4.Sliding the power switch of the transmitter control panel to
"ON" position, as show in Fig.7, the battery status indicator
gives a flash to indicate a normal operation. If there is no flash,
it indicates either power supply is not available or battery is
installed wrongly. If the indicator keeps lighting , it indicates
that battery is weak , a replacement is necessary.
5
6
Caution: The audio cable serves as antenna for this VHF system. Please stretch the
cable to its maximum to get the most efficient transmission power.
