MEITRACK® GPS Vehicle Tracker
Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.
File Name:
MEITRACK T1 User Guide
Project:
T1
Sub Project:
User Guide
Revision:
V1.7
User Guide V1.7
Creator:
Creation Date:
Update Date:
Page:
Confidential:
T1
Cavana Cheung
2011-07-18
2012-10-27
- 1 - of 22
External Documentation
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1 and is the answer not in the manual?

Questions and answers

Related Manuals for MeiTrack T1

Summary of Contents for MeiTrack T1

  • Page 1 File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 1 - of 22 Revision: V1.7 Confidential: External Documentation MEITRACK® GPS Vehicle Tracker User Guide V1.7 Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved.

  • Page 2: Table Of Contents

    Install RFID Reader (RS232 Interface) ................... - 20 - Install Camera (RS232 Interface) ....................- 21 - Install GPS/GSM Antennas ......................- 21 - Mount the T1 unit ........................- 22 - Copyright © 2012 Shenzhen Meiligao Electronics Co., Ltd. All rights reserved. - 2 -...

  • Page 3: Copyright And Disclaimer

    Meiligao (MEITRACK), or transmitted in any form, either electronically or mechanically, including photocopying and recording. In no event shall Meiligao (MEITRACK) be liable for direct, indirect, special, incidental, or consequential damages (including but not limited to economic loss, personal injury, and loss of asset and property) arising out of the use or inability or illegality to use the product or documentation.

  • Page 4: Specifications

    File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 4 - of 22 Revision: V1.7 Confidential: External Documentation Low Battery Alarm  Speeding Alarm  Tow Alarm ...

  • Page 5: T1 And Accessories

    Make sure the SIM Lock code is turned off; If you require the function of sending an SMS location report to the authorized phone number when it makes a call to the T1, please make sure the SIM installed supports displaying caller ID.

  • Page 6: Charging

    8 hours is highly appreciated. Configuration and testing suggested be prior to installation. 6.3 LED Indications Press and hold the Power On/Off button for 3~5 seconds to turn on/off T1. GPS LED (Blue) One button is pressed or input is active.
  • Page 7 File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 7 - of 22 Revision: V1.7 Confidential: External Documentation Click on the link then the location can be shown directly on Google Maps on your mobile phone.

  • Page 8: Multiple Phone Numbers- A71

    If no preset phone number, it is empty (default is empty). Send command “0000, A71” to delete all phone numbers. When the SOS button is pressed, T1 will make a call to phone number 1, 2 and 3. It will stop calling when one number answers.

  • Page 9: Sleep Mode - A73

    File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 9 - of 22 Revision: V1.7 Confidential: External Documentation Authorize a phone number to make a silent call to the tracker. The tracker will answer the call automatically and allows the caller to listen to what is happening around the tracker.

  • Page 10: Time Zone- B35

    This part mainly shows you how to use the MEITRACK Parameter Editor. Note: Don’t connect T1 to external battery when configuring. Please refer to the MEITRACK Parameter Editor User Guide for more information regarding configuration and functions. Run ‘PL2303_Prolific_DriverInstaller’ to install the driver for the USB data cable.
  • Page 11 ‘Prolific USB-to-Serial Comm Port’ as the following picture shows. Note: Remember this Com number. It needs to be input into the MEITRACK Parameter Editor. It is COM3 in this example and it would be COM4 or COM5… in your computer.

  • Page 12: Sms Tracking

    Click ‘Read Settings’ button to show the default or previous settings of the tracker. Note: MEITRACK Parameter Editor is in the CD. The language will be automatically adjusted to be the same as your PC operation system’s language. Please use “Ctrl+L” to change the language.
  • Page 13 Event Selected event’s SMS reports will be sent to the authorized phone number. For more details, please refer to MEITRACK GPRS/SMS Protocol. For description of events from SOS/Input 1 Active to Tow Alarm, please refer to tap II GPRS Tracking.

  • Page 14: Gprs Tracking

    External Power Off Alarm when external power supply if off or cut. No GPS Signal Report when T1 enters GPS blind area or no GPS signal. Get GPS Signal Report when T1 exits GPS blind area or get GPS signal.
  • Page 15 Interval = 0, stop tracking by time interval. Max time interval = 65535*10 seconds GPRS Report Times = 0, report without limit. = [1,65535], set report times, T1 will stop reporting when reaching the times. IP & Port Input server’s IP address and port number.
  • Page 16 External Power Off Alarm when external power supply if off or cut. No GPS Signal Report when T1 enters GPS blind area or no GPS signal. Get GPS Signal Report when T1 exits GPS blind area or get GPS signal.

  • Page 17: Installation

    File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 17 - of 22 Revision: V1.7 Confidential: External Documentation 7 Installation 7.1 Install I/O Cable The I/O cable is a 12-pin cable including power, analog input, negative/positive input and output.

  • Page 18: Power/Gnd (Pin1/Pin2)

    File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 18 - of 22 Revision: V1.7 Confidential: External Documentation Output low voltage sink current (effective): 400mA max. 7.1.1 Power/GND (PIN1/PIN2) Connect GND (-Black) and Power (+Red) wires to the battery of vehicle.

  • Page 19: Output (Pin10/Pin11/Pin12)

    File Name: MEITRACK T1 User Guide Creator: Cavana Cheung Project: Creation Date: 2011-07-18 Update Date: 2012-10-27 Sub Project: User Guide Page: - 19 - of 22 Revision: V1.7 Confidential: External Documentation 7.1.4 Output (PIN10/PIN11/PIN12) 7.1.5 Analog Input (PIN8/PIN9) 7.1.5.1 Analog Input Application 1– Detect External Power Voltage Input range：0-6V...

  • Page 20: Install Handset Phone (Rs232 Interface)

    7.2 Install Handset Phone (RS232 Interface) PIN Number Color Description Power Output. Output Voltage: 5V Black Ground Orange Handset Phone RS232 TX (T1 RX) Yellow Handset Phone RS232 RX (T1 TX) Blue Microphone Positive Green Microphone Negative Purple Speaker Positive...

  • Page 21: Install Camera (Rs232 Interface)

    RX, Camera RS232 TX (T1 RX) White TX, Camera RS232 RX, T1 TX Note: when connecting T1 with camera, the below connecting wire is needed. The 8PIN interface connects to T1, and the 4PIN interface to camera. 4PIN to camera 8PIN to T1 The interface can only be connected to one of the camera, handset and RFID reader.

  • Page 22: Mount The T1 Unit

    Confidential: External Documentation 7.6 Mount the T1 unit If mounting required, there are 4 screw holes on the T1, 2 along either side that act as fixing points to the vehicle Please do not hesitate to email us at info@meitrack.com if you have any questions.
