  • Page 2 Network Camera User’s Guide To prevent fire or shock hazard, do not expose the unit to rain or moisture. For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 3: Declaration Of Conformity

    Network Camera User’s Guide Declaration of Conformity This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    Network Camera User’s Guide Table of Contents Overview ........................6 Introduction ......................6 Features ........................6 Minimum System Requirements................6 Package Contents ....................7 Physical Description ....................8 2.1 Front View ....................... 8 2.2 Bottom View ....................8 Hardware Installation ................... 10 Preparation ......................
  • Page 5 Network Camera User’s Guide 6.1.2.2 Privacy Mask ................36 6.1.3 System: Configure and maintain system..........37 6.1.3.1 System: ..................37 6.1.3.2 Date & Time ................38 6.1.3.3 Maintenance ................39 6.1.4 Video: Configure profile ..............42 6.1.4.1 Common ................... 42 6.1.4.2 Video Profile ................

  • Page 6: Overview

    Network Camera User’s Guide Overview The user’s guide explains how to operate this camera from a computer. User should read this manual completely and carefully before you operate the device. Introduction The device is accessible via the LAN or Internet connection. Connect your device directly to a local area network or xDSL modem, and with Microsoft®...

  • Page 7: Package Contents

    Network Camera User’s Guide 1. Package Contents ■ Cube Camera Network ■ -ROM ( manual and IP utility) User ■ Start Guide Quick ■ Camera mounting kit ■ adapter (DC12V) Power If any of the above items are missing, please contact your dealer immediately. Note: Using a power supply with a different voltage than the one included with the Network Camera will cause damage and void the warranty for this product.

  • Page 8: Physical Description

    Network Camera User’s Guide 2. Physical Description 2.1 Front View Microphone Lens & focus ring Micro-SD Lens & focus ring User could use this ring to adjust focus manually. Microphone The Camera has built-in an internal microphone. This microphone is hidden in the pinhole located on the front panel.
  • Page 9 Network Camera User’s Guide got problems after restart, user can restore the factory default settings and install it again. To restore the device, please follow the steps below: 1. Make sure the Camera is ready first. Insert the paper clip or other tool and press and hold the button down continuously.

  • Page 10: Hardware Installation

    Network Camera User’s Guide 3. Hardware Installation 1. Attach the Camera with the included stand 2. Place the Camera on the table or fix it onto ceiling or wall Use three screws to fix the Network Camera onto the ceiling or wall. You could also put the Network Camera on the table directly.
  • Page 11 Network Camera User’s Guide 4. Connect the external power supply to Camera Connect the attached power adapter to the DC power jack of the Network Camera. Note: Use the power adapter, 12VDC, included in the package and connect it to wall outlet for AC power. Power Cable Once you have installed the camera well and powered it on, the Power LED (orange) will turn on later.

  • Page 12: Preparation

    Network Camera User’s Guide 4. Preparation 4.1 Search and Set up by IPWizard II When you installed the Camera on a LAN environment, you have two easy ways to search your Cameras by IPWizard II or UPnP™ discovery. Here is the way to execute IPWizard II to discover Camera’s IP address and set up related parameter in a Camera.

  • Page 13: View

    Network Camera User’s Guide 4.1.2 View If IP Wizard II finds network devices, View button will be available. Please select the device you want to view and click the View button. Then you could see the video from camera directly. Furthermore you could double click the left button of mouse to link to the network device by browser.
  • Page 14 Network Camera User’s Guide setting procedure and click “>>” button will move to next page as below. In case, you do not want to change username and/or password, then just click “Submit” button to perform your setting accordingly. Click “<<” button will go back to previous page. If you like to change username and/or password of the device, just click the check button.

  • Page 15: Upnp Of Windows® Xp, Vista Or 7

    Network Camera User’s Guide 4.2 UPnP of Windows® XP, Vista or 7 UPnP™ is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. This device is an UPnP enabled device. If the operating system, Windows XP, Vista or 7, of your PC is UPnP enabled, the Network Camera will be very easy to be found.

  • Page 16: Access The Device From The Internet Explorer For The First Time

    Network Camera User’s Guide To use UPnP IGD function (NAT traversal), you need to make sure the UPnP function is enabled in your router. Most new home routers should support this function. Some of routers are default enable and others are not. Please check user’s manual of your NAT router for detail. (2) Enable UPnP NAT traversal option of the Network Camera Refer to Setting ...

  • Page 17: Logging In As An User

    Network Camera User’s Guide 4.5 Logging in as an User If you log in the Camera as an ordinary User, “Setting” function will be not accessible. 4.6 Logging in as an Administrator If you log in the Camera as the Administrator, you can perform all the settings provided by the device.

  • Page 18: Monitor Image Section

    Network Camera User’s Guide 5.1 Monitor Image Section The image shot by the device is shown here. The date and time are displayed at the top of the window. 5.2 Video Profile The device supports multi-profile function for H.264 and MJPEG simultaneously. User can chose the proper and/or preferred profile which is listed here.

  • Page 19: 2-Way Audio

    Network Camera User’s Guide 5.5 2-Way Audio The device supports 2-way audio function. User can chose to enable or disable this function by toggling the icon below. Disable audio uploading function. Enable audio uploading function. 5.6 Full Screen Enlarge video to full screen display. Enlarge video to full screen display.

  • Page 20: Digital Zoom

    Network Camera User’s Guide 5.7.1 Digital Zoom Click Digital Zoom to active this function as above. User can drag or scale the box over the video to adjust zoom ratio and position. 5.7.2 Snapshot Click Snapshot to activate this function. Press Snapshot button to take a picture. The image file is saved as JPEG format into your local PC.

  • Page 21: Record

    Network Camera User’s Guide 5.7.3 Record Click Record to activate this function. Press Record button to start recording. The video file is saved as ASF format into your local PC. While you want to stop it, press Stop to stop recording.

  • Page 22: About

    Network Camera User’s Guide 5.7.5 About Click About to show this ActiveX information. 22/65...

  • Page 23: Administrating The Device

    Network Camera User’s Guide 6. Administrating the Device 6.1 System Setting This function is only available for user logged into Camera as administrator. Click on each menu name to display its setting page. Item Action Configure Network settings such as DHCP, DDNS, 3GPP, Network PPPoE and UPnP Camera...

  • Page 24: Network

    Network Camera User’s Guide 6.1.1.1 Network This section provides the menu for connecting the device through Ethernet cable. MAC address: Displays the Ethernet MAC address of the device. Note that user can not modify it. Obtain IP address automatically (DHCP): DHCP: Stands for Dynamic Host Configuration Protocol.

  • Page 25: Ipv6

    Network Camera User’s Guide http://xx.xx.xx.xx/, or http://xx.xx.xx.xx:xxxx/ to access the device. If multiple devices are installed on the LAN and also required to be accessed from the WAN, then the HTTP Port can be assigned as the virtual server port mapping to support multiple devices.

  • Page 26: Ddns Service

    Network Camera User’s Guide Choose the HTTPS port. The default value is 443. 6.1.1.4 DDNS service DDNS: Stands for Dynamic Domain Name Server Your Internet Service Provider (ISP) provides you at least one IP address which you use to connect to the Internet. The address you get may be static, meaning it never changes, or dynamic, meaning it’s likely to change periodically.

  • Page 27: Pppoe

    Network Camera User’s Guide DDNS: To enable or disable the DDNS service here. Server name: Choose one of the built-in DDNS servers. DDNSHost: The domain name is applied of this device. User name: The user name is used to log into DDNS. Password: The password is used to log into DDNS.

  • Page 28: Streaming

    Network Camera User’s Guide PPPoE: To enable or disable the PPPoE service here. User name: Type the user name for the PPPoE service which is provided by the ISP. Password: Type the password for the PPPoE service which is provided by the ISP. IP address, Subnet mask, and Gateway (read only): Shows the IP information got from PPPoE server site.

  • Page 29: Upnp

    Network Camera User’s Guide 6.1.7 UPnP UPnP is short for Universal Plug and Play, which is a networking architecture that provides compatibility among networking equipment, software, and peripherals. This device is an UPnP enabled Network Camera. If your operating system is UPnP enabled, the device will automatically be detected and a new icon will be added to “My Network Places.”...

  • Page 30: Bonjour

    Network Camera User’s Guide Friendly Name: To show the friendly name of this device here. UPnP NAT Traversal When enabled, the device will attempt to configure port mapping in a NAT router on your network, using UPnP™. Note that UPnP™ must be enabled in the NAT router first. Port Range: The port range will open in NAT router.

  • Page 31: Ip Filter

    Network Camera User’s Guide ONVIF: To enable or disable the ONVIF interface here. And select the ONVIF version to match client’s supported version. 6.1.1.10 IP Filter You can enter different user’s IP address which are allowing enter or denying by the device. IP Filter: To enable or disable the IP filter function here.

  • Page 32: Ip Notification

    Network Camera User’s Guide 6.1.1.11 IP Notification In case the IP address is changed, system is able to send out an email to alert someone if the function is enabled. SMTP Notification (e-mail): If enable this function, then the “Send to” and “Subject” fields need to be filled. Send To: Type the receiver’s e-mail address.
  • Page 33 Network Camera User’s Guide Proxy Address: Type the server name or the IP address of the HTTP Proxy. Proxy Port: Set port number of Proxy. Proxy Login name: Type the user name for the HTTP Proxy. Proxy Login Password: Type the password for the HTTP Proxy. Custom parameter: User can set specific parameters to HTTP server.

  • Page 34: Camera: Adjust Camera Parameters

    Network Camera User’s Guide 6.1.2 Camera: Adjust Camera parameters Use this menu to set the functions of the camera parameters of the device. 6.1.2.1 Picture Rotation: Turn the “Mirror” and “Vertical Flip” On or OFF. The image will be overturned as below. 34/65...
  • Page 35 Network Camera User’s Guide White Balance: Auto: will adjust the white balance automatically. Hold: will hold the white balance. Exposure Control: Auto: will adjust the internal gain automatically. Hold: will hold the internal gain. Color Level: Large value will be colorful. Brightness: Large value will brighten camera.

  • Page 36: Privacy Mask

    Network Camera User’s Guide 6.1.2.2 Privacy Mask Use this page to specify privacy mask window 1 to window 8 and set the name and gray level for selected window. Add and Delete: To add or delete the privacy mask windows, user can specify up to 7 windows to mask the video captured by this device.

  • Page 37: System: Configure And Maintain System

    Network Camera User’s Guide 6.1.3 System: Configure and maintain system Use this menu to perform the principal settings of the device. 6.1.3.1 System: DIPS (Dynamic IP Service): -Function Discarded- To enable or disable the DIPS® (Dynamic IP Service) function. Device ID (for DIPS): -Function Discarded- It’s a unique number of each device for identification and this ID is used for DIPS.

  • Page 38: Date & Time

    Network Camera User’s Guide You will see that DIPS is a much easier service than DDNS. Device Title: You can enter the name of this unit here. It’s very useful to identify the specific device from multiple units. The information will be shown on IPWizard II once the device is found. Software Version: This information shows the software version of the device.

  • Page 39: Maintenance

    Network Camera User’s Guide 6.1.3.3 Maintenance Hard Factory Default (Include the network setting): Recall the device hard factory default settings. Note that click this button will reset all device’s parameters to the factory settings (including the IP address). Factory Default (Except the network setting): The unit is restarted and most current settings are reset to factory default values.
  • Page 40 Network Camera User’s Guide Firmware Upgrade: The device supports new firmware upgrade (the software that controls the operation in the device). Please contact your dealer for the latest version if necessary. Download the latest firmware file from our website or your dealer. Unzip this firmware file to binary file and store it into your PC.
  • Page 41 Network Camera User’s Guide Warning!!! The download firmware procedure cannot be interrupted. If the power and/or network connection are broken during the download procedure, it WILL cause serious damage to the device. Strongly suggest that DO NOT upgrade firmware via Wireless LAN due to high error rate possibly and don't allow any other clients to access this unit during updating procedure.

  • Page 42: Video: Configure Profile

    Network Camera User’s Guide 6.1.4 Video: Configure profile This device provides 2 modes of video profile. The first one is 1.3 Mega mode which supports video resolution up to 1.3 Mega-pixel. Maximum frame rate of this mode is up to 30fps. The second one is 720p mode which supports video resolution up to 1280x720 but frame rate can be up to 30fps.

  • Page 43: Video Profile

    Network Camera User’s Guide 6.1.4.2 Video Profile Name: To assign a name to the selected profile. Video Type: Video codec of the selected profile. Resolution: Show the resolution of the selected profile. ROI: Assign the selected profile as a ROI stream or not. (Only available for the profiles with max resolution) Rate Control: Defines the rate control method of this profile.

  • Page 44: Roi

    Network Camera User’s Guide GOP Control: Defines the Intra/Inter-frame (I/P) ratio of this profile. For example, set the GOP to 30, then the video stream will have one Intra-frame every 30 frames. Multicast: Enable or disable the multicast function. Multicast Video: IP address and port for multicast video streaming of the selected profile.

  • Page 45: Audio: Audio Parameters

    Network Camera User’s Guide 6.1.5 Audio: Audio parameters Audio: To enable or disable audio function Audio Type: To select audio codec Mute While PT: Mute the audio while pan and/or tilt motion Audio Mode: To select Simplex or Full duplex (2-way audio) mode Input Gain: To adjust gain of input audio Output Gain:...

  • Page 46: User: Manage User Name, Password And Login Privilege

    Network Camera User’s Guide 6.1.6 User: Manage user name, password and login privilege Use this menu to add, update, or remove the usernames and passwords of the Administrator and viewer. Access Right: Administrator can access every function in this device. However, Viewers only can view the video and access limited function.

  • Page 47: E-Mail: Setup E-Mail Configuration

    Network Camera User’s Guide 6.1.7 E-Mail: Setup E-Mail configuration User may setup SMTP mail parameters for further operation of Event Schedule. That’s, if users want to send the alarm message out, it will need to configure parameters here first and also add at least one event schedule to enable event triggering.

  • Page 48: Motion Detection: Setup Motion Detection

    Network Camera User’s Guide 6.1.8 Motion detection: Setup motion detection Use this menu to specify motion detection window 1 to window 10 and set the conditions for detection while observing a captured image. Add and Del: To add or delete the motion windows. User can specify up to 10 Included and/or Excluded windows to monitor the video captured by this device.

  • Page 49: Audio Detection: Setup Audio Detection

    Network Camera User’s Guide 6.1.9 Audio detection: Setup audio detection Use this menu to specify audio alarm level. Event will be triggered if detected audio volume exceeds the alarm level. Audio Alarm Level: Move the slide to specify the audio alarm level. The level bar will change accordingly in the picture below and current detected volume is displayed in blue.
  • Page 50 Network Camera User’s Guide Enable automatic disk cleanup: Delete old recorded files while the conditions are reached as below. Remove recordings order than: Delete old files by days. Remove oldest recordings when disk is: Delete old files by left capacity. 50/65...

  • Page 51: Samba Server

    Network Camera User’s Guide 6.1.10.2 SAMBA Server This page shows the status of SAMAB server. You may setup related parameters to manage the remote SAMBA server. Host: Type the SAMBA server domain name or the IP address of the SMTP server. Share: Type the share folder of remote SAMBA server which the camera will upload files to this space.

  • Page 52: Continuous Recording

    Network Camera User’s Guide 6.1.11 Continuous Recording: The camera can continuously record video stream into files and save them to attached SD card or remote SAMBA server. Note that there are various factors affecting the recording results, such as the camera’s system loading, network condition, SD card performance, multiple client accessing, and so on.

  • Page 53: Recording List: Files List Inside The Sd Card

    Network Camera User’s Guide 6.1.12 Recording List: Files list inside the SD Card 6.1.12.1 Recording List This page only shows the event recording files which stored in SD card. User may play or delete the selected file. 6.1.12.2 Continuous Recording List This page only shows the continuous recording files which stored in SD card or remote SAMBA server.

  • Page 54: Event Server: Setup Ftp/Tcp/Http/Samba Server Configuration

    Network Camera User’s Guide 6.1.13 Event Server: Setup FTP/TCP/HTTP/SAMBA server configuration 6.1.13.1 FTP Server You may setup FTP parameters for further operation of Event Schedule. That’s, if users want to send the alarm message to an FTP server, it will need to configure parameters here and also add at least one event schedule to enable event triggering as SMTP.
  • Page 55 Network Camera User’s Guide Name: User can specify multiple TCP servers as wish. Therefore, user needs to specify a name for each TCP server setting. TCP Server: Type the server name or the IP address of the TCP server. TCP Port: Set port number of TCP server.

  • Page 56: Http Server

    Network Camera User’s Guide 6.1.13.3 HTTP Server The device also can send event message to specified HTTP server. Name: User can specify multiple HTTP servers as wish. Therefore, user needs to specify a name for each HTTP server setting. URL: Type the server name or the IP address of the HTTP server.
  • Page 57 Network Camera User’s Guide Name: User can specify multiple HTTP servers as wish. Therefore, user needs to specify a name for each HTTP server setting. SAMBA Server: Type the server name or the IP address of the SAMBA server. Test: Check the SAMBA server whether this account is available or not.

  • Page 58: Event Schedule: Configure The Event Schedule

    Network Camera User’s Guide 6.1.14 Event Schedule: Configure the event schedule 6.1.14.1 Setting This menu is used to specify the schedule of Event or Schedule Trigger and activate the some actions provided by this device. Where the Schedule Trigger will be activated by user-define interval without event happened.
  • Page 59 Network Camera User’s Guide Example 2: Send file to E-Mail server by motion triggered from Friday 18:00 to Saturday 06:00 Select event trigger. Enable time: start from Friday 18:00 and keep work in 12 hours, so it will stop on Saturday 06:00.
  • Page 60 Network Camera User’s Guide Enable Voice Alert every 10-minute during 18:00 to 24:00 from Monday to Friday. Type: Select schedule trigger and interval is 10-minute. Enable time: Select Monday to Friday, and set start time from 18:00 and keep work in 6 hours.

  • Page 61: Record

    Network Camera User’s Guide 6.1.14.2 Record User can choose the type of record file for event or schedule application. Record File Type: Choose a profile to record. Record File Prefix: Define the prefix of recorded filename. Pre-Trigger Duration: Define the maximum duration of pre-alarm. Best Effort Duration: Define the best effort duration of post-alarm.

  • Page 62: Using Vlc Player To Access Rtsp Streaming

    Network Camera User’s Guide 7. Using VLC Player to Access RTSP Streaming Note 1: This information is provided for convenience only. We will not provide support for the installation or use of VLC software. Note 2: The IP address used in the document are the default URLs and are provided for example purposes only.
  • Page 63 Network Camera User’s Guide 3GPP To use the 3GPP function, in addition to previous section, you might need more information or configuration to make this function work. Note that to use the 3GPP function, it strongly recommends to install the Networked Device with a public and fixed IP address without any firewall protection.

  • Page 64: Specification

    Network Camera User’s Guide 8. Specification Video Sensor Type 1/4" image sensor Active Pixels 1280 x 1024 (HxV) Compression H.264 /Motion JPEG Streaming Simultaneously multi-profile streaming SXGA, VGA, QVGA, 160x120 (1.3 Mega Mode); Resolution 720P, 640x360, 160x90 (720p Mode) Max. Frame Rate 1.3MP (1280x1024) at 30 fps (NTSC/PAL) Day/Night Digital D/N Control...
  • Page 65 Network Camera User’s Guide Motion / Schedule Store Category Stores video clips and snapshots Local Storage Memory Card Slot Micro SD / Micro SDHC Card up to 32 GB Memory Card Overwrite Network IPv4, TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, FTP, RTP, Protocol RTSP, RTCP, ICMP, UPnP, IPv6, HTTPS, DDNS, DIPS, ARP, Bonjour, IGMP, PPPoE, 3GPP, SAMBA...
