- Page 1 Adam Equipment CBC SERIES (P.N. 8680, Revision C4, February 2009) Software rev.: 3.06 & above © Adam Equipment Company 2009...
- Page 2 © Adam Equipment Company 2009...
-
Page 3: Table Of Contents
REAL TIME CLOCK SETUP................19 AUTO SLEEP FUNCTION.................. 20 10.0 BATTERY AND BACKLIGHT OPERATION............21 10.1 BATTERY ......................21 10.2 BACKLIGHT FOR LCD..................21 11.0 ERROR CODES..................... 22 12.0 REPLACEMENT PARTS AND ACCESSORIES ............ 23 13.0 SERVICE INFORMATION..................23 © Adam Equipment Company 2009... - Page 4 © Adam Equipment Company 2009...
-
Page 5: Introduction
• The CBC series provides accurate, fast and versatile counting scales. • There are 2 type of scales within the CBC series- CBC scales are gram/ kilogram only scales and the CBCa scales are changeable from pounds to kilograms. The scales have the same functions except that CBCa scales have the ability to toggle between the two weighing units. -
Page 6: Specifications
Model: CBC 100a UNITS OF MAXIMUM TARE READABILITY REPEATIBILITY LINEARITY MEASURE CAPACITY RANGE Kilograms 48.000 kg -48 kg 0.002 kg 0.002 kg 0.004 kg Pounds 100 lb -99 lb 0.005 lb 0.005 lb 0.01 lb © Adam Equipment Company 2009... -
Page 7: Common Specifications
Parts counting, check-counting, weighing, accumulating memory, pre-set count with alarm Interface RS-232 bi-directional interface English, German, French, Spanish selectable text Date/Time Real Time Clock (RTC), To print date and time information (Dates in year/month/day, day/month/year or month/day/year formats- Battery backed) © Adam Equipment Company 2009... -
Page 8: Installation
• the scales when they are not in use. INSTALLATION OF CBC SCALES • The CBC Series come with a stainless steel platform packed separately. • Place the platform in the locating holes on the top cover. • Do not press with excessive force as this could damage the load cell inside. -
Page 9: Key Descriptions
This is the net weight. Entering a value using the keypad will store that as the tare value. [Zero] Sets the zero point for all subsequent weighing to show zero. © Adam Equipment Company 2009... -
Page 10: Displays
"U. Weight" or symbol as above. • In both cases the scale continues to operate and the indications are to alert the user for a potential problem. © Adam Equipment Company 2009... -
Page 11: Count Display
• Press [Tare] to tare the scale. The weight that was displayed is stored as the tare value which is subtracted from the display, leaving zero on the display. The indicator above “Net” will be ON. © Adam Equipment Company 2009... -
Page 12: Parts Counting
• As more items are added to the scale, the weight and the quantity will increase. • If a quantity which is smaller than the sample is placed on the scale, then the scale will automatically enhance the Unit Weight © Adam Equipment Company 2009... -
Page 13: Counting More Parts
A beep will be heard when the value is updated. It is wise to check the quantity is correct when the unit weight has been updated © Adam Equipment Company 2009... -
Page 14: Check-Counting
• To observe the total stored value, press the [MR] key. The total will be displayed for 2 seconds. • To clear the memory- first press [MR] to recall the totals from memory and then press the [CE] key to clear all values from the memory. © Adam Equipment Company 2009... -
Page 15: Automatic Accumulated Totals
• The first parameter is “F1” “CAL”. (See section 8.0 for details) • To enter into Calibration function, press the [Tare] key. • To exit a parameter, press the [Zero] key. • To select the second parameter press the [U. Wt./Units] key. © Adam Equipment Company 2009... -
Page 16: Calibration
• For entering Calibration, see section 7.0 Parameters • When “F1” “CAL” is displayed, press [Tare]. • The display will then show "unLoAd" to request all weight be removed from the platform. • Press the [Tare] key to set the zero point. © Adam Equipment Company 2009... -
Page 17: Rs-232 Interface
9.0 RS-232 INTERFACE The CBC Series are supplied with a RS-232 bi-directional interface. The scale when connected to a printer or computer through the RS-232 interface, outputs the weight, unit weight and count. - Page 18 2 line feeds, carriage return <lf><cr><lf><cr> Pressing the [MR] key will not send the totals to the RS-232 when the continuous print is turned on. The continuous print will only be for weight and display data that is current. © Adam Equipment Company 2009...
-
Page 19: Input Commands Format
Prints the results to a PC or printer using the RS-232 interface. It also adds the value to the accumulation memory if the accumulation function is not set to automatic. In CBC series, the [Print] key will either print the current items being counted or the results of the accumulation memory if [M+] is pressed first. -
Page 20: Rs-232 Setup
Print Auto automatically or printing Print mAn manually. Select the operation of AC Auto accumulating automatically, AC mAn manually or turned off. AC oFF Select Language for CoUntr nGLiSH EnGLiSH printing. FrEnCH GErMAn SPAniSH © Adam Equipment Company 2009... -
Page 21: Real Time Clock Setup
• Press the [CE] key to change the date and time. The display will show the current time format, “H-m-S”. • Enter the time using the numeric keys using a 24 hour clock format, 3:41PM is “154100”. © Adam Equipment Company 2009... -
Page 22: Auto Sleep Function
“0” Auto sleep mode disabled “1” Auto sleep after 1 minute “5” Auto sleep after 5 minutes “10” Auto sleep after 10 minutes • Press [Tare] to set the value. The scale returns to zero. © Adam Equipment Company 2009... -
Page 23: Battery And Backlight Operation
2. ON only when a weight is placed on the scale or 3. Turned off. • To set the backlight press and hold [Pst] key for 4 seconds. • The weight display will show “EL xx” where xx is the current setting for the backlight. © Adam Equipment Company 2009... -
Page 24: Error Codes
[Zero] key is pressed, Improper calibration of the scale. Damaged load cell. Damaged Electronics. Err 6 A/D count is not correct Platform is not installed. when turning the scale Damaged Load cell. Damaged Electronics. © Adam Equipment Company 2009... -
Page 25: Replacement Parts And Accessories
Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. © Adam Equipment Company 2009... -
Page 26: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 27 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 28 © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment. Adam Equipment reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
