MAINTENANCE MANUAL
KLN 94

GPS NAVIGATION

SYSTEM
MANUAL NUMBER 006-15599-0000
REVISION 0 SEPTEMBER, 2000

Advertisement

   Related Manuals for Honeywell bendis king KLN 94

   Summary of Contents for Honeywell bendis king KLN 94

  • Page 1: Gps Navigation

    MAINTENANCE MANUAL KLN 94 GPS NAVIGATION SYSTEM MANUAL NUMBER 006-15599-0000 REVISION 0 SEPTEMBER, 2000...
  • Page 2 MAINTENANCE MANUAL KLN 94 GPS NAVIGATION SYSTEM...
  • Page 3 ©2000 Honeywell International Inc. Reproduction of this publication or any portion thereof by any means without the express written permission of Honeywell is prohibited. For further information contact the manager, Technical Publications, Honeywell, One Technology Center, 23500 West 105th Street Olathe KS 66061...
  • Page 4 ©2000 Honeywell International Inc. Reproduction of this publication or any portion thereof by any means without the express written permission of Honeywell is prohibited. For further information contact the manager, Technical Publications, Honeywell, One Technology Center, 23500 West 105th Street Olathe KS 66061...
  • Page 5 BENDIX/KING KLN 94 SECTION IV THEORY OF OPERATION PARAGRAPH PAGE GENERAL INFORMATION 4.1.1 GENERAL DESCRIPTION 4.1.2 BASIC CONSTRUCTION BLOCK DIAGRAM THEORY 4.2.1 POWER BOARD 4.2.2 FRONT PANEL ASSEMBLY 4.2.3 GPS XPRESS RECEIVER 4.2.4 MAIN BOARD 4.2.5 UNIT INTERCONNECTION DETAILED CIRCUIT THEORY 4-21 4.3.1 POWER BOARD...
  • Page 6 BENDIX/KING KLN 94 SECTION VI ILLUSTRATED PARTS LIST PARAGRAPH PAGE General Revision Service List of Abbreviations Sample Parts List KLN 94 FINAL ASSEMBLY AND SYSTEM SOFTWARE KLN 94 FRONT PANEL ASSY. 6-15 KLN 94 BUTTON/BACKLIGHT ASSY. 6-21 KLN 94 BUTTON BOARD 6-25 KLN 94 SWITCH BOARD ASSY.
  • Page 7: Table Of Contents

    BENDIX/KING KLN 94 LIST OF ILLUSTRATIONS (cont.) FIGURE PAGE KLN 94 POWER BOARD TROUBLESHOOTING FLOWCHART 5-53 SAMPLE PARTS LIST KLN 94 ASSEMBLY DRAWING KLN 94 FRONT PANEL ASSEMBLY DRAWING 6-17 KLN 94 FRONT PANEL BUTTONS/BACKLIGHT DRAWING 6-23 KLN 94 BUTTON BOARD DRAWING 6-27 KLN 94 BUTTON BOARD SCHEMATIC 6-29...
  • Page 8: Table Page

    BENDIX/KING KLN 94 LIST OF TABLES (cont.) TABLE PAGE Recommended Cleaning Agents 5-23 Unsafe Cleaning Agents 5-24 TOC-4 15599M00.JA Rev 0, Sept/2000...
  • Page 9: Assembly Designations

    BENDIX/KING KLN 94 SECTION IV THEORY OF OPERATION GENERAL INFORMATION 4.1.1 GENERAL DESCRIPTION The KLN 94 is a panel-mounted, long range, GPS based airborne navigation system with a data- base. The KLN 94 provides VFR, IFR enroute, terminal and non-precision approach functions. The KLN 94 is certified to TSO C129a.
  • Page 10 BENDIX/KING KLN 94 BLOCK DIAGRAM THEORY Figure 4-1 is a block diagram showing the basic signal flow through a KLN 94 GPS RNAV. 4.2.1 POWER BOARD The Power Board block diagram is shown in Figure 4-2. The power supply uses a flyback converter circuit to transform the aircraft power bus voltage (11-33 volts) into the required voltages for the KLN 94’s internal circuitry.
  • Page 11 BENDIX/KING KLN 94 FIGURE 4-1 KLN 94 UNIT BLOCK DIAGRAM Rev 0, Sept/2000 15599M00.JWA Page 4-3...
  • Page 12 BENDIX/KING KLN 94 FIGURE 4-2 KLN 94 POWER SUPPLY BLOCK DIAGRAM (Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 4-5...
  • Page 13 BENDIX/KING KLN 94 FIGURE 4-2 KLN 94 POWER SUPPLY BLOCK DIAGRAM (Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 4-7...
  • Page 14 BENDIX/KING KLN 94 FIGURE 4-3 KLN 94 FRONT PANEL BLOCK DIAGRAM Rev 0, Sept/2000 15599M00.JWA Page 4-9...
  • Page 15 BENDIX/KING KLN 94 FIGURE 4-4 KLN 94 HOST MICROPROCESSOR BLOCK DIAGRAM Rev 0, Sept/2000 15599M00.JWA Page 4-11...
  • Page 16 BENDIX/KING KLN 94 FIGURE 4-5 KLN 94 GRAPHICS MICROPROCESSOR BLOCK DIAGRAM Rev 0, Sept/2000 15599M00.JWA Page 4-13...
  • Page 17 BENDIX/KING KLN 94 FIGURE 4-6 KLN 94 I/O BLOCK DIAGRAM (Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 4-15...
  • Page 18 BENDIX/KING KLN 94 FIGURE 4-6 KLN 94 I/O BLOCK DIAGRAM (Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 4-17...
  • Page 19 BENDIX/KING KLN 94 FIGURE 4-7 KLN 94 UNIT INTERCONNECTION DIAGRAM Rev 0, Sept/2000 15599M00.JWA Page 4-19...
  • Page 20 BENDIX/KING KLN 94 DETAILED CIRCUIT THEORY 4.3.1 POWER BOARD 4.3.1.1 General Refer to Figure 4-2 and Power Board section of the Illustrated Parts List as an aid for the following discussion. The KLN 94 power supply produces the +5.0V, +9V, -12V, +13V, -15V, and +20V (V_LCD_DRIVE) DC voltages.
  • Page 21 BENDIX/KING KLN 94 4.3.1.2.4 ON/OFF Control The On/Off Control circuit monitors the signal from the front panel On/Off switch (PWR_SW_LO), the avionics power bus (AIRCRAFT_POWER_MONITOR), and the microprocessor-controlled shutdown line (POWER_SHUTDOWNn). If these inputs allow the unit to turn on, the On/Off Con- trol circuit outputs an active-low ENABLEn signal.
  • Page 22 BENDIX/KING KLN 94 Soft start and shutdown control is provided by CR6025 which serves to hold the COMP output (Pin 1) of U6002 low to delay startup or initiate shutdown. Undervoltage shutdown is generated by U6003-B pulling pin 1 (COMP) of U6002 to ground. This occurs when V_IN falls below 7.2V. If this happens, R6067 provides hysteresis to prevent restart until INT_AC_PWR has returned to at least +9.0V.
  • Page 23 BENDIX/KING KLN 94 4.3.1.3.8 Power Interrupt Switch The Power Interrupt Switch provides the control logic and power switches to turn on the Capacitor Backup circuit during power interrupt. U6003-A senses the output voltage from the Input Hash Filter and compares it to a reference voltage that is generated by U6002 pin 14 (5V_LVPS_REF). R6060 provides about 0.7V of hysteresis.
  • Page 24 BENDIX/KING KLN 94 If too much current flows, R6037 will begin to turn on Q6011 which then cuts back gate drive to Q6009-B, thereby limiting the current. When the unit is turned off, the +5V power applied to the gate of Q6010 will be so low that Q6010 will be off.
  • Page 25 BENDIX/KING KLN 94 At power down, the reset controller’s output pin, U6004-1, goes low immediately after a dip in the +5V supply is detected. When it goes low, Q6017 stops conducting which causes Q6020 to stop conducting. Resistor R6057 bleeds down the level of the LCD Bias Supply at least as quickly as the +5V supply voltage falls.
  • Page 26 BENDIX/KING KLN 94 4.3.3 GPS XPRESS RECEIVER CAUTION DO NOT ATTEMPT TO ALIGN OR REPAIR THE GPS PXPRESS RECEIVER BOARD (P/N 200–08825–0001). THIS BOARD IS NOT A FIELD SERVICEABLE ASSEMBLY The GPS Receiver Board, operating in conjunction with the KA 92 antenna provides the Host mi- croprocessor (on the Main board) with position, velocity, and time information through the RS-232 interface module.
  • Page 27: Adc Channels

    BENDIX/KING KLN 94 SYSTEM ANALOG ANALOG SIGNALS DESCRIPTIONS CHANNELS ADA0 DIM_POT_SENSE Monitors the setting of the Switch Board U7005 pot setting. ADA1 DIGTEMP Measures unit temperature. ADA2 DIM_BUS_SENSE Monitors the setting of the aircraft’s lighting bus. ADA3 DISPLAY_TEMP Measure of the Backlight LED’s temperature. ADA4 PWRBUS Samples unit bus voltage selected by U5020.
  • Page 28: Host Processor Address Map

    BENDIX/KING KLN 94 uP Chip Select Designation Size Space Data Size, bits CSBOOT* ROM_CSn 512K 00000-7FFFF FC1_CS4* XROM_CSn 256K 80000-BFFFF BG_CS1* DB_CSn C0000-CFFFF BGACK_CS2* DBXOVER_CSn D0000-D07FF FC2_CS5* SRAM1_CSn D0800-DFFFF A20_CS7* SRAM2_CSn 112K E0000-FBFFF A22_CS9* PERI_CSn FC000-FFFFF A19_CS6* DPRAM_CSn FC000-FC7FF BR_CS0* DUARTn FC800-FC80F FC810...
  • Page 29: Graphics Microprocessor Address Map

    BENDIX/KING KLN 94 4.3.4.2.7 Graphics Microprocessor The Graphics microprocessor handles two main functions within the KLN 94. The first function is the interface to the LCD display. The majority of the data shown on the display is generated from the Host Microprocessor and passed to the Graphics microprocessor via the Dual Port SRAM (U5008).
  • Page 30: Graphics Microprocessor Interrupts

    BENDIX/KING KLN 94 LABEL DESCRIPTION G_WDTOUT Goes high when internal watchdog times out. INT0 CF_READY Goes high when the Compact Flash card is ready for the next data transfer. INT1 CF_PRESENT Goes high when the Compact Flash card is inserted into the socket.
  • Page 31 BENDIX/KING KLN 94 During program and erasing of the flash memory devices, a VPP of +5VDC will be supplied to the VPP signal line by U5003 pin 13 when HW_PGM_EN is pulled high by the U5029 decode logic device. This is done one of two ways, either when a programming adapter is connected to the J5102 JTAG port connector or by pressing the CURSOR and ENT keys simultaneously on the front panel at the time power is applied to the unit.
  • Page 32 BENDIX/KING KLN 94 4.3.4.2.12.2.2 Generation of control signals for buffering and multiplexing of the 386EX data bus, PERIPH_BUS, and CF_BUS. This avoids PERIPH bus contention with a possible previous PERIPH read operation. 4.3.4.2.12.2.3 Generation of customized RDn and WRn signals for PERIPH_BUS and CF_BUS accesses.
  • Page 33 BENDIX/KING KLN 94 4.3.4.2.12.3 Main EPLD Functionality The Main logic is spread across three EPLDs identified as MAIN1 (U5029), MAIN2 (U5041), and MAIN3 (U5023) on the schematic. Refer to other sections of this document for discussion of spe- cific functions assigned to the MAIN EPLDs. The following paragraphs give an overview of the functions.
  • Page 34 BENDIX/KING KLN 94 The DISCRETE_CS2n signal will be asserted low when the MAIN_DISCRETE_CSn is low, the MAIN_ADDRESS_BUS1 is high, and the other two MAIN_ADDRESS_BUS signals are low. 4.3.4.2.12.5 Main 2 EPLD Controller The MAIN2 EPLD controller holds the Display Video decoding, Audio Tone/Clock Generator, and some discrete line decoding.
  • Page 35 BENDIX/KING KLN 94 Three 8 bit latches are connected to the microprocessor data bus. An independent DISCRETE_CSn signal for each latch is controlled by the WRn signal. If WRn is low and the ap- propriate DISCRETE_CSn signal is low, the data from the DATA_BUS will be latched to the ap- propriate output pin.
  • Page 36 BENDIX/KING KLN 94 CR5015 removes its negative cycle before the internal ADC of the Host microprocessor samples it. Q5021 and R5180 are used to select the bias of the input signal. The bias is currently set to 0V. 4.3.4.2.17 Dimming Pot control The DIM_POT_SENSE circuitry consist of a 5VREF signal at one input to the pot.
  • Page 37: Peripheral Chip Selects

    BENDIX/KING KLN 94 This limits the sinking current of Q5013-B to approximately 350mA. When pin 15 of U5013 is low, Q5013-B will be turned off. 4.3.4.2.23 DUART and RS-232 Interface DUART U5042 provides two asynchronous receiver-transmitters. It is used for serial communica- tion between the Host microprocessor and the GPS PXpress Card Receiver.
  • Page 38 BENDIX/KING KLN 94 U5043-C and U5043-D are connected to the external lighting bus signals LIGHTING_28V_LO and LIGHTING_14V. The inverting summing amplifier U5043-D uses R5201, R5122, and R5107 to scale the voltage. U5043-C filters and inverts the DC voltage level so the Host microprocessor can use this voltage to control the intensity of the button and nomenclature backlighting LEDs.
  • Page 39 BENDIX/KING KLN 94 Level shifter transistors Q5008 and Q5011 permit the standard 5V logic of the Host microproces- sor to connect the drive transistors to the -12V supply rail during the active low state. Resistors R5136, R5140, R5006, R5141, R5145, R5147 and R5146 supply the needed bias currents. Clamp transistor Q5005 is turned on by the GRAPHICS_RESET signal to prevent bursts of light during that period of start-up when the microprocessor is not initialized.
  • Page 40 BENDIX/KING KLN 94 SECTION V MAINTENANCE INTRODUCTION This section contains the test, alignment, troubleshooting and disassembly/assembly procedures for the KLN 94. Before maintenance is attempted, it is advisable to have a thorough understand- ing of the Theory of Operation. TEST AND ALIGNMENT The final test procedure of section 5.2.4 shall be followed to determine if the KLN 94 is operating...
  • Page 41 A power supply source for the GPS unit. This source may be the aircraft or an ex- ternal supply (if the KLN 94 is removed from the aircraft). For an external supply, Honeywell recommends the following: Commander 2000-K Desktop Control Station: Lone Star Aviation Corporation 804 North Great S.
  • Page 42 BENDIX/KING KLN 94  5.2.3.1.3 Installing the Windows -based GPS Database Loader To install the GPS Database Loader from CD ROM, perform the following steps:  Start the computer and boot to Microsoft Windows 95 / 98 / 2000 (or higher) or Win- ...
  • Page 43 Select GPS Database Loader. Click the "add/remove" button. Click ‘yes’ to confirm. After installation, store the Honeywell KLN 94 Application Software CD-ROM in a safe place. It will only be needed if re-installation is required. 5.2.3.1.4 Updating the Software in a KLN 94 GPS ...
  • Page 44 BENDIX/KING KLN 94 When prompted, place the KLN 94 in Program Mode. This can be accomplished by pressing and holding the "ENT" and "CRSR" buttons while powering on the KLN 94. The KLN 94 should display "Please Program". When communication between the PC and the KLN 94 is established, the KLN 94 should display a "Loading.."...
  • Page 45 BENDIX/KING KLN 94 Note: If communication is not established between the GPS unit and the PC, check is the cable connection. If it is secure, try a different COM port (option C on the PC menu). (11) Once communication has been established, it will take approximately 6 minutes to update the software in the KLN 94.
  • Page 46 BENDIX/KING KLN 94 DEV CAL VERTICAL Press MSG TST 6 to activate Press the “MSG” button to activate alignment of the Vertical Deviation Circuit. Turn the right outer knob, of the KLN 94 front panel, to get 0 ± 2.0mV between VER- TICAL DEV +UP (P942-13) and VERTICAL DEV +DOWN (P942-14), on the digital voltmeter.
  • Page 47 BENDIX/KING KLN 94 Disassemble the KLN 94 to allow a small Philips-head screwdriver to access the contrast adjustment Variable Resistor. This Variable Resistor is labeled “VR1”, and is located near the bottom center on the printed circuit card of the 043-05012- 01 LCD Color Display.
  • Page 48 BENDIX/KING KLN 94 Set the date and time to the present date and GMT. 5.2.4.4 UNIT CURRENT DRAIN TEST Attach a DC Ammeter to the unit. Turn the unit power on (with no superflags set), fan on, LCD and button backlighting at full bright, and aircraft power set to 27.5V dc.
  • Page 49 BENDIX/KING KLN 94 Press the ALT button on the unit. The annunciators should toggle between the high and low states each time the ALT button is pressed. If no failure is indicated, check “OK” on the Final Data Sheet. Press the button labeled DIR (DIRECT TO) on the unit. Check for a DC voltage between (-100mV and -900mV) or (100mV and 900mV) on the TO/FROM FLAG output (THTP13, THTP14).
  • Page 50 BENDIX/KING KLN 94 NOTE: Baro must be set to 29.92”. Set the Gillham Altitude switches according to the table below. Verify that the alti- tude is the same as indicated in the table. SWITCH GILLHAM ALTITUDE INPUT SWITCH 24,300 Ft. ±10 Ft.
  • Page 51 BENDIX/KING KLN 94 If no failures are indicated, check “OK” on the Final Data Sheet. 5.2.4.10 ANNUNCIATOR OUTPUT TESTS Using the Right inner knob bring up test page 9 (TST 9). Press CRSR. Using right inner and outer knob, toggle the annunciators at the unit. Check for a corresponding indication at the test harness.
  • Page 52 BENDIX/KING KLN 94 NOTE: All Checks for this test will be across test points THTP6 and THTP7 (TST 9). Set S2 to Vertical, toggle the VERT FLAG to ON (on the Tst 9 page), and check for a DC voltage of not more than 50mV. The corresponding superflag will be OFF. Toggle the VERT FLAG OFF (on the Tst 9 page) and check for a DC voltage be- tween 350mV and 900mV.
  • Page 53 BENDIX/KING KLN 94 N/V BATTERY 3.7V P/S 5V 5.0V P/S RF 5V 5.1V TST +3 Verify the NV BATTERY reading is not less than 3.3VDC. If no failures are indicated, record the voltage reading on the Final Data Sheet. Verify the DIGITAL 5V reading is between +4.75VDC and 5.25VDC. If no failures are indicated, record the voltage reading on the Final Data Sheet.
  • Page 54 BENDIX/KING KLN 94 DISPLAY TEST PATTERNS Use CLR button to sequence patterns TST 2 To check button lighting, set the lighting to 14V. Then, set the lighting to 28V. Assess the display for missing pixels. Check display dimming. Display will be fully dimmed with dimming knob completely counter-clockwise and fully bright with the knob completely clockwise.
  • Page 55 BENDIX/KING KLN 94 ALTITUDE ALERT AUDIO ON HALF VOLUME DC ROLL STEERING POSITIVE TST 5 Connect a frequency counter to the ALT ALERT AUDIO output (THTP15, THTP16). Check for a reading of 1000Hz ±100Hz. If no failure is indicated, record the frequency reading on the Final Data Sheet. Connect an oscilloscope to the ALT ALERT AUDIO output (THTP15, THTP16).
  • Page 56 BENDIX/KING KLN 94 Press the NRST button on the unit. If the test is passed, the following message will be displayed. Config Module Test Passed TST 10 If the test fails, the following message will be displayed. Config Module Test Failed TST 10 If no failure is indicated, check “OK”...
  • Page 57 BENDIX/KING KLN 94 __1_nm ------- M>LEG AUX +2 Two or more satellites should be acquired, an Sg of more than 4, and a HIT of GD will be displayed after 5 minutes of run time. Turn the right inner knob to the AUX +1 page. It should display the present state of the GPS receiver as NAV D and an estimated position error of not more than 0.124nm.
  • Page 58 BENDIX/KING KLN 94 FINAL TEST DATA SHEET 5.2.4.2 UNIT SOFTWARE VERSION Graphics Code <Enter part number here _____________> _______ OK HOST Code <Enter part number here _____________> _______ OK 5.2.4.3 CLOCK SETTING _______ OK 5.2.4.4 UNIT CURRENT DRAIN TESTS Unit Current Drain 785mA _______ mA 14V Light Bus Current Drain <1mA _______ OK...
  • Page 59 BENDIX/KING KLN 94 5.2.4.16 UNIT BUILT-IN SELF TEST _______ OK 5.2.4.17 AUDIO OUTPUT AND DC ROLL STEERING TEST 1000Hz ±100Hz Audio Output Frequency _______ Hz Audio Output At Full Volume 8.4Vp-p to 12.4Vp-p _______ Vp-p Audio Output At Half Volume 4.2Vp-p to 6.8Vp-p _______ Vp-p Audio Output Off <100mVp-p _______ Vp-p...
  • Page 60 BENDIX/KING KLN 94 OVERHAUL 5.3.1 VISUAL INSPECTION This section contains instructions and information to assist in determining, by visual inspection, the condition of the KLN 94’s major assemblies and subassemblies. These inspection procedures will assist in finding defects resulting from wear, physical damage, deterioration, or other causes. To aid inspection, detailed procedures are arranged in alphabetical order.
  • Page 61 BENDIX/KING KLN 94 Potentiometers Inspect all potentiometers for evidence of damage or loose terminals, cracked in- sulation or other irregularities. Resistors, Fixed Inspect the fixed resistors for cracked, broken, blistered, or charred bodies and loose, broken, or improperly soldered connections. On chip resistors, be especially alert for hairline cracks in the body and broken terminations.
  • Page 62 BENDIX/KING KLN 94 WARNING: OPERATIONS INVOLVING THE USE OF A CLEANING SOLVENT SHOULD BE PER- FORMED UNDER A VENTILATED HOOD. AVOID BREATHING SOLVENT VAPOR AND FUMES; AVOID CONTINUOUS CONTACT WITH THE SOLVENT. WEAR A SUITABLE MASK, GOGGLES, GLOVES, AND AN APRON WHEN NECESSARY.
  • Page 63 BENDIX/KING KLN 94 Recommended Cleaning Procedures CAUTION: DO NOT ALLOW SOLVENT TO RUN INTO SLEEVES OR CONDUIT THAT COVERS WIRES CONNECTED TO INSERT TERMI- NALS. Exterior Wipe dust cover and front panel with a lint-free cloth damp- ened with denatured alcohol. For cleaning connectors, use the following procedure.
  • Page 64 BENDIX/KING KLN 94 CAUTION: DO NOT USE SOLVENT TO CLEAN PARTS COMPOSED OF OR CONTAINING NYLON OR RUBBER GROMMETS. CLEAN THESE ITEMS WITH MILD LIQUID DISHWASHING DETERGENT AND WATER. USE DETER- GENT FOR THIS PURPOSE ONLY. CAUTION: DUPONT VERTREL SMT DOES HAVE GEN- ERAL MATERIAL COMPATIBILITY PROB- LEMS WITH POLYCARBONATE, POLYSTY- RENE, AND RUBBER.
  • Page 65 BENDIX/KING KLN 94 NOTE: Solvents may be physically applied in several ways including agitation, spraying, brushing, and vapor degreasing. The cleaning solvents and methods used shall have no deleterious effect on the parts, connections, and materials being used. If sensitive components are being used, spray is recommended.
  • Page 66 BENDIX/KING KLN 94 NOTE: When necessary to disturb the dress of wires and cables, note the positions before disturbing and re- store them to proper dress after cleaning. Blow dust from surfaces, holes, and recessesd using an air jet. Finish cleaning chassis by wiping finished surfaces with a lint-free cloth moistened with solvent.
  • Page 67 BENDIX/KING KLN 94 When repairing circuits, carefully observe lead dress and component orientation. Keep leads as short as possible and observe correct repair techniques. There are certain soldering considerations with surface mount components. The soldering iron tip should not touch the ceramic component body.
  • Page 68 BENDIX/KING KLN 94 Store and transport all MOS devices in conductive material so that all exposed leads are shorted together. Do not insert MOS devices into conventional plastic “snow” or plastic trays used for storing and transporting standard semicon- ductor devices. Ground working surfaces on workbench to protect the MOS devices.
  • Page 69 BENDIX/KING KLN 94 Insert replacement component observing correct orienta- tion. PC Board, Multi-Lead Component Removal (IC’s, etc.) Remove component by clipping each lead along both sides. Clip off leads as close to component as possible. Discard component. Heat hole from solder side and remove clipped lead from each hole.
  • Page 70 When replacing a connector, refer to the appropriate PC board assembly drawing, and follow the notes, to ensure correct mounting and mating of each connector. Crystal The use of any crystal, other than a Honeywell crystal, is considered an unautho- rized modification. Diodes Diodes used are silicon and germanium.
  • Page 71 BENDIX/KING KLN 94 WARNING REMOVE ALL POWER FROM THE UNIT BE- FORE DISASSEMBLY OF ANY MODULE. BE- SIDES BEING DANGEROUS TO LIFE, VOLT- AGE TRANSIENTS CAN CAUSE CONSIDER- ABLE DAMAGE TO THE EQUIPMENT. CAUTION EXERCISE EXTREME CARE WHEN DISCON- NECTING AND RECONNECTING MULTIPLE PIN CONNECTORS, TO ENSURE THAT THE CONNECTORS ARE NOT DAMAGED BY MIS- ALIGNMENT OF THE PINS.
  • Page 72 BENDIX/KING KLN 94 Remove two fasteners (089-06008-0004) securing Power Board heatsink to Bottom Cover assembly. Remove eight fasteners (089-05878-0004) securing Power Board assembly to Bottom Cover (047-12425-0006) assembly. Sever black and red fan wiring. Lift Cap Board Assembly (200-09639-0001) up, and off, of Bottom Cover as- sembly.
  • Page 73 BENDIX/KING KLN 94 Buttons and Backlight Assembly/Button Board Removal Perform steps outlined in steps A, C, D, and E. Remove five hex screws/washers (089-06491-0003/089-08001-0034). The Buttons and Backlight Assembly (300-09748-0001) is now separate from the Bezel and can be removed. The Button Board (200-09641-0001) is a part of this assembly and can be separated from the Light Bar (088-03408-0001) and the Keypad (088-03409-0001).
  • Page 74 BENDIX/KING KLN 94 RF Cable Assembly Removal Perform steps outlined in step A. Remove Xpress Cover (047-10752-0000) from GPS Xpress Receiver (205- 00891-0002). Remove RF Cable Assembly (155-02811-0004) connector from J502 of the GPS Xpress Receiver Assembly. Remove two fasteners (089-06004-0003) securing RF Cable Assembly (155- 02811-0004) connector to rear of the Top Cover (047-12426-0006).
  • Page 75 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 5-36 15599M00.JA Rev 0, Sept/2000...
  • Page 76 BENDIX/KING KLN 94 FIGURE 5-1 KLN 89/89B/94 TEST HARNESS (Sheet 1 of 3) Rev 0, Sept/2000 15599M00.JWA Page 5-37...
  • Page 77 BENDIX/KING KLN 94 FIGURE 5-1 KLN 89/89B/94 TEST HARNESS (Sheet 2 of 3) Rev 0, Sept/2000 15599M00.JWA Page 5-39...
  • Page 78 BENDIX/KING KLN 94 FIGURE 5-1 KLN 89/89B/94 TEST HARNESS (Sheet 3 of 3) Rev 0, Sept/2000 15599M00.JWA Page 5-41...
  • Page 79 BENDIX/KING KLN 94 FIGURE 5-2 PC INTERFACE DRAWING/SOFTWARE UPDATE TOOL KIT Rev 0, Sept/2000 15599M00.JWA Page 5-43...
  • Page 80 BENDIX/KING KLN 94 FIGURE 5-3 KTS 143 TEST FIXTURE Rev 0, Sept/2000 15599M00.JWA Page 5-45...
  • Page 81 BENDIX/KING KLN 94 FIGURE 5-4 KI 229 RADIO MAGNETIC INDICATOR Rev 0, Sept/2000 15599M00.JWA Page 5-47...
  • Page 82 BENDIX/KING KLN 94 FIGURE 5-5 KLN 94 MAIN BOARD TROUBLESHOOTING FLOWCHART (Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 5-49...
  • Page 83 BENDIX/KING KLN 94 FIGURE 5-5 KLN 94 MAIN BOARD TROUBLESHOOTING FLOWCHART (Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 5-51...
  • Page 84: Kln 94 Power Board Troubleshooting Flowchart

    BENDIX/KING KLN 94 FIGURE 5-6 KLN 94 POWER BOARD TROUBLESHOOTING FLOWCHART (Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 5-53...
  • Page 85 BENDIX/KING KLN 94 FIGURE 5-6 KLN 94 POWER BOARD TROUBLESHOOTING FLOWCHART (Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 5-55...
  • Page 86 Each parts list is followed by a component location drawing. Parts identified in this IPL by Honeywell part number meet design specifications for this equipment and are the recommended replacement parts. Warranty informa- tion concerning Honeywell replacement parts is contained in Service Memo #1, P/N 600-08001-00XX.
  • Page 87 BENDIX/KING KLN 94 Abbreviation Name Transistor Resistor Thermistor Switch Transformer Test Point Component Network, Integrated Circuit, Circuit Assembly Photocell/Vacuum Tube Waveguide Crystal Table 1 (Continued) Abbreviations Page 6-2 15599M00.JA Rev 0, Sept/2000...
  • Page 88: Sample Parts List

    BENDIX/KING KLN 94 Sample Parts List The above is only a sample. The actual format and style may vary slightly. A ‘Find Number’ column, when shown, references selected items on the BOM’s accompa- nying Assembly Drawing. This information does not apply to every BOM. There- fore, a lack of information in this column, or a lack of this column, should not be interpreted as an omission.
  • Page 89 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-4 15599M00.JA Rev 0, Sept/2000...
  • Page 90 BENDIX/KING KLN 94 KLN 94 FINAL ASSEMBLY AND SYSTEM SOFTWARE 069-01034-0101 KLN 94 FINAL ASSY. Rev. E --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0101 --------------------------------------------------------------- 000-01045-0101 KLN94 GPS PRODUCT 004-02179-4000 KLN 94 MINIMUM PER 015-00220-0003 BATTERY, LITHIUM, 1.00 030-03417-0001 CONN, HDR, RECPT, 2.00 030-03417-0002...
  • Page 91 BENDIX/KING KLN 94 206-00410-0102 KLN 94 SYSTEM BOOT SOFTWARE Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0102 --------------------------------------------------------------- 057-05287-0102 UNIT SFTWR V0102 1.00 205-00891-0002 GPS PXPRESS - PROG 1.00 205-00942-0003 KLN94 MAIN BOARD H 1.00 222-30470-0001 KLN94 BOOT SW SYST 206-00416-0101 KLN 94 SYSTEM APP SOFTWARE Rev.
  • Page 92: Kln 94 Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-2 KLN 94 ASSEMBLY DRAWING (P/N 300-09714-0000 Rev. E, Sheet 1 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-7...
  • Page 93 BENDIX/KING KLN 94 FIGURE 6-2 KLN 94 ASSEMBLY DRAWING (P/N 300-09714-0000 Rev. E, Sheet 2 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-9...
  • Page 94 BENDIX/KING KLN 94 FIGURE 6-2 KLN 94 ASSEMBLY DRAWING (P/N 300-09714-0000 Rev. E, Sheet 3 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-11...
  • Page 95 BENDIX/KING KLN 94 FIGURE 6-2 KLN 94 ASSEMBLY DRAWING (P/N 300-09714-0000 Rev. E, Sheet 4 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-13...
  • Page 96 BENDIX/KING KLN 94 200-09673-0001 KLN 94 FRONT PANEL ASSY. Rev. C --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- J946 030-03418-0001 CONN, AUDIO, JACK, 1.00 P5001 030-03417-0003 CONN, HDR, RECPT, 1.00 P5009 030-03417-0002 CONN, HDR, RECPT, 1.00 P9005 030-03423-0002 CONN, HDR, RECPT, 1.00 016-01097-0000...
  • Page 97 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-16 15599M00.JA Rev 0, Sept/2000...
  • Page 98: Kln 94 Front Panel Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-3 KLN 94 FRONT PANEL ASSEMBLY DRAWING (P/N 300-09673-0000 Rev. C, Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-17...
  • Page 99 BENDIX/KING KLN 94 FIGURE 6-3 KLN 94 FRONT PANEL ASSEMBLY DRAWING (P/N 300-09673-0000 Rev. C, Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-19...
  • Page 100 BENDIX/KING KLN 94 200-09748-0001 KLN 94 BUTTON/BACKLIGHT ASSY. Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- 088-03408-0001 LIGHT BAR ACTUATOR 1.00 088-03409-0001 SILICONE KEYPAD 1.00 200-09641-0001 BUTTON BOARD 1.00 300-09748-0000 BUTTONS & BACKLIGH Rev 0, Sept/2000 15599M00.JA Page 6-21...
  • Page 101 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-22 15599M00.JA Rev 0, Sept/2000...
  • Page 102: Kln 94 Front Panel Buttons/backlight Drawing

    BENDIX/KING KLN 94 FIGURE 6-4 KLN 94 FRONT PANEL BUTTONS/BACKLIGHT DRAWING (P/N 300-09748-0000 Rev. -) Rev 0, Sept/2000 15599M00.JWA Page 6-23...
  • Page 103 BENDIX/KING KLN 94 200-09641-0001 KLN 94 BUTTON BOARD Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- DS1001 007-06580-0001 DIODE, LED, AMBER 1.00 DS1002 007-06580-0001 DIODE, LED, AMBER 1.00 DS1003 007-06580-0001 DIODE, LED, AMBER 1.00 DS1004 007-06580-0001 DIODE, LED, AMBER 1.00 DS1005 007-06580-0001...
  • Page 104 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-26 15599M00.JA Rev 0, Sept/2000...
  • Page 105: Kln 94 Button Board Drawing

    BENDIX/KING KLN 94 FIGURE 6-5 KLN 94 BUTTON BOARD DRAWING (P/N 300-09641-0000 Rev. A) Rev 0, Sept/2000 15599M00.JWA Page 6-27...
  • Page 106: Kln 94 Button Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-6 KLN 94 BUTTON BOARD SCHEMATIC (P/N 002-09641-0000 Rev. -) Rev 0, Sept/2000 15599M00.JWA Page 6-29...
  • Page 107 BENDIX/KING KLN 94 200-09715-0001 KLN 94 SWITCH BOARD ASSY. Rev. B --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- 012-05072-0000 FOAM TAPE 1.50 016-01013-0000 VAC GREASE DC 976 1.00 025-00018-0099 WIRE 26 WHT 2.00 031-00372-0001 SWITCH SLIDE SPDT 1.00 047-10416-0001 SW BRKT KLX135 1.00...
  • Page 108 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-32 15599M00.JA Rev 0, Sept/2000...
  • Page 109: Kln 94 Front Mechanical Switch Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-7 KLN 94 FRONT MECHANICAL SWITCH ASSEMBLY DRAWING (P/N 300-09715-0000 Rev. B) Rev 0, Sept/2000 15599M00.JWA Page 6-33...
  • Page 110 BENDIX/KING KLN 94 6.10 200-09640-0001 KLN 94 SWITCH BOARD Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C7001 106-05103-0057 CAP CH 10KX7R/100V 1.00 C7002 106-05103-0057 CAP CH 10KX7R/100V 1.00 C7003 106-05103-0057 CAP CH 10KX7R/100V 1.00 C7004 106-05103-0057 CAP CH 10KX7R/100V 1.00 C7005...
  • Page 111 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- 009-09640-0001 PCB, SWITCH BOARD 1.00 150-00004-0010 TUBING TFLN 22AWG 1.00 192-09640-0001 KLN 94 SWITCH BD 300-09640-0000 KLN 94 SWITCH BOA Page 6-36 15599M00.JA Rev 0, Sept/2000...
  • Page 112: Kln 94 Switch Board Drawing

    BENDIX/KING KLN 94 FIGURE 6-8 KLN 94 SWITCH BOARD DRAWING (P/N 300-09640-0000 Rev. C, Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-37...
  • Page 113 BENDIX/KING KLN 94 FIGURE 6-8 KLN 94 SWITCH BOARD DRAWING (P/N 300-09640-0000 Rev. C, Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-39...
  • Page 114: Kln 94 Switch Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-9 KLN 94 SWITCH BOARD SCHEMATIC (P/N 002-09640-0000 Rev. A, Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-41...
  • Page 115 BENDIX/KING KLN 94 FIGURE 6-9 KLN 94 SWITCH BOARD SCHEMATIC (P/N 002-09640-0000 Rev. A, Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-43...
  • Page 116 BENDIX/KING KLN 94 6.11 205-00891-0002 KLN 94 GPS XPRESS PROGRAMMED BOARD Rev. B --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0002 --------------------------------------------------------------- REF100 300-08825-0000 GPS XPRESS ASSY 057-05252-0891 IDT 205-00891-0000 1.00 057-05335-0002 DECAL 205 DASH 02 1.00 125-00937-0002 P-XPRESS PROGRAM D 1.00 193-00891-0002 PXPRESS ASSY...
  • Page 117 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0000 --------------------------------------------------------------- C522 106-05104-0037 CAP CH 100KX7R/25V 1.00 C523 106-05104-0037 CAP CH 100KX7R/25V 1.00 C524 106-05104-0037 CAP CH 100KX7R/25V 1.00 C525 106-05102-0016 CAP CH 1K NPO/50V 1.00 C526 106-05030-0020 CH 3.0PF NPO/100V 1.00 C527 106-05030-0020...
  • Page 118 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0000 --------------------------------------------------------------- Q501 007-00903-0000 2N7002 MOSFET 1.00 Q502 007-00933-0000 MMBT2369 1.00 R501 139-04751-0000 RES CH 4.75K EW 1% 1.00 R502 139-04751-0000 RES CH 4.75K EW 1% 1.00 R503 139-04751-0000 RES CH 4.75K EW 1% 1.00 R504 139-04751-0000...
  • Page 119 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0000 --------------------------------------------------------------- 047-10721-0001 GPS XPRESS SHIELD 1.00 193-00891-0001 P XPRESS ASSEMBLY 193-00891-0002 PXPRESS ASSY 300-08825-0000 GPS XPRESS ASSY Page 6-48 15599M00.JA Rev 0, Sept/2000...
  • Page 120: Kln 94 Gps Xpress Board Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-10 KLN 94 GPS XPRESS BOARD ASSEMBLY DRAWING (P/N 300-08825-0000 Rev. AA) Rev 0, Sept/2000 15599M00.JWA Page 6-49...
  • Page 121: Kln 94 Gps Xpress Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-11 KLN 94 GPS XPRESS BOARD SCHEMATIC (P/N 002-08825-0000 Rev. 4, Sheet 1 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-51...
  • Page 122 BENDIX/KING KLN 94 FIGURE 6-11 KLN 94 GPS XPRESS BOARD SCHEMATIC (P/N 002-08825-0000 Rev. 4, Sheet 2 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-53...
  • Page 123 BENDIX/KING KLN 94 FIGURE 6-11 KLN 94 GPS XPRESS BOARD SCHEMATIC (P/N 002-08825-0000 Rev. 4, Sheet 3 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-55...
  • Page 124 BENDIX/KING KLN 94 6.12 205-00942-0003 KLN 94 PROGRAMMED MAIN BOARD Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0003 --------------------------------------------------------------- REF100 300-09638-0000 KLN 94 MAIN BOA 057-05252-0942 KLN 94 SOFTWARE LA 1.00 057-05335-0003 DECAL 205 DASH 03 1.00 125-01011-0001 KLN 94 HOST BOOT S 1.00 125-01012-0002...
  • Page 125 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C5035 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5036 106-05102-0026 CAP CH 1K NPO/100V 1.00 C5037 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5038 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5039 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5040 096-01186-0036...
  • Page 126 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C5086 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5087 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5088 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5089 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5090 106-05103-1047 CAP CH 10KX7R/50V 1.00 C5091 106-05103-1047...
  • Page 127 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C5138 096-01186-0010 CAP 15UF 10V 10% 1.00 C5139 096-01186-0036 CAP 10UF 35V 10% 1.00 C5140 096-01186-0010 CAP 15UF 10V 10% 1.00 C5142 106-05102-0026 CAP CH 1K NPO/100V 1.00 C5144 106-04104-0047 CH 100KX7R/50V...
  • Page 128 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C5191 106-04104-0047 CH 100KX7R/50V 1.00 C5192 106-05102-0026 CAP CH 1K NPO/100V 1.00 C5193 106-05102-0026 CAP CH 1K NPO/100V 1.00 C5194 106-05102-0026 CAP CH 1K NPO/100V 1.00 C5195 106-04221-0026 CAP CH220PFNPO/100 1.00 C5196...
  • Page 129 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- CR5008 007-06223-0000 DIO DA204K 1.00 CR5009 007-06223-0000 DIO DA204K 1.00 CR5010 007-06223-0000 DIO DA204K 1.00 CR5011 007-06223-0000 DIO DA204K 1.00 CR5012 007-06223-0000 DIO DA204K 1.00 CR5013 007-06223-0000 DIO DA204K 1.00 CR5014 007-06223-0000...
  • Page 130 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- Q5020 007-00467-0000 XSTR S NPN MMBTA06 1.00 Q5021 007-00903-0000 2N7002 MOSFET 1.00 Q5022 007-00467-0000 XSTR S NPN MMBTA06 1.00 Q5023 007-00466-0000 XSTR S PNP MMBTA56 1.00 Q5024 007-00903-0000 2N7002 MOSFET 1.00 Q5025...
  • Page 131 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R5033 139-02001-0010 RES CH 2.00K TW 1% 1.00 R5034 139-01000-0010 RES CH 100 .1W 1% 1.00 R5035 139-01003-0010 RES CH 100K TW 1% 1.00 R5036 139-08062-0010 RES CH 80.6K TW 1% 1.00 R5037 139-02433-0010...
  • Page 132 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R5084 139-01472-0010 RES CH 14.7K .1W 1 1.00 R5085 139-01003-0010 RES CH 100K TW 1% 1.00 R5086 139-01472-0010 RES CH 14.7K .1W 1 1.00 R5087 139-01472-0010 RES CH 14.7K .1W 1 1.00 R5088 139-01472-0010...
  • Page 133 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R5136 139-01001-0010 RES CH 1000 .1W 1% 1.00 R5137 139-01000-0010 RES CH 100 .1W 1% 1.00 R5138 139-01000-0010 RES CH 100 .1W 1% 1.00 R5139 139-00221-0010 RES CH 22.1 TW 1% 1.00 R5140 139-00000-0014...
  • Page 134 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R5187 139-08062-0010 RES CH 80.6K TW 1% 1.00 R5188 139-01001-0010 RES CH 1000 .1W 1% 1.00 R5189 139-02001-0010 RES CH 2.00K TW 1% 1.00 R5190 139-00221-0010 RES CH 22.1 TW 1% 1.00 R5191 139-00000-0014...
  • Page 135 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- U5031 120-02502-0012 PROC 68C16 144PQFP 1.00 U5032 120-08231-0001 DISCRETE INPUT CIR 1.00 U5033 120-02716-0006 BUFFER, TRI-STATE 1.00 U5034 120-02546-0010 CLOCK, SERIAL TIME 1.00 U5035 120-08231-0001 DISCRETE INPUT CIR 1.00 U5036 120-03174-0014...
  • Page 136: Kln 94 Main Board Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-12 KLN 94 MAIN BOARD ASSEMBLY DRAWING (P/N 300-09638-0000 Rev. F, Sheet 1 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-69...
  • Page 137 BENDIX/KING KLN 94 FIGURE 6-12 KLN 94 MAIN BOARD ASSEMBLY DRAWING (P/N 300-09638-0000 Rev. F, Sheet 2 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-71...
  • Page 138 BENDIX/KING KLN 94 FIGURE 6-12 KLN 94 MAIN BOARD ASSEMBLY DRAWING (P/N 300-09638-0000 Rev. F, Sheet 3 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-73...
  • Page 139 BENDIX/KING KLN 94 FIGURE 6-12 KLN 94 MAIN BOARD ASSEMBLY DRAWING (P/N 300-09638-0000 Rev. F, Sheet 4 of 4) Rev 0, Sept/2000 15599M00.JWA Page 6-75...
  • Page 140 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 1 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-77...
  • Page 141 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 2 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-79...
  • Page 142 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 3 of 14 Rev 0, Sept/2000 15599M00.JWA Page 6-81...
  • Page 143 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 4 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-83...
  • Page 144 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 5 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-85...
  • Page 145 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 6 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-87...
  • Page 146 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 7 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-89...
  • Page 147 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 8 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-91...
  • Page 148 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 9 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-93...
  • Page 149 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 10 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-95...
  • Page 150 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 11 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-97...
  • Page 151 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 12 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-99...
  • Page 152 BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 13 of 14 Rev 0, Sept/2000 15599M00.JWA Page 6-101...
  • Page 153: Kln 94 Main Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-13 KLN 94 MAIN BOARD SCHEMATIC (P/N 002-09638-0000 Rev. F, Sheet 14 of 14) Rev 0, Sept/2000 15599M00.JWA Page 6-103...
  • Page 154 BENDIX/KING KLN 94 6.13 200-09665-0001 KLN 94 SUPPRESSOR BOARD Rev. - --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- CR4001 007-05241-0002 TRNSRB 150W 40V 1.00 CR4002 007-05241-0205 TRNSRB 1500W 24V 1.00 CR4003 007-05241-0205 TRNSRB 1500W 24V 1.00 CR4004 007-05241-0203 TRNSRB 1500W 15V 1.00 CR4005...
  • Page 155 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-106 15599M00.JA Rev 0, Sept/2000...
  • Page 156: Kln 94 Suppressor Board Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-14 KLN 94 SUPPRESSOR BOARD ASSEMBLY DRAWING (P/N 300-09665-0000 Rev. -) Rev 0, Sept/2000 15599M00.JWA Page 6-107...
  • Page 157: Kln 94 Suppressor Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-15 KLN 94 SUPPRESSOR BOARD SCHEMATIC (P/N 002-09665-0000 Rev. -) Rev 0, Sept/2000 15599M00.JWA Page 6-109...
  • Page 158 BENDIX/KING KLN 94 6.14 200-09642-0001 KLN 94 BUS I/O BOARD Rev. A --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C3001 106-05103-0057 CAP CH 10KX7R/100V 1.00 C3002 106-05103-0057 CAP CH 10KX7R/100V 1.00 C3003 106-05103-0057 CAP CH 10KX7R/100V 1.00 C3004 106-05103-0057 CAP CH 10KX7R/100V 1.00...
  • Page 159 BENDIX/KING KLN 94 THIS PAGE IS RESERVED Page 6-112 15599M00.JA Rev 0, Sept/2000...
  • Page 160: Kln 94 Bus I/o Board Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-16 KLN 94 BUS I/O BOARD ASSEMBLY DRAWING (P/N 300-09642-0000 Rev. B) Rev 0, Sept/2000 15599M00.JWA Page 6-113...
  • Page 161: Kln 94 Bus I/o Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-17 KLN 94 BUS I/O BOARD SCHEMATIC (P/N 002-09642-0000 Rev. -) Rev 0, Sept/2000 15599M00.JWA Page 6-115...
  • Page 162 BENDIX/KING KLN 94 6.15 200-09639-0001 KLN 94 POWER BOARD Rev. B --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C6001 097-00225-0008 CAP, HIGH CAPACITY 1.00 C6002 096-01186-0036 CAP 10UF 35V 10% 1.00 C6003 106-04104-0047 CH 100KX7R/50V 1.00 C6004 106-04104-0047 CH 100KX7R/50V 1.00 C6005...
  • Page 163 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- C6052 106-04104-0047 CH 100KX7R/50V 1.00 C6053 106-04104-0047 CH 100KX7R/50V 1.00 C6054 106-05103-0057 CAP CH 10KX7R/100V 1.00 C6055 106-04104-0047 CH 100KX7R/50V 1.00 C6056 106-05103-0057 CAP CH 10KX7R/100V 1.00 C6057 096-01186-0012 CAP 1.0UF 16V 10% 1.00...
  • Page 164 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- J6008 030-03386-0002 CONN, HDR, MALE, S 1.00 L6001 019-02753-1680 COIL 68UH 1.26A 1.00 L6002 019-02753-1680 COIL 68UH 1.26A 1.00 L6003 019-02369-0001 IND 15UH 1.00 L6004 019-02753-1220 COIL 22UH 2.2A 1.00 L6005 013-00172-0001...
  • Page 165 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R6012 139-03320-0010 RES CH 332 .1W 1% 1.00 R6013 139-01002-0010 RES CH 10K TW 1% 1.00 R6014 139-00221-0010 RES CH 22.1 TW 1% 1.00 R6015 139-00221-0010 RES CH 22.1 TW 1% 1.00 R6016 139-04992-0010...
  • Page 166 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- R6063 139-04992-0010 RES SM 49.9K 1/10W 1.00 R6064 139-01502-0010 RES CH 15 K .1W 1% 1.00 R6065 139-01000-0010 RES CH 100 .1W 1% 1.00 R6066 139-01372-0010 RES SM 13.7K 1/10W 1.00 R6067 139-02002-0010...
  • Page 167 BENDIX/KING KLN 94 --------------------------------------------------------------- SYMBOL PART NUMBER FIND NO DESCRIPTION 0001 --------------------------------------------------------------- 150-00032-0010 TBG SHRNK 1/2&5/8 150-00034-0010 TBG SHRNK 3/4&7/8 1.60 192-09639-0001 KLN 94 POWER BD 300-09639-0000 KLN 94 POWER BOAR Page 6-122 15599M00.JA Rev 0, Sept/2000...
  • Page 168: Kln 94 Power Board Assembly Drawing

    BENDIX/KING KLN 94 FIGURE 6-18 KLN 94 POWER BOARD ASSEMBLY DRAWING (P/N 300-09639-0000 Rev. C, Sheet 1 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-123...
  • Page 169 BENDIX/KING KLN 94 FIGURE 6-18 KLN 94 POWER BOARD ASSEMBLY DRAWING (P/N 300-09639-0000 Rev. C, Sheet 2 of 2) Rev 0, Sept/2000 15599M00.JWA Page 6-125...
  • Page 170: Kln 94 Power Board Schematic

    BENDIX/KING KLN 94 FIGURE 6-19 KLN 94 POWER BOARD SCHEMATIC (P/N 002-09639-0000 Rev. B, Sheet 1 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-127...
  • Page 171 BENDIX/KING KLN 94 FIGURE 6-19 KLN 94 POWER BOARD SCHEMATIC (P/N 002-09639-0000 Rev. B, Sheet 2 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-129...
  • Page 172 BENDIX/KING KLN 94 FIGURE 6-19 KLN 94 POWER BOARD SCHEMATIC (P/N 002-09639-0000 Rev. B, Sheet 3 of 3) Rev 0, Sept/2000 15599M00.JWA Page 6-131...

Comments to this Manuals

Symbols: 0
Latest comments:
