- Page 1 图纸编码 版本号 RD-SS847-SM-04（SS-I） SS847XAL 英文说明书（CCS3.0） 编辑日期 2020/11/27 制作 刘丽萍 审核 白丹 批准 余泽松 物料编码 1320109329 备注 以 A4 样本打印...
- Page 2 ECLIPSE 1000 RGBAL USER MANUAL ECLIPSE 1000 RGBAL SS847 MODEL: SS847XAL...
-
Page 3: Technical Specifications
1 PRODUCT 1.1 TECHNICAL SPECIFICATIONS Type SS847XAL LED colors R*20PCS,G*14PCS,B*14PCS,L*24PCS,A*18PCS Power 300W Voltage Range AC100~240V,50/60Hz Protection IP20 Operation 0℃~45℃ Temperature Dimensions 600X370X370mm Weight 8.3kg（without lens tube）... -
Page 4: Safety Notes
1.2 Safety Notes IMPORTANT ． ． ． ． ． ． ． ． ． This product must be installed by a qualified professional. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes The manufacturer will not accept liability for any resulting damages caused by the ... -
Page 5: Installation
2 INSTALLATION 2.1MOUNTING UPRIGHT ． ． ． ． ． ． ． For overhead use, always install a safety cable that can hold at least 10 times the weight of the fixture. For overhead installation, the fixture must be always secured with a safety wire that can bear ... -
Page 6: Data Network Requirements
2.3 Data network requirements Connect the DMX512 controller to the units in series. A DMX 512 data link is required in order to control the fixture via DMX. The fixture has 3/5-pin XLR connectors for DMX data input and output. Each unit has 13 DMX channels so the DMX Addresses should increase by increments of 1，... -
Page 7: Functions And Settings
3 FUNCTIONS AND SETTINGS 3.1 DISPLAY OPERATION MENU：Used to access the menu or to return a previous menu option; ENTER：Used to select and store the current menu or confirm the current function value or option within a menu; UP：Navigates downwards through the menu list and increases the numeric value when in a ... - Page 8 POWER Fast rotation of fan，all power STUDIO Automatic rotation of fan DISP KEY ON（default） Locks display (passcode <UP>, <DOWN>,<UP>, <DOWN>, <ENTER>) DISP TIME Display backlight always on Turns off display backlight after 10s/30s 30s（default） /2min of inactivity 2min INFO FIXTURE HOURS Hours of fixture use VERSION Software versions...
-
Page 9: Using A Dmx512 Controller
4 USING A DMX512 CONTROLLER 4.1 DMX CONTROL HSIC Value Function (7CH) CH.1 0-255 INTENSIYT CH.2 0-255 CH.3 0-255 HUE FINE CH.4 0-255 SATURATION NO FUNCTION 1800K 2200K 2700K 3000K 3200K 4000K CH.5 4500K 5000K 5600K 6000K 6500K 7000K 8000K 10000K 10000K STROBE... - Page 10 081-090 POWER 091-100 RESERVED 101-110 DIMMER OFF 111-120 DIMMER DIM4 121-130 RESERVED 131-140 RESERVED 141-150 RESERVED 151-160 1200Hz 161-170 2400Hz 171-180 4000Hz 181-190 6000Hz 191-200 25000Hz 201-210 ALL RESET 211-220 RESERVED 221-230 RESERVED 231-240 RESERVED 241-255 RESERVED COLOR MODE SIMPLE Value Function 8BIT...
- Page 11 4500K 5000K 5600K 6000K 6500K 7000K 8000K 10000K 10000K STROBE NO FUNCTION 10-99 STROBE FROM SLOD TO FAST (0-25Hz) CH.4 CH.7 CH.9 CH.15 100-109 NO FUNCTION 110-179 THUNDER STROBE 180-189 NO FUNCTION 190-255 RANDOM SROBE CONTROL（EXECUTE AFTER 3 SECONDS） 000-010 NO FUNCTION 011-020 RESERVED...
- Page 12 Annex 1 PRESET COLOR Value Color Names 0-10 NO FUNCTION COLOR 1 11-15 L176 Loving Amber 0.407 0.321 COLOR 2 16-20 Light Salmon 0.499 0.321 COLOR 3 21-25 Scarlet 0.561 0.296 COLOR 4 26-30 L164 Flame Red 0.659 0.302 COLOR 5 31-35 L747 Easy White...
