Product Manual
Open the box
1
Open the box and remove the
accessories and the layer of
foam.
Open the top door, then remove packaging supports
5
and tapes.
7
Remove the screw and the plastic
piece from heated bed.
Load the filament
Please remove
1
the filament
stopper.
4
Push the filament through the filament guide tube to the hole of the
extruder and press "LOAD FILAMENT" function on the display menu.
2
Take out the printer by
holding the grip holds.
8
Remove the drip tray fixing
tapes.
2 Install the new filament
cartridge into the empty slot.
3
Remove plastic bag
and tapes.
Packing
supports x2
tapes x3
6
Remove the heated bed fixing tapes and foam.
3 Place and push to click the
cartridge locker into the slot.
4
Remove the cardboard.
9
Connect the printer to your PC
first using a USB cable then
turn on the power switch.
Tips: Pull the released arm ,then
load filament shall be easily.
ENG
A A A
B B
