Function Menu

Holding down [SHIFT] button, and then press [FUNCTION</>] button
to enter function menu. The LCD displays the current function menu
option. Use [+/YES]/ [-/NO] or data dial to set parameter of the current
menu.
The option and parameters are as follows:
No. LCD display
1 xxx Tune
2 xxx KeySplit
3 xxx BeatType
4 xxx MetroVol
5 00x Pedal xxxx
6 xxx ReverbVol
7 xxx ChorusVol
8 xxx xxxx
9 xxx HarmonySpeed
10 xxx Midi In
11 xxx Midi Out
12 xxx PowerOff
13 xxx Perform Beat
Note:
The function menu status will exit if no operation is done within 5 seconds.

Tune

This function sets the pitch of entire keyboard by steps of cents.
1.
Holding down [SHIFT] button, and then press [FUNCTION
button to select tune menu. LCD displays "xxx Tune".
Use [+/YES]/[-/NO] or data dial to change tune value. Its range is
from -50 to 50 cents.
2.
Press [+/YES] and [-/NO] simultaneously will set the tune value to
its default setting:000. The setting is applied to both accompaniment
and the voice.

KeySplit

This function sets the point which separates the entire keyboard to two
sections.
1.
Holding down [SHIFT] button, and then press [FUNCTION
button to select keysplit menu. LCD displays "xxx KeySplit". Use
[+/YES]/ [-/NO] or data dial to change keysplit value. The range of
keyspilit: 1~88.
2.
Press [+/YES] and [-/NO] simultaneously will set the keysplit value
to its default setting: F#3(34).
Note:
When twinova is opened, the range of keysplit is C3~C6 (28~64).
Press [+/YES] and [-/NO] simultaneously will set twinova keysplit value
to its default setting: E3(32).
24
AW_CDP5200_Manual_G09_140718
2014 7 18 17:19:16
Range Default
-50 ~ +50 000
1 ~ 88 034
0, 2 ~ 9 004
0~127 080
Sust,St/T, Mem Sust
0 ~ 127 Depend on voice
0 ~ 127 Depend on voice
Duet, StandardTrio, Full Duet
Chord, Rock Duet, Country
Duet, Country Trio, Block,
4 Close 1, 4 Close 2,
4 Open, 1+5, Octave,
Strum, Echo, Tremolo, Trill
1 ~ 4 1
1 ~ 16，ALL ALL
1 ~ 16 001
OFF, 30,60 030
4-4, 3-4, 2-4, 6-8 4-4
</> ]
</> ]
