Maintenance Tools
Important Safety Instruction
The maintenance tools provided should only be handled by an adult. Please keep tools away
from children. Incorrect handling or maintenance of the printer may cause damage to the product
or personal injury.
Information and usage of the advanced maintenance tools
▇ Scraper
Scraper remove the printed object from the heated bed after completion of printing.
PRINTING
(Caution: do not remove the printed object while the heated bed is hot.)
▇ Cleaning Wire
To remove the small pieces of filament left from the filament path inside the nozzle. The cleaning
wire can be used when an obstruction occurs in the filament path inside the nozzle or when the
filament cannot be pushed out while loading the filament.
(Caution: the heated bed may be hot while cleaning the filament path, please follow the instruction to descend the
heated bed position before you performing the above.)
When cleaning the printer nozzle, gears or filament path please ensure to keep hands
clear of the heated bed which may be hot.
▇ Copper Brush
To clean and remove the small pieces of filament left from the tip or surface of the extruder and
inside the drive gear. In the event of "auto-calibration failed" after several attempts, use the copper
brush to clean and remove the filament pieces from the extruder.
Specifications
FEATURES
Print Technology
Printer Head
Build Volume(W x D x H)
Print Speed
Layer Resolution Settings
Know about XYZware
2
View
Move
Rotate
Scale
Info
Remove
(Notice: Some instructions and video tutorials might require online registration to obtain authorization.)
da Vinci 1.0 3D Printer
Fused Filament Fabrication
Single Head
20 x 20 x 20 cm
60, 90, 120 mm/s
Standard
200 microns
Speed
300 microns
Ultra fast
400 microns
Custom
100-400microns
For Mac OS and Win8/8.1 user or software related topics, please
visit following webpage for further information and download the
proper XYZware version:
Import
Export
Save
Print
Settings
Help
http://support.xyzprinting.com/downloads
1
3
XYZware 1.0
one, with or without modeling skill. You can view the model in various
perspectives by importing (*.stl) file to it. It is also used to print objects from
da Vinci 3D printer.XYZware can be found in the bundle installation disc. To
check our latest software updates and further information,
please go to:
http://support.xyzprinting.com/manuals
FEATURES
da Vinci 1.0 3D Printer
Filament Diameter
1.75 mm
Nozzle Diameter
0.4 mm
AC Input
100-240V, 50~60Hz
Connectivity
USB 2.0 x 1
Display
FSTN LCM (16 Characters x 4)
Control Method
Key x 6
Indicator
Buzzer
Lighting
LED
Weight
28.5 Kg
is developed by XYZprinting Inc. It is designed for every-
ENG
-5-
