RCC-2000 / RR-2000
Operation manual
Extra Long Range (XLR) Wireless
Microphone System
CHIAYO ELECTRONICS CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RCC-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chiayo RCC-2000

  • Page 1 RCC-2000 / RR-2000 Operation manual Extra Long Range (XLR) Wireless Microphone System CHIAYO ELECTRONICS CO., LTD.
  • Page 2 1. Remote Control Center RCC-2000 2. Remote Receiver RR-2000 The Remote Control Center RCC-2000 is the nerve center of the whole system. It is capable of controlling up to 4 units of Remote Receiver RR-2000, delivering power supply and receiving / monitoring signal of the individual Remote Receiver via Cat 5e cable.
  • Page 3 Instructions Connecting the remote receivers and the control unit Connect the remote receivers RR-2000 to the control unit RCC-2000 with CAT-5/6/7 cables. Each cable length should not exceed 250 meters. CAT-5/6/7 cables. Max length 250m RR-2000 LIN K A N T .B A N T.
  • Page 4 RCC-2000 / RR-2000 Extra Long Range (XLR) Wireless Microphone System PARTS AND FUNCTIONS OF RCC-2000 ► Front 1. Power switch. 2. RF signal indicator of the 2 remote receivers’ CH A and CH B 3. AF signal indicator of the 2 remote receivers’ CH A and CH B 4.
  • Page 5 Instructions Warning: In order for this function to work correctly, the volume of the remote receiver module side should be manually fixed at an appropriate level beforehand! Changing ON/OFF status of the remote receivers Press MENU button to go to “R1-4” page. MENU ...
  • Page 6 RCC-2000 / RR-2000 Extra Long Range (XLR) Wireless Microphone System Changing the frequency Press MENU button to go to “CHANNEL/FREQUENCY” page. MENU  Hold SET to enter setting. Choose A or B by SET button, and UP/DOWN buttons to change the frequency.
  • Page 7 RIGHT: channel B 1. Power switch. 2. 7-segment LED display 3. Channel UP button 4. Channel DOWN button (RCC-2000 has priority and overrides this button for channel number) 5. AF signal indicator 6. RF signal indicator 7. Module power/volume control ►...
  • Page 8 (CH A) is assigned on the left and the B channel (CH B) assigned on the right of this rack. If this unit is connected to the RR1 RJ-45 connector of the RCC-2000, module A must be set to A1 and module B to B1. If another RR-2000 is connected to the RR2 RJ-45 connector, its module A must be set to A2 and module B set to B2.
  • Page 9 Instructions Audio output connection Balanced output Unbalanced output ¼” PHONE PLUG connector provides XLR connector provides balanced audio output signal from this jack to the unbalanced audio output signal from this jack mixer/amplifier. Use an audio output cable to the mixer/amplifier. Use an audio output with “XLR”...
  • Page 10 Mounting Both the remote control center RCC-2000 and remote receiver RR-2000 have a half-19"-casing design. They can be cabinet-mounted with either one or two units. Individual kits for mounting one or two units are available and please refer to below assembly illustration.
  • Page 11 Instructions Outdoor weather-resistant mounting Remote receiver RR-2000 can be mounted outdoor in a weather-resistant casing PRR-2000 as following. It’s highly recommended to install the casing under the protection of the roof or cover against the rain. ► ▼...
  • Page 12 CHIAYO ELECTRONICS CO., LTD. Http://www.chiayo.com.tw | Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 | Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 | Fax: 886-5-5767611 12I1488...
