOMINAL RUNNING CURRENT (COOLING) 91.5 86.1 2.74 2.97 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV...
  • Page 86 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB600B4 ADB750B5 MODEL OUTDOOR UNIT AMC150C X 4 (PFC) AMC150C X 5 (PFC) Btu/h 600,000 750,000 NOMINAL COOLING CAPACITY 175,850 219,810 NOMINAL TOTAL INPUT POWER (COOLING) 64,697 82,381 NOMINAL RUNNING CURRENT (COOLING) 124.2 157.3 2.72 2.67 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV...
  • Page 87 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB75D ADB100D MODEL OUTDOOR UNIT A4MC75D A4MC100D Btu/h 73000 91000 NOMINAL COOLING CAPACITY 21395 26670 NOMINAL TOTAL INPUT POWER (COOLING) 7636 11526 NOMINAL RUNNING CURRENT (COOLING) 14.6 19.5 2.80 2.31 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE ID: 220 ~ 240/1/50...
  • Page 88 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB125D ADB150D1 MODEL OUTDOOR UNIT A4MC125D A4MC150D Btu/h 108000 145000 NOMINAL COOLING CAPACITY 31640 42500 NOMINAL TOTAL INPUT POWER (COOLING) 12100 16239 NOMINAL RUNNING CURRENT (COOLING) 21.7 28.4 2.62 2.62 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE 10.1...
  • Page 89 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB150D2 ADB200D2 MODEL OUTDOOR UNIT A4MC75D X 2 A4MC100D X 2 Btu/h 146000 182000 NOMINAL COOLING CAPACITY 42790 53340 NOMINAL TOTAL INPUT POWER (COOLING) 15536 22372 NOMINAL RUNNING CURRENT (COOLING) 30.2 39.5 2.75 2.38 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 90 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB300D2 ADB400D4 MODEL OUTDOOR UNIT A4MC150D X 2 A4MC100D X 4 Btu/h 290000 364000 NOMINAL COOLING CAPACITY 84990 106680 NOMINAL TOTAL INPUT POWER (COOLING) 33998 45044 NOMINAL RUNNING CURRENT (COOLING) 59.2 79.3 2.50 2.37 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 91 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB500D4 MODEL OUTDOOR UNIT A4MC125D X 4 Btu/h 432000 NOMINAL COOLING CAPACITY 126610 NOMINAL TOTAL INPUT POWER (COOLING) 53820 NOMINAL RUNNING CURRENT (COOLING) 93.1 2.35 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV REFRIGERANT CHARGE 10.1 X 4 POWER SOURCE V/Ph/Hz 380 ~ 415/3/50...
  • Page 92 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB200B2 ADB250B2 MODEL OUTDOOR UNIT A4MC100D X 2 A4MC125D X 2 Btu/h 182000 216000 NOMINAL COOLING CAPACITY 53340 63280 NOMINAL TOTAL INPUT POWER (COOLING) 22,502 25,330 NOMINAL RUNNING CURRENT (COOLING) 39.6 45.1 2.37 2.50 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 93 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB300B2 ADB300B3 MODEL OUTDOOR UNIT A4MC150D X 2 A4MC100D X 3 Btu/h 2900000 273000 NOMINAL COOLING CAPACITY 85000 80010 NOMINAL TOTAL INPUT POWER (COOLING) 34,048 34,408 NOMINAL RUNNING CURRENT (COOLING) 59.2 60.2 2.50 2.33 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 94 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB350B3 MODEL OUTDOOR UNIT A4MC100D A4MC125D X 2 Btu/h 307000 NOMINAL COOLING CAPACITY 89950 NOMINAL TOTAL INPUT POWER (COOLING) 37,485 NOMINAL RUNNING CURRENT (COOLING) 65.8 2.40 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV REFRIGERANT CHARGE 7.95 (x2) POWER SOURCE V/Ph/Hz 380 ~ 415/3/50...
  • Page 95 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB400B4 ADB450B3 MODEL OUTDOOR UNIT A4MC100D X 4 A4MC150D X 3 Btu/h 364000 435000 NOMINAL COOLING CAPACITY 106680 127500 NOMINAL TOTAL INPUT POWER (COOLING) 44,541 50,023 NOMINAL RUNNING CURRENT (COOLING) 77.9 86.5 2.40 2.55 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...
  • Page 96 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 INDOOR UNIT ADB500B4 ADB600B4 MODEL OUTDOOR UNIT A4MC125D X 4 A4MC150D X 4 Btu/h 431800 580000 NOMINAL COOLING CAPACITY 126560 170000 NOMINAL TOTAL INPUT POWER (COOLING) 51,078 67,293 NOMINAL RUNNING CURRENT (COOLING) 90.9 117.5 2.48 2.53 REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR TXV INDOOR TXV REFRIGERANT CHARGE...

  • Page 97: Performance Data

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Performance Data Model: ADB40B – ALC35D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 9.67 6.57 2.40 9.33 6.40 2.60 8.98 6.23 2.81 8.62 6.05 3.05 7.92 5.63 3.31 7.31 5.30 3.65 24°C 9.69 7.87 2.40...
  • Page 98 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB40B – ALC40D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 11.05 7.51 2.99 10.66 7.31 3.24 10.26 7.11 3.51 9.85 6.91 3.80 9.05 6.43 4.12 8.35 6.05 4.55 24°C 11.06 8.99 2.99 10.67 8.78...
  • Page 99 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB50B – ALC50D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 13.82 9.39 4.26 13.33 9.14 4.61 12.83 8.90 4.99 12.32 8.64 5.41 11.31 8.04 5.87 10.44 7.57 6.48 24°C 13.84 11.24 4.26 13.34 10.99...
  • Page 100 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB60B – ALC61D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 16.86 11.45 4.52 16.26 11.15 4.89 15.66 10.85 5.30 15.03 10.54 5.74 13.80 9.80 6.23 12.74 9.22 6.87 24°C 16.88 13.71 4.52 16.28 13.39...
  • Page 101 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB80B – AMC72C Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 19.34 14.41 5.40 18.66 14.04 5.84 17.97 13.66 6.33 17.25 13.27 6.86 15.84 12.35 7.44 14.62 11.61 8.21 24°C 19.37 17.26 5.40 18.68 16.86...
  • Page 102 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB80B – AMC80C Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 22.11 16.48 6.66 21.32 16.05 7.20 20.53 15.61 7.80 19.71 15.17 8.45 18.10 14.11 9.17 16.71 13.28 10.11 24°C 22.14 19.73 6.66 21.35 19.28...
  • Page 103 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB100B – AMC100B Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 27.65 18.78 7.85 26.67 18.29 8.49 25.68 17.80 9.19 24.65 17.29 9.97 22.63 16.09 10.81 20.89 15.13 11.92 24°C 27.68 22.49 7.85 26.70 21.98...
  • Page 104 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB100B – AMC100C Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 27.65 18.78 8.29 26.67 18.29 8.97 25.68 17.80 9.71 24.65 17.29 10.53 22.63 16.09 11.42 20.89 15.13 12.59 24°C 27.68 22.49 8.29 26.70 21.98...
  • Page 105 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB125B – AMC125B Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 36.20 25.20 9.68 35.05 24.64 10.35 33.83 24.05 11.12 32.52 23.43 12.00 29.27 21.39 12.98 27.19 20.23 14.29 24°C 36.34 30.01 9.69 35.19 29.39...
  • Page 106 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB150B1 – AMC150C Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 43.44 28.60 12.71 42.07 27.97 13.58 40.60 27.30 14.59 39.03 26.59 15.75 35.12 24.27 17.04 32.63 22.96 18.76 24°C 43.61 34.06 12.72 42.23 33.36...
  • Page 107 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200B2 – AMC100B x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 57.91 39.21 15.78 56.07 38.34 16.87 54.12 37.43 18.13 52.03 36.46 19.56 46.82 33.28 21.16 43.49 31.48 23.30 24°C 58.13 46.70 15.80...
  • Page 108 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200B2 – AMC100C x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 57.93 39.22 16.60 56.09 38.35 17.74 54.14 37.44 19.06 52.05 36.46 20.57 46.84 33.29 22.26 43.51 31.49 24.51 24°C 58.15 46.72 16.62...
  • Page 109 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB250B2 – AMC125B x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 72.40 50.39 20.13 70.11 49.28 21.51 67.67 48.10 23.12 65.06 46.85 24.94 58.54 42.77 26.99 54.38 40.46 29.72 24°C 72.69 60.02 20.15...
  • Page 110 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B2 – AMC150C x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 57.20 26.82 84.13 55.94 28.66 81.20 54.61 30.80 78.06 53.18 33.24 70.25 48.55 35.96 65.26 45.93 39.60 24°C 87.22 68.14 26.85...
  • Page 111 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B3 – AMC100B x 3 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 58.82 24.18 84.13 57.52 25.85 81.20 56.15 27.77 78.06 54.69 29.97 70.25 49.93 32.43 65.26 47.23 35.71 24°C 87.22 70.06 24.21...
  • Page 112 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B3 – AMC100C x 3 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 58.84 25.41 84.13 57.54 27.15 81.20 56.17 29.18 78.06 54.70 31.49 70.25 49.94 34.07 65.26 47.24 37.51 24°C 87.22 70.08 25.43...
  • Page 113 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB350B3 – AMC100B + AMC125B x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 101.37 70.53 28.73 98.16 68.97 30.70 94.74 67.33 32.99 91.08 65.57 35.60 81.96 59.87 38.52 76.14 56.63 42.41 24°C 101.76...
  • Page 114 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400B4 – AMC100B x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 115.81 78.42 31.20 112.15 76.69 33.34 108.25 74.86 35.83 104.06 72.91 38.66 93.64 66.56 41.83 86.99 62.97 46.06 24°C 116.27 93.41 31.23...
  • Page 115 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400B4 – AMC100C x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 115.84 78.45 32.83 112.18 76.72 35.08 108.27 74.89 37.70 104.09 72.94 40.68 93.67 66.59 44.02 87.01 62.99 48.47 24°C 116.30 93.44 32.86...
  • Page 116 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB450B3 – AMC150C x 3 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 130.33 85.80 39.41 126.21 83.91 42.12 121.81 81.91 45.26 117.10 79.77 48.84 105.38 72.83 52.85 97.89 68.89 58.19 24°C 130.84 102.20 39.45...
  • Page 117 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB500B4 – AMC125B x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 144.81 100.78 40.58 140.22 98.56 43.37 135.35 96.21 46.60 130.11 93.70 50.29 117.09 85.54 54.41 108.76 80.92 59.91 24°C 145.37 120.04 40.62...
  • Page 118 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB600B4 – AMC150C x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 173.77 114.40 53.01 168.27 111.88 56.66 162.42 109.21 60.88 156.14 106.37 65.70 140.50 97.11 71.08 130.52 91.86 78.27 24°C 174.45 136.27 53.07...
  • Page 119 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB750B4 – AMC150C x 5 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 217.21 143.00 67.45 210.34 139.84 72.08 203.02 136.51 77.46 195.17 132.95 83.58 175.63 121.38 90.44 163.15 114.82 99.58 24°C 218.06 170.33 67.51...
  • Page 120 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB80B – AMC72C (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 19.94 14.89 4.87 19.23 14.50 5.26 18.52 14.11 5.70 17.77 13.71 6.18 16.32 12.75 6.70 15.07 12.00 7.39 24°C 19.96 17.83 4.87 19.25...
  • Page 121 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB80B – AMC80C (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 22.11 15.63 6.08 21.32 15.22 6.57 20.53 14.81 7.12 19.71 14.39 7.72 18.10 13.39 8.37 16.71 12.60 9.23 24°C 22.14 18.72 6.08 21.35...
  • Page 122 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB100B – AMC100B (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 27.65 20.87 7.95 26.67 20.33 8.60 25.68 19.78 9.31 24.65 19.21 10.09 22.63 17.88 10.95 20.89 16.82 12.07 24°C 27.68 24.99 7.95 26.70...
  • Page 123 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB125B – AMC125B (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 36.21 28.26 9.30 35.06 27.64 9.93 33.84 26.98 10.68 32.53 26.28 11.52 29.28 23.99 12.46 27.19 22.69 13.72 24°C 36.35 33.66 9.30 35.20...
  • Page 124 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB150B1 – AMC150C (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 43.44 31.46 12.36 42.07 30.77 13.21 40.60 30.03 14.20 39.03 29.25 15.32 35.12 26.70 16.58 32.63 25.26 18.25 24°C 43.61 37.47 12.38 42.23...
  • Page 125 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200B2 – AMC100B x 2 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 57.93 43.58 15.88 56.09 42.62 16.98 54.14 41.60 18.24 52.05 40.52 19.69 46.84 36.99 21.30 43.51 34.99 23.45 24°C 58.15 51.91...
  • Page 126 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB250B2 – AMC125B x 2 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 72.40 56.51 19.16 70.11 55.27 20.48 67.67 53.95 22.01 65.06 52.54 23.75 58.54 47.97 25.70 54.38 45.38 28.29 24°C 72.69 67.32...
  • Page 127 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B2 – AMC150C x 2 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 62.92 25.69 84.13 61.53 27.46 81.20 60.06 29.50 78.06 58.50 31.84 70.25 53.40 34.45 65.26 50.52 37.93 24°C 87.22 74.94...
  • Page 128 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B3 – AMC100B x 3 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 86.88 65.37 24.34 84.13 63.93 26.01 81.20 62.40 27.95 78.06 60.78 30.17 70.25 55.49 32.64 65.26 52.49 35.94 24°C 87.22 77.87...
  • Page 129 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB350B3 – AMC100B + AMC125B x 2 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 101.37 78.18 27.82 98.16 76.45 29.73 94.74 74.63 31.95 91.08 72.69 34.47 81.96 66.36 37.30 76.14 62.77 41.07 24°C...
  • Page 130 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400B4 – AMC100B x 4 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 115.84 87.16 31.41 112.18 85.24 33.57 108.27 83.21 36.07 104.09 81.04 38.92 93.67 73.99 42.12 87.01 69.99 46.37 24°C 116.30 103.83...
  • Page 131 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB450B3 – AMC150C x 3 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 130.33 94.38 37.72 126.21 92.30 40.31 121.81 90.09 43.32 117.10 87.75 46.74 105.38 80.11 50.57 97.89 75.78 55.68 24°C 130.84 112.42...
  • Page 132 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB500B4 – AMC125B x 4 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 144.81 113.04 38.66 140.22 110.55 41.31 135.35 107.91 44.40 130.11 105.10 47.91 117.09 95.95 51.84 108.76 90.76 57.07 24°C 145.37 134.64...
  • Page 133 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB600B4 – AMC150C x 4 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 173.77 125.84 50.75 168.27 123.06 54.24 162.42 120.12 58.29 156.14 117.00 62.90 140.50 106.81 68.06 130.52 101.04 74.93 24°C 174.45 149.89...
  • Page 134 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB750B5 – AMC150C x 5 (PFC) Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 217.21 157.30 64.62 210.34 153.83 69.06 203.02 150.16 74.22 195.17 146.25 80.08 175.63 133.52 86.65 163.15 126.31 95.41 24°C 218.06 187.37...
  • Page 135 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB75D – A4MC75D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 20.22 14.34 5.81 19.50 13.96 6.28 18.78 13.59 6.80 18.03 13.20 7.38 16.55 12.28 8.00 15.28 11.55 8.82 24°C 20.25 17.17 5.81 19.53 16.77...
  • Page 136 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB100D – A4MC100D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 25.20 18.35 8.77 24.31 17.87 9.48 23.40 17.39 10.27 22.47 16.89 11.13 20.63 15.72 12.08 19.05 14.78 13.32 24°C 25.23 21.97 8.77 24.34 21.47...
  • Page 137 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB125D – A4MC125D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 31.27 22.35 9.49 30.28 21.86 10.14 29.22 21.34 10.90 28.09 20.78 11.76 25.28 18.97 12.73 23.48 17.95 14.01 24°C 31.39 26.62 9.50 30.40 26.07...
  • Page 138 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB150D1 – A4MC150D Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 42.00 28.05 12.74 40.67 27.43 13.61 39.25 26.78 14.63 37.74 26.08 15.79 33.96 23.81 17.08 31.54 22.52 18.81 24°C 42.16 33.41 12.75 40.83 32.71...
  • Page 139 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB150D2 – A4MC75D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 42.28 30.62 12.19 40.95 29.95 13.03 39.52 29.23 14.00 37.99 28.47 15.11 34.19 25.99 16.35 31.76 24.59 18.00 24°C 42.45 36.48 12.20...
  • Page 140 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200D2 – A4MC100D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 52.71 36.68 17.55 51.04 35.87 18.76 49.27 35.02 20.15 47.36 34.11 21.75 42.62 31.14 23.53 39.59 29.45 25.91 24°C 52.92 43.69 17.57...
  • Page 141 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300D2 – A4MC150D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 83.99 56.08 26.67 81.33 54.84 28.50 78.50 53.53 30.63 75.46 52.14 33.05 67.91 47.60 35.76 63.08 45.03 39.37 24°C 84.31 66.80 26.70...
  • Page 142 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400D4 – A4MC100D x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 105.42 73.36 35.33 102.08 71.75 37.76 98.53 70.03 40.58 94.72 68.21 43.79 85.24 62.27 47.38 79.18 58.91 52.17 24°C 105.83 87.39 35.37...
  • Page 143 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB500D4 – A4MC125D x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 125.11 87.07 42.22 121.15 85.15 45.12 116.94 83.12 48.49 112.42 80.96 52.32 101.16 73.91 56.61 93.97 69.91 62.33 24°C 125.60 103.71 42.26...
  • Page 144 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200B2 – A4MC100D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 52.71 38.17 17.65 51.04 37.33 18.86 49.27 36.44 20.27 47.36 35.49 21.87 42.62 32.40 23.67 39.59 30.65 26.06 24°C 52.92 45.46 17.67...
  • Page 145 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB250B2 – A4MC125D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 62.53 47.04 19.87 60.55 46.01 21.24 58.45 44.91 22.82 56.19 43.74 24.62 50.56 39.93 26.64 46.97 37.77 29.34 24°C 62.78 56.04 19.89...
  • Page 146 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B2 – A4MC150D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 84.00 60.04 26.71 81.34 58.71 28.55 78.51 57.31 30.68 75.47 55.82 33.10 67.92 50.96 35.82 63.09 48.21 39.43 24°C 84.32 71.51 26.74...
  • Page 147 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB300B3 – A4MC100D x 3 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 79.06 57.26 26.99 76.56 56.00 28.85 73.90 54.66 31.00 71.04 53.24 33.45 63.93 48.60 36.19 59.38 45.98 39.85 24°C 79.37 68.20 27.02...
  • Page 148 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB350B3 – A4MC100D + A4MC125D x 2 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 88.89 66.90 29.40 86.07 65.42 31.43 83.08 63.86 33.77 79.87 62.20 36.44 71.87 56.78 39.43 66.76 53.71 43.41 24°C 89.23...
  • Page 149 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400B4 – A4MC100D x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 105.42 76.34 34.94 102.08 74.65 37.34 98.53 72.87 40.13 94.72 70.98 43.30 85.24 64.80 46.85 79.18 61.30 51.58 24°C 105.83 90.93 34.97...
  • Page 150 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB450B4 – A4MC150D x 3 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 125.99 90.06 39.24 122.01 88.07 41.93 117.76 85.97 45.06 113.21 83.73 48.63 101.87 76.44 52.61 94.63 72.31 57.93 24°C 126.48 107.27 39.28...
  • Page 151 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB500B4 – A4MC125D x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 125.06 94.10 40.07 121.11 92.02 42.82 116.89 89.83 46.02 112.37 87.49 49.66 101.12 79.87 53.73 93.93 75.56 59.16 24°C 125.55 112.08 40.11...
  • Page 152 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB600B4 – A4MC150D x 4 Cooling Mode Outdoor temperature 19°C 25°C 30°C 35°C 40°C 46°C (CFM) 21°C 167.99 120.07 52.79 162.67 117.43 56.41 157.01 114.62 60.62 150.94 111.64 65.41 135.83 101.92 70.78 126.18 96.41 77.93 24°C 168.65 143.02 52.84...
  • Page 153 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Outline & Dimension Indoor Unit Model: ADB40/50B Dimension Model 40/50B Dimension Model 40/50B Dimension Model 40/50B...
  • Page 154 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB60/80/100B Dimension Model 60/80/100B 1402 1232 1462 1502 Dimension Model 60/80/100B Dimension Model 60/80/100B...
  • Page 155 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB125B/150B1/200B2 Dimension Model 125/150B 1370 1540 1600 1640 200B 1624 1794 1854 1894 Dimension Model 125/150B 200B Dimension Model 125/150B 200b...
  • Page 156 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Dimension Model 125/150B 1370 1540 1600 1640 200B 1624 1794 1854 1894 Dimension Model 125/150B 1040 200B 1040 Dimension Model 125/150B 200B...
  • Page 157 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB250B2/300B2/300B3 Dimension Model 250/300B 1766 1636 1826 1866 Dimension Model 250/300B 1291 Dimension Model 250/300B 1199 1069 1196 1073 Dimension Model 250/300B...
  • Page 158 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Dimension Model 250/300B 1766 1636 1826 1866 Dimension Model 250/300B 1231 Dimension Model 250/300B 1259 1069 1196 1073 Dimension Model 250/300B...
  • Page 159 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB350B3/400B4/450B3/500B4 Dimension Model 350B 2022 1852 2082 2122 1199 1069 400/450/500B 2174 2004 2234 2274 1466 1336 Dimension Model 350B 1240 400/450/500B 1240 Dimension Model 350B 1546 1451 1326 400/450/500B 1546 1451 1326 Dimension Model 350B 400/450/500B...
  • Page 160 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Dimension Model 350B 2082 1852 2022 2122 1259 1069 400/450/500B 2234 2004 2174 2274 1526 1336 Dimension Model 350B 1240 400/450/500B 1240 Dimension Model 350B 1486 1451 1326 400/450/500B 1486 1451 1326 Dimension Model 350B 400/450/500B...
  • Page 161 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB600B4/750B5 Dimension Model 600B 1883 1978 1758 2234 2004 1680 750B 2162 2257 2037 2234 2004 1680 Dimension Model 600B 2174 1905 1775 750B 2174 1905 1775 Dimension Model 600B 750B...
  • Page 162 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Dimension Model 600B 1918 1758 2234 2004 1680 750B 2197 2037 2234 2004 1680 Dimension Model 600B 2174 1905 1775 750B 2174 1905 1775 Dimension Model 600B 750B Note: ADB200-500B models are available in Vertical Air Discharge as Standard. Convertible at field.
  • Page 163 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB75/100D Dimension Model 1120 1264 1370 100D 1349 1493 1599 Dimension Model 100D Dimension Model 100D...
  • Page 164 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB125D/150D1/150D2 Dimension Model 125D 1526 1754 1654 1794 150D 1805 2033 1933 2073 Dimension Model 125D 1009 150D 1009 Dimension Model 125D 150D...
  • Page 165 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB200/300D2 Dimension Model 200D2 1064 1209 1167 1089 1260 1113 300D2 1226 1501 1461 1381 1129 1552 1405 Dimension Model 200D2 1324 300D2 1214 1486...
  • Page 166 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: ADB400/500D4 Dimension Model 400D4 1691 1651 1571 1742 1596 1405 500D4 2047 2007 1927 2098 1952 1172 1760...
  • Page 167 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Outdoor Unit Model: ALC35/40/50/61D Dimension Model 35/40/50/61D 1030 Dimension Model 35/40/50/61D...
  • Page 168 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: AMC72/80C Dimension Model 72/80C 1300...
  • Page 169 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: AMC100C Dimension Model 100C 1033 1393...
  • Page 170 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: AMC100/125B Dimension Model 100/125B 1116 Dimension Model 100/125B 1116...
  • Page 171 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: AMC150C Dimension Model 150C 1116 1041 Dimension Model 150C...
  • Page 172 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Model: A4MC75/100/125/150D Dimension Model 75/100D 1041 125D 1083 1041 150D 1083 1047 1142...

  • Page 173: Wiring Diagram

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Wiring Diagram Indoor Unit Outdoor Unit Model: ADB40B Model: ALC40D...
  • Page 174 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB50B Model: ALC50D...
  • Page 175 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB60B Model: ALC61D...
  • Page 176 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB80B Model: ALC72/80C...
  • Page 177 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB100B Model: AMC100B/100C...
  • Page 178 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB125B Model: AMC125B...
  • Page 179 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB150C Model: AMC150C...
  • Page 180 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB200B2 Model: AMC100B x 2 ABD250B2 AMC125B x 2 ABD300B2 AMC150C x 2 ABD300B3 AMC100B/100C x 3 ABD350B3 AMC100B + AMC125B x 2 ABD400B4 AMC100B/100C x 4 ABD450B3 AMC150C x 3 ABD500B4 AMC125B x 4 ABD600B4 AMC150C x 4...
  • Page 181 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB75D Model: A4MC75D...
  • Page 182 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB100D Model: A4MC100D...
  • Page 183 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB125D Model: A4MC125D ABD150D A4MC150D...
  • Page 184 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB150D2 Model: A4MC75D x 2 ABD200D2 A4MC100D x 2 ABD300D2 A4MC150D x 2 ABD400D4 A4MC100D x 4 ABD500D4 A4MC125D x 4...
  • Page 185 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Indoor Unit Outdoor Unit Model: ADB200B2 Model: A4MC100D x 2 ABD250B2 A4MC125D x 2 ABD300B2 A4MC150D x 2 ABD300B3 A4MC100D x 3 ABD350B3 A4MC100D + A4MC125D x 2 ABD400B4 A4MC100D x 4 ABD450B3 A4MC150D x 3 ABD500B4 A4MC125D x 4 ABD600B4 A4MC150D x 4...

  • Page 186: Troubleshooting

    TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Troubleshooting Error Code / Fault Condition When a malfunction of the air conditioner unit is detected, immediately switch off the main power supply before proceeding with the following troubleshooting procedures. The following are common fault conditions and simple troubleshooting tips. If any other fault conditions which are not listed occur, contact your nearest local dealer.
  • Page 187 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Error Code (SLM3) Seven Segment Display Error E1 Blinking Room air sensor contact loose / short E2 Blinking Indoor coil sensor contact open E3 Blinking Outdoor coil sensor contact open Compressor overload protection / E4 Blinking Indoor coil sensor short / Outdoor coil sensor short E5 Blinking Gas leak...
  • Page 188 TECHNICAL SPECIFICATION TS-SB-B/D-AM-A1 Phase Sequencer The unit with Scroll Compressor can only rotate in one direction. For this reason, a protective device (phase protector) is fitted to prevent incorrect wiring of the electrical phases. When the three phases are not connected correctly, the phase sequencer operates, and the unit will not start.
  • Page 189 Sarawak : +6082-344 128 Products manufactured in an ISO certified facility. Johor : +607-3551 599 Sabah : +6088-420 205 This document contains the most current product information as of this printing. For the most up-to-date product information, please logon to www.acson.com.my www.acson.com.my TM-A(4)DB...

This manual is also suitable for:

Alc seriesAmc seriesA4mc series

Table of Contents

Save PDF
