21
20
When [SHIFT] button released
21. [STYLE] button
Enter style mode
22. [VOICE] button
Enter voice mode
23. [SONG] button
Enter song mode and play songs
27~34. Voice direct button
Shortcut to select a voice
37. [BANK] button
Adjust the memory bank
38. [STORE] button
Register the current panel settings
39~42. M1~M4 button
Recall the registered panel settings
43. [O.T.S] button
Turn one touch setting on or off
When [SHIFT] button pressed
38. [ACCOMP] button
Select the accomp track to record
39~43. MELODY 1-5 button
Select the melody1-5 track to record

Rear Panel

46 47
46. POWER ON / OFF
Turn the power on or off
47. PHONES 1 AND 2
Connect the headphone
48. USB Jack
Connect to a computer.
49. AUX. IN Jack
Connect an external sound
source, Such as an Mp3 or
CD player.
AW_CDP5200_Manual_G09_140718
2014 7 18 17:19:11
24
22 25
23 26
When [SHIFT] button pressed
21. [DEMO] button
Enter demo mode
22. [PERFORM] button
Enter the Performance Assistant
mode
23. [ALBUM] button
Enter album mode
27. [PIANO] button
Select the piano mode
28. [METRONOME] button
Turn the metronome on or off
29. [DUAL] button
Turn the Voice R2 on or off
30. [LOWER] button
Turn the Voice L on or off
31. [TOUCH] button
Choose a keyboard touch setting
32. [DSP] button
Turn the DSP effect on or off
33~34. [TRANSPOSE+/-] button
Adjust the transpose
37. [RECORD] button
Enter record mode
48
49
50. AUX. OUT Jack
Connect the audio equipment.
51. DC IN Jack
Connect the DC 15V power adaptor.
52. SPEAKER Jack
Connect the speaker.
53. PEDAL Jack
Connect to the pedals.
Panel & Display Description
27 28 29 30 31
37 38 39 40
20. LCD
Display the information of the piano
24. Data dial
Adjust the value
25~26. [YES/+]/[NO/-] button
Adjust the value
35. [TWINOVA] button
Turn the TWINOVA on or off
36. [OCTAVE] button
Set octave in TWINOVA mode
44. [HARMONY] button
Turn harmony effect on or off
45. [SCALE] button
Turn the scale effect on or off

Pedal

54. Soft Pedal
51 52 53
50
55. Sostenuto Pedal
56. Sustain Pedal(multi function pedal)
32 33 34 35 36
41 42 43 44 45
54 55 56
When you step on the soft pedal, all
notes played on the keyboard will
have a softer effect.
When you step on the sostenuto
pedal, the notes played before you
step on the pedal would have a
sustain effect.
When you step on the sustain pedal,
all notes played on the keyboard will
have a longer sustain
