Setup

This section contains information about setting up your instrument and preparing to play. Carefully read this section before
turning the power on.

Setup Guide

Before you begin assembling the instrument, check that all the parts
below were supplied.
You also need to have a Phillips screwdriver.
2
9
8
6
AW_CDP5200_Manual_G09_140718
2014 7 18 17:19:12
1
6
5
10 11
12 13
7
4
1. Piano body
2.
Left leg component
3. Right leg component
4.
Foot pedal assembly
5.
Foot pedal cable
6.
Left sound box
7.
Right sound box
8.
Turned nut (4PCS)
9.
Phillips head screws M6x50 (8PCS)
10.
Plastic screw cap (8PCS)
11.
Hand screws (4PCS)
12. Gasket (2PCS)
13.
Phillips head screws M4x15 (2PCS)
