Extra Long Range (XLR) Wireless Microphone System
RR-2000
RCC-2000
Operation manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RR-2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chiayo RR-2000

  • Page 1 RR-2000 RCC-2000 Extra Long Range (XLR) Wireless Microphone System Operation manual ISO 9001 REGISTERED INTERNATIONAL 14001 ISO 14001 REGISTERED INTERNATIONAL OHSAS 18001 OHSAS 18001 GREEN PRODUCT...
  • Page 2: Basic Concept

    The Remote Control Center RCC-2000 is the nerve center of the whole system. It is capable of controlling up to 4 units of Remote Receiver RR-2000, delivering power supply and receiving / monitoring signal of the individual Remote Receiver via Cat 5e cable.
  • Page 3 ISO 9001|ISO 14001|OHSAS 18001 VARIOUS SETTINGS ON THE REMOTE CONTROL CENTER RCC-2000 ■ Adjusting the volume Press MENU button to go to “VOLUME” page. MENU  Hold SET to enter setting. Choose A or B by SET button, and UP/DOWN buttons to adjust the volume.
  • Page 4 A or B  change FREQUENCY The display value indicates the RF signal strength. Pointer ”” indicates which RR-2000’s module the audio comes from. The item marked with “X” is power off on either the module itself or RCC-2000.
  • Page 5 If this unit is connected to the RR1 RJ-45 connector of the RCC-2000, module A must be set to A1 and module B to B1. If another RR-2000 is connected to the RR2 RJ-45 connector, its module A must be set to A2 and module B set to B2. And so on.
  • Page 6 A or B and DOWN button to select 1/2/3/4. Precisely, the two receivers of 1st RR-2000 should be named as A1 and B1, for 2nd as A2 and B2, for 3rd as A3 and B3, for 4th as A4 and B4. This should be done so in accordance with the preset programming in the Remote Control Center RCC-2000.
  • Page 7 ■ Mounting Both the remote control center RCC-2000 and remote receiver RR-2000 have a half-19"-casing design. They can be cabinet-mounted with either one or two units. Individual kits for mounting one or two units are available and please refer to below assembly illustration.
  • Page 8 HANDHELD TRANSMITTER SQ-6100/SQ-7100 Microphone parts and functions SQ-6100 SQ-7100 Cartridge Battery weak/power LED Power switch Battery compartment Bottom cap Locking button Audio mute switch Setting button Up button Down button Charging port ■ Battery installation & indicator This transmitter requires 2 x AA batteries to operate. To install, remove the battery cover and slide the batteries into the battery compartment &...
  • Page 9 ISO 9001|ISO 14001|OHSAS 18001 ■ Making changes to battery selection Use UP or DOWN button to go to the Battery selection page. Press UP or DOWN button to move the cursor to either NiMH (rechargeable battery) or AKLN (Alkaline battery) position. When the desired battery has been selected, it will be automatically saved and stored in the memory.
  • Page 10 BELT-PACK TRANSMITTER SM-7100 ■ Parts and functions 1. Antenna 2. Battery weak/audio mute indicator 3. Audio mute switch 4. (Lavalier microphone) Mini XLR connector 5. LCD 6. Charging port 7. Cover release button 8. Power switch 9. Gain control (GT, high impedance) 10.
  • Page 11 ISO 9001|ISO 14001|OHSAS 18001 ■ Making changes to battery selection Use UP or DOWN button to go to the Battery selection page. Press UP or DOWN button to move the cursor to either NiMH (rechargeable battery) or AKLN (Alkaline battery) position. When the desired battery has been selected, it will be automatically saved and stored in the memory.
  • Page 12 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw|Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan|Tel: 886-2-27415741|Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan|Tel: 886-5-2711000|Fax: 886-5-5767611...
