Version 1.0
WWW.YAGANG.COM

USER MANUAL

MX-COLOR
LED110

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-COLOR and is the answer not in the manual?

Questions and answers

Summary of Contents for Silver Star MX-COLOR

  • Page 1: User Manual

    Version 1.0 WWW.YAGANG.COM USER MANUAL MX-COLOR LED110...
  • Page 2: Table Of Contents

    PART 1 PRODUCT (GENERAL)..............1 1.1--PRODUCT INTRODUCTION..................2 1.2--PRODUCT FEATURES....................2 1.3--TECHNICAL SPECIFICATIONS...................3 1.4--PHOTOMETRIC DATA....................4 1.5--SAFETY WARNING....................4 PART 2 INSTALLATION.................5 2.1--MOUNTING........................6 2.2-- SETTING UP (STAND ALONE)..................7 2.3--SETTING UP (MASTER/SLAVE)..................7 2.4--SETTING UP (DMX512 CONTROLLER)...............8 PART 3 DISPLAY PANEL OPERATION........... 9 3.1--BASIC........................10 3.2--MENU........................11 3.3--SETTING DMX512 ADDRESS...................12 3.4--RUN MODE......................12 3.5--EDIT PROGRAM......................13 3.6--SPECIAL OPTIONS....................14...
  • Page 3: Part 1 Product (General)

    Par t Par t PRODUCT INTRODUCTION PRODUCT FEATURES TECHNICAL SPECIFICATIONS PHOTOMETRIC DATA SAFETY WARNING PRODUCT (GENERAL)
  • Page 4: Product Introduction

    PRODUCT INTRODUCTION This product is designed for indoor use only. Suitable applications include wash or effect lighting for architectural, stage or nightclub applications. Direct input of DMX512 signal allows the fixtures to be controlled from any DMX512 controller. The fixture is fully programmable with one custom program available and is supplied with two automatic programs and two music-active programs (all accessible from DMX512 controller).
  • Page 5: Technical Specifications

    TECHNICAL SPECIFICATIONS Voltage 100~120V...50/60Hz 220~240V...50/60Hz50W Rated Power LED/Unit 18pcs (6 X RED / 6 X GREEN / 6 X BLUE) Output/LED LED Beam Angle 15 (30 Optional) Cooling Forced air convection Dimensions x 300 x 356mm Weight 8.9Kg 149.25 43.78 94.25 278.5 2006.11.15...
  • Page 6: Photometric Data

    PHOTOMETRIC DATA RGB 100% WHITE 1600 90 LUX 1500 80 LUX 10 Diameter(m) 10 Diameter(m) GREEN 40 LUX 25 LUX 10 Diameter(m) 10 Diameter(m) BLUE 30 LUX 10 Diameter(m) SAFETY WARNING IMPORTANT ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA.
  • Page 7: Part 2 Installation

    Par t Par t MOUNTING SETTING UP (STAND ALONE) SETTING UP (MASTER/SLAVE) SETTING UP (DMX512 CONTROLLER) INSTALLATION...
  • Page 8: Mounting

    MOUNTING The LED fixture can be operated in any position at any angle. When mounted on a flat surface, the surface must be strong enough to support 10 times the weight of the fixture and stable so that the will be no damage caused to the fixture or surrounding people or objects because of movements of the fixture on the surface.
  • Page 9: Setting Up (Stand Alone)

    SETTING UP (STAND ALONE) The LED fixture can be used as a stand alone unit. The stand alone functions AUTO 1, AUTO 2, SOUND 1, SOUND 2, CUSTOM 1 can be activated without the need to connect to any controller or connecting to any other equipment. Simply, access the <RUN>...
  • Page 10: Setting Up (Dmx512 Controller)

    SETTING UP (DMX512 CONTROLLER) When units are connected in series to a DMX512 controller and other DMX512 equipment, connect the equipment as shown in the diagram below. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the controller.
  • Page 11: Part 3 Display Panel Operation

    Par t Par t BASIC MENU SETTING DMX512 ADDRESS RUN MODE EDIT PROGRAM SPECIAL OPTIONS DISPLAY PANEL OPERATION...
  • Page 12: Basic

    BASIC The LED fixture is mounted with a LCD display and 4 control buttons. MODE DOWN ENTER Scroll through the main menu or exit from the current sub-menu Scroll 'UP' through the menu list or increase the value of the current function Scroll 'DOWN' through the menu list or decrease the value of the current function Enter the currently selected menu or confirm the current function value 2006.11.15...
  • Page 13: Menu

    MENU Welcome Auto 1 Auto 2 Sound 1 Sound 2 Custom Slave Edit Prg Edit Program Step 0 2 55 Titl 2 55 25 5 Green 0 Blue Strobe 0 2 55 Time Fade Reset Custom Confirm Reset Option Fan Speed High Invert Pan ON/OFF...
  • Page 14: Setting Dmx512 Address

    SETTING DMX512 ADDRESS Welcome Address 1 Address Enter the Address mode to set the DMX addre RUN MODE Welcome Auto 1 Auto 2 Sound 1 Sound 2 Custom Slave Enter the Run menu in order to select the operation mode of the fixture For stand alone operation, select from the modes AUTO 1 , AUTO 2 ,...
  • Page 15: Edit Program

    EDIT PROGRAM Welcome Edit Prg Edit Program Step 0 2 55 Titl 2 55 25 5 Green 0 Blue Strobe 0 2 55 Time Fade Reset Custom Confirm Reset Step Select from 100 steps to create or edit Steps that are not required should have the Time set as 0 Set the PAN position of the LED fixture (0-255) Tilt...
  • Page 16: Special Options

    SETTING DMX512 ADDRESS Welcome Option Fan Speed High Invert Pan ON/OFF Invert Tilt ON/OFF Reset Load Default Fan Speed Set the Fan Speed as high or low Note that when the fan speed is set to low that any overheating by the unit will automatically change the fan speed to high Invert Pan Select...
  • Page 17: Part 4 Operation With Dmx512

    Par t Par t BASIC ADDRESSING CHANNEL ASSIGNMENT FUNCTION EXPLANATION OPERATION WITH DMX512...
  • Page 18: Basic Addressing

    BASIC ADDRESSING It connect all of the units in series using standard DMX512 signal cable It set the DMX512 address in the 'Address' menu It is possible to have the same DMX address or independent addresses for each fixture. CHANNEL ASSIGNMENT CHANNEL FUNCTION TILT...
  • Page 19 Function Function 98.5 WHITE MAXIMUM INTENSITY 94.5 AUTO-MACRO 84.5 RED UP/GREEN DOWN /BLUE 100% RED 100%/GREEN UP/BLUE UP 72.5 RED 100%/GREEN 0%/BLUE DOWN 49.5 60.5 RED DOWN/GREEN 0%/BLUE 100% 37.5 RED 0%/GREEN DOWN/BLUE 100% MINIMUM RED 0%/GREEN 100%/BLUE UP INTENSITY 25.5 RED DOWN / GREEN 100%/BLUE 0% 13.5...
  • Page 20: Function Explanation

    FUNCTION EXPLANATION CH1 adjusts the PAN from 0 to 540 TILT CH2 adjusts the TILT from 0 to 540 PAN/TILT SPEED CH3 adjusts the speed of the PAN and TILT faders RED, GREEN & BLUE CH4, CH5 & CH6 control the intensity of each of the RED, GREEN & BLUE LEDs. When the slider is at the highest position (255) the intensity of the color is the maximum CH4, CH5 &...
