Summary of Contents for Medeli SP40A
- Page 2 Using the Instruction Manual Thank you for purchasing this Digital Piano. The use of high technology and the most advanced sampling technique brings you high quality sound and enjoyment. The combination of digital piano and electronic keyboard features let you perform perfectly. We hope this digital piano will be able to explore your creativity, and brings you unlimited happiness and music enjoyment.
-
Page 3: Table Of Contents
Contents General Guide The Connectors - Using the Adaptor - Using Headphones - Using the AUX.OUT jack Using the AUX.IN jack - Using the Foot Pedals - Using the MIDI IN/OUT jack Operation 6-10 1. Power Switch & Volume 2. Voice/Dual Voice 3. -
Page 4: General Guide
General Guide 1.FRONT PANEL POWER SWITCH VOICE TYPE & DEMO SONG SELECT MASTER VOLUME 0 - PIANO 1 DUAL 1 - PIANO 2 2 - E.PIANO 1 TOUCH 3 - E.PIANO 2 RECORD 4 - HARPSICHORD TRACK A 5 - VIBES TRACK B 6 - STRINGS ENSEMBLE REPEAT... -
Page 5: The Connectors
The Connectors Using the Adaptor 1. connect the adaptor into the AC wall outlet and the cord into the DC power jack on the underside of the piano body. Adaptor DC 12V Plug the power cable into an AC power outlet. -
Page 6: Using The Aux.in Jack
The Connectors Using the AUX.IN jack The audio output from a CD player connected to the AUX IN jack on the left panel can be mixed with the sound of the piano brain. This function is convenient CD Player when you want to play along with a favourite song. -
Page 7: Operation
Operation 1. Power Switch & Volume 2. Use the volume control 1. Turn the POWER to switch switch to adjust the on the piano. volume to your desired The LED display lightens up. level Caution: If the LED display has not lightened up after you turned on the piano, please check the power supply. -
Page 8: Dsp (Digital Signal Processor)
Operation 4. DSP (Digital Signal Processor) There i s D SP r esponse f unction and it is a default setting. P r e s s t h e [ D S P ] b u t t o n t o adjust the DSP response level in the range of 1 to 3. -
Page 9: Touch Response
Operation 7. Touch Response There is touch response function and it is a default setting. Press the [TOUCH] button to adjust the touch response level in the range of 1 to 3. 2 is the default level. To turn off the touch response function, press the [TOUCH] button repeatedly until "OFF"... -
Page 10: Demo Song
Operation Repeat the playback During the playback, press the [REPEAT] button to set the point of beginning that you want to listen. "r-A" will appear on the display, then press the [REPEAT] button again to set the end point of the playback. "r-B" will appear on the display and the recorded song will playback repeatedly. - Page 11 Operation Repeat the demo song When a demo song is playing , press the [REPEAT] button to set the point of beginning that you want to listen. "r-A" will appear on the display, then press the [REPEAT] button again to set the end point of the playback.
-
Page 12: Midi
MIDI The MIDI IN and MIDI OUT terminals, which is located at the rear panel of the unit. The following shows the description of MIDI and the steps of using MIDI function. What is MIDI? MIDI stand for Musical Instrument Digital Interface. MIDI is a world wide standard that makes it possible for various electronic musical instruments and other devices, such as computers, to "communicate with each other". -
Page 13: Specifications
Specifications Keyboard 88 hammer action keys Voice 10 Voices Demo Song 20 Demo Songs Display Switch and Buttons POWER SWITCH, VOLUME SWITCH, DUAL, DSP, TOUCH, RECORD, TRACK A, TRACK B, REPEAT, METRONOME, TRANSPOSE +/-, TEMPO +/-, DEMO ALL, RECORD - PLAY/STOP, DEMO - SELECT/ START/STOP, VOICE SELECT 0-9 Transpose 12 semitones...
