- Page 1 图纸编码 RD-SS358-SM-01(SS-I) 版本号 SS358XCE/XCET/XCEM 英文说明书 编辑日期 （CCS3.0） 2020/12/16 制作 刘丽萍 审核 白丹 批准 余泽松 物料编码 1320109359 备注 以 A4 样本制作...
- Page 2 CAM3/ETZ CAM3/EMZ USER MANUAL MODEL: SS358XCE/SS358XCEM/SS358XCET...
-
Page 3: Technical Specifications
1 PRODUCT 1.1 TECHNICAL SPECIFICATIONS Type SS358XCE/SS358XCEM/SS358XCET LED colors 14PCS RGBW LED Power Voltage Range AC100~240V,50/60Hz Protection IP20（SS358XCE）IP65（SS358XCEM）IP66（SS358XCET） Operation -0℃~45℃（SS358XCE） Temperature -20℃~45℃（SS358XCEM\SS342XCET） Dimensions 245X246X202mm Weight 4.8kg... -
Page 4: Safety Notes
1.2 Safety Notes IMPORTANT ． ． ． ． ． ． ． ． ． This product must be installed by a qualified professional. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes The manufacturer will not accept liability for any resulting damages caused by the ... -
Page 5: Installation
2 INSTALLATION 2.1MOUNTING UPRIGHT ． ． ． ． ． ． ． For overhead use, always install a safety cable that can hold at least 10 times the weight of the fixture. For overhead installation, the fixture must be always secured with a safety wire that can bear ... -
Page 6: Data Network Requirements
2.3 Data network requirements Connect the DMX512 controller to the units in series. A DMX 512 data link is required in order to control the fixture via DMX. The fixture has 3/5-pin XLR connectors for DMX data input and output. Each unit has 13 DMX channels so the DMX Addresses should increase by increments of 1，... -
Page 7: Functions And Settings
3 FUNCTIONS AND SETTINGS 3.1 DISPLAY OPERATION MENU：Used to access the menu or to return a previous menu option; ENTER：Used to select and store the current menu or confirm the current function value or option within a menu; UP：Navigates downwards through the menu list and increases the numeric value when in a ... - Page 8 1200HZ（default） Sets the PWM frequency 2400HZ 4000HZ 6000HZ 25000HZ DKEY ON（default） Locks display (passcode <UP>, <DOWN>,<UP>, <DOWN>, <ENTER>) DTIM Display backlight always on Turns off display backlight after 10s/30s 30s（default） /2min of inactivity 2min INFO VERSION Software versions WT.01 Preset color temperatures WT.02 WT.03 WT.04...
-
Page 9: Using A Dmx512 Controller
4 USING A DMX512 CONTROLLER 4.1 DMX CONTROL HSIC Value Function (7CH) CH.1 0-255 INTENSIYT CH.2 0-255 CH.3 0-255 HUE FINE CH.4 0-255 SATURATION NO FUNCTION 1800K 2200K 2700K 3000K 3200K 4000K CH.5 4500K 5000K 5600K 6000K 6500K 7000K 8000K 10000K 10000K STROBE... - Page 10 201-210 ALL RESET 211-255 RESERVED TOUR TR16 Value Function （7CH） （11CH） （16CH） CH.1 CH.1 CH.1 0-255 MASTER DIMMER CH.2 0-255 MASTER DIMMER FINE CH.2 CH.2 CH.3 0-255 CH.4 0-255 RED FINE CH.3 CH.3 CH.5 0-255 GREEN CH.6 0-255 GREEN FINE CH.4 CH.4 CH.7...
- Page 11 41-50 AUTO 1 51-60 AUTO 2 61-70 AUTO 3 71-80 AUTO 4 81-90 AUTO 5 91-100 AUTO 6 101-110 AUTO 7 111-120 AUTO 8 121-130 AUTO 9 131-140 AUTO 10 141-150 PROGRAM 1 151-160 PROGRAM 2 161-255 NO FUNCTION CH.10 CH.15 0-255 AUTO SPEED ADJUSTMENT...
- Page 12 Annex 1 PRESET COLOR Value Color Names 0-15 NO FUNCTION COLOR 1 16-20 Light Salmon 0.499 0.321 COLOR 2 21-25 Scarlet 0.561 0.296 COLOR 3 26-30 L164 Flame Red 0.659 0.302 31-40 NO FUNCTION COLOR 4 41-45 Dark Salmon 0.498 0.347 COLOR 5 46-50...
