- Page 1 Adam Equipment Grain Scale Model: CQT1751GR pn. 9757 rev B © Adam Equipment Company 2009...
- Page 2 © Adam Equipment Company 2009...
-
Page 3: Table Of Contents
STORING WHEN NOT IN USE BASIC OPERATION TURNING ON THE SCALE ZEROING / TARE WEIGHING WEIGHING UNITS GRAIN DETERMINING PARAMETERS PARAMETER SETTING AUTO POWER OFF SETTING THE BACKLIGHT CALIBRATION TROUBLE SHOOTING ERROR MESSAGES REPLACEMENT PARTS AND ACCESSORIES SPECIFICATIONS WARRANTY STATEMENT ©Adam Equipment Company 2009... - Page 4 ©Adam Equipment Company 2009...
-
Page 5: 2.0 Introduction
Thank you for purchasing your new grain scale which is based upon the Core series of Balances. The CQT1751GR model has been specifically developed and designed to be used to assist in the grading of grain to asses the quality of the grain as well as to give an indication of the Kilograms per hectolitre (kg/Hl). -
Page 6: Installing Batteries
Turns the balance power on/off [S/P CE] key Stores weight readings and does percentage calculation as well as clearing stored values. [Recall / Tare] key Recalls stored weighings / results and also to zeros and tares the balance ©Adam Equipment Company 2009... - Page 7 BOTTOM Battery compartment screws Battery compartment cover Batteries are not included DISPLAY ZERO indicator Indicates when the scale is at zero. STABLE indicator Indicates when the reading is stable. ©Adam Equipment Company 2009...
-
Page 8: Locating And Protecting Your Scale
Keep the scale clean, and do not stack material on the scale when it is not in use. The CQT1751GR has a stacking feature allowing more than one unit to be stacked on top of each other. For more details on this see the section on storing. -
Page 9: Storing When Not In Use
If you have any of the Highland series or Core or Grain Scale product lines you can store them easily on top of each other. To save space and protect them from damage. Without Shield With Shield ©Adam Equipment Company 2009... -
Page 10: Basic Operation
The display will show the weight and the unit of weight currently in use. The stable indicator will light up when the reading is stable. WEIGHING UNITS Two units are available: grams (g) and Kilograms per Hectolitre (Kg/Hl). ©Adam Equipment Company 2009... -
Page 11: Grain Determining
The balance will show Store 1 for 2 seconds and then “xx.x Kg / Hl”. In this example it will show 80.00 Kg / Hl. ► Store 80.00 ► Kg/Hl The Store symbol (►) lights up when the first net weight is stored and the Kg/Hl symbol (►) also lights up. ©Adam Equipment Company 2009... - Page 12 “ XX.X PER”. In the example the 1 weight was 400g ( calculated as 80.00Kg/Hl), the 2 weight was 30g (calculated as 6.00Kg/Hl). Therefore the percentage value would be 7.50%. Store ► 7.50 Kg/Hl ► ©Adam Equipment Company 2009...
- Page 13 11) If the balance is turned off during the weighing process when it is turned on again it will have kept the stored information in the memory so that you could then complete the tests without having to start again due to a loss of power. ©Adam Equipment Company 2009...
-
Page 14: Parameters
80 seconds before the power will switch off 90 PWR 90 seconds before the power will switch off 5) Press the [S/P/CE]key to confirm the setting 6) To exit turn the scale off and back on again ©Adam Equipment Company 2009... -
Page 15: Setting The Backlight
4) Press [Recall/Tare] to select the settings as follows 1 BL - 2 BL – OFF BL 5) Press the [S/P/CE]key to confirm the setting 6) To exit turn the balance off and back on again ©Adam Equipment Company 2009... -
Page 16: Calibration
8) If the weight is within 5% of the last calibration the display will show PASS and exist the calibration routine. If the calibration is not successful the display will show FAIL and exit the routine, if the calibration fails try again. ©Adam Equipment Company 2009... -
Page 17: Trouble Shooting
TROUBLE SHOOTING ERROR MESSAGES If an error message is shown, repeat the step that caused the message. If the error message is still shown then contact your Adam Equipment dealer for support. ERROR DESCRIPTION POSSIBLE CAUSES Solutions CODE A/D Value too high. -
Page 18: Replacement Parts And Accessories
AC adapter SA plug 12VAC 150mA 5099 AC adapter Australian plug 12VAC 150mA 9502 120 mm Stainless steel pan 9511 Draft shield lid 9510 Draft shield (without lid) 9306 In-use wet cover 8030 Security lock and cable ©Adam Equipment Company 2009... - Page 19 ©Adam Equipment Company 2009...
-
Page 20: Specifications
(5.2” ø x 3.2”) Balance ABS Plastic Housing Pan Size 120mm ø (5.1” ø) Overall 173 x 255 x 86mm (6.8” x 10” x 3.3”) Dimensions Without draft shield (w x d x h) Net Weight 820g (1.8lb) ©Adam Equipment Company 2009... -
Page 21: Warranty Statement
The warranty will cease to operate if the equipment is not returned in the original packaging and with correct documentation for a claim to be processed. All claims are at the sole discretion of Adam Equipment. This warranty does not cover equipment where defects or poor performance is due to misuse, accidental... - Page 22 ©Adam Equipment Company 2009...
- Page 23 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 24 ADAM EQUIPMENT is an ISO 9001:2000 certified global company with more than 35 years experience in the production and sale of electronic weighing equipment. For a complete listing of all Adam balances and balances visit our website at: www.adamequipment.com © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment.
