- Page 1 图纸编码 RD-SS9481-SM-01(SS-I) 版本号 SS9481SCM 英文说明书 编辑日期 2021/8/5 制作 刘丽萍 审核 白丹 批准 余泽松 1320109430 物料编码 修改内容 修改尺寸 备注 以 A4 样板打印...
- Page 2 NEPTUNE 700 PROFILE USER MANUAL NEPTUNE 700 PROFILE SS9481 MODEL: SS9481SCM...
-
Page 3: Technical Specifications
1 PRODUCT 1.1 TECHNICAL SPECIFICATIONS Type SS9481SCM LED colors 1 LED(CW) 600W Angle 7-50° Power 750W Control Protocol DMX512，RDM，Artnet，sACN，W-DMX(可选) Voltage Range AC100~240V,50/60Hz Input Current 110V/7A,220V/3.5A Protection IP65 Operation Temperature -20℃~45℃ Dimensions 416X364X728mm Weight 34kg... -
Page 4: Safety Notes
1.2 Safety Notes IMPORTANT This product must be installed by a qualified professional. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes ... - Page 5 clearance of 150 mm (6 in.) around fans and air vents. Do not illuminate surfaces within 3 m (10 ft.) of the product. Do not install a fuse that has a higher rating than the one originally installed in the product. Do not bypass fuses.
-
Page 6: Truss Installation
2 INSTALLATION 2.1 MOUNTING Truss installation Keep all combustible materials (e.g. fabric, wood, paper) at least 500 mm (20 in.) away from the product. For overhead use, always install a safety cable that can hold at least 10 times the weight of the fixture. -
Page 7: Data Network Requirements
2.4 Data network requirements Connect the DMX512 controller to the units in series. A DMX 512 data link is required in order to control the fixture via DMX. The fixture has 3/5-pin XLR connectors for DMX data input and output. ... -
Page 8: Functions And Settings
3 FUNCTIONS AND SETTINGS 3.1 DISPLAY OPERATION MENU：Used to access the menu or to return a previous menu option; ENTER：Used to select and store the current menu or confirm the current function value or option within a menu; ... - Page 9 Sets the PWM frequency 1200Hz Default) 2400Hz LED PWM 4000Hz 6000Hz 25000Hz Hold after loss of DMX signal SAVE Default) DMX ERROR BLACK Blackout after loss of DMX signal Display backlight always on Turns off display backlight after 30s/1min DISPLAY TIME /2min of inactivity 1min Default)
- Page 10 GOBO.ROTA 0-255 ANIMATION.D 0-255 ANIMATION.R 0-255 PRISM 0-255 FROST 1 0-255 FROST 2 0-255 ZOOM 0-255 FOCUS 0-255 IRIS 0-255 FRAMING1.L 0-255 FRAMING1.R 0-255 FRAMING2.L 0-255 FRAMING2.R 0-255 FRAMING3.L 0-255 FRAMING3.R 0-255 FRAMING4.L 0-255 FRAMING4.R 0-255 FRAMING ROT 0-255 DIMMER 0-255 STROBE 0-255...
- Page 11 LED use time TEMPERATURE LED temperature VERSION Software versions NETWORK Check network parameter 0x388Axxxxxxxx Check fixture's ID LABEL NEPTUNE 700 PROFILE Check fixture's LABEL MEMORY IC Memory IC ANGLESENSOR Angle Sensor PAN SENSOR Pan Sensor PAN ENCODER Pan Encoder PAN DRIVEIC...
- Page 12 TILT ± 127 Tilt position fine adjustment COLOR ± 127 Color position fine adjustment CMY-C ± 127 CMY-C position fine adjustment CMY-M ± 127 CMY-M position fine adjustment CMY-Y ± 127 CMY-Y position fine adjustment ± 127 CTO position fine adjustment FIXED GOBO ±...
-
Page 13: Using A Dmx512 Controller
4 USING A DMX512 CONTROLLER 4.1 DMX CONTROL BASIC STANDARD Extend Value Function （41CH) (35CH) (44CH) CH.1 CH.1 CH.1 000-255 PAN 0-540° CH.2 CH.2 000-255 PAN FINE CH.2 CH.3 CH.3 000-255 TILT 0-270° CH.4 CH.4 000-255 TILT FINE CH.3 CH.5 CH.5 000-255 PT Speed... - Page 14 COLOR WHELL 000-007 WHITE 008-015 COLOR 1 016-023 COLOR 2 024-031 COLOR 3 032-039 COLOR 4 CH.10 CH.12 CH.12 040-047 COLOR 5 048-055 COLOR 6 056-063 COLOR 7 064-191 COLOR WHELL 0-360° 192-222 COLOR WHELL RAINBOW EFFECT(SPEED 100%->1) 223-224 STOP 225-255 COLOR WHELL RAINBOW EFFECT(SPEED 1->100%) CH.13...
- Page 15 211-215 STOP ROTATING GOBO REVERSE ROTATION (SPEED 1 —> 100%) 216-255 CH.15 CH.16 000-255 GOBO ROTATING FINE FIXED GOBO WHEEL 0-10 WHITE 11-15 FIXED GOBO WHEEL 1 16-20 FIXED GOBO WHEEL 2 21-25 FIXED GOBO WHEEL 3 26-30 FIXED GOBO WHEEL 4 31-35 FIXED GOBO WHEEL 5 36-40...
- Page 16 201-205 STOP PRISM INSERT AND REVERSE ROTATION (SPEED 1 —> 100%) 206-255 FROST 1 CH.17 CH.20 CH.21 0-255 FROST（0-100%） FROST 2 CH.18 CH.21 CH.22 0-255 FROST（0-100%） IRIS IRIS OPEN —> CLOSE (FROM LARGE TO SMALL) 0-127 128-130 IRIS CLOSE CH.19 CH.22 CH.23 131-171...
- Page 17 CH.40 0-255 FRAMING ROTATION FINE CH.33 CH.38 CH.41 0-255 DIMMER CH.39 CH.42 0-255 DIMMER FINE STROBE NO FUNCTION 10-99 STROBE（ FROM SLOW TO FAST） CH.34 CH.40 CH.43 100-109 NO FUNCTION 110-179 LIGHTNING STROBE 180-189 NO FUNCTION 190-255 RANDOM SROBE CONTROL(EXECUTE AFTER 3 SECONDS) 000-010 NO FUNCTION 011-020...
