Product Manual
Load filament
DA VINCI 1 0
UTILITIES
SETTINGS
INFO
Choose"UTILITIES"
1
and press"OK" to
continue.
LOAD FILAMENT
EXTRUDER HEATING
TEMPERATURE999 C
PLEASE WAIT
Please wait for
4
extruder to reach
working temperature.
Sample print
Before you start printing, apply the glue
stick to the area of the heated bed which
corresponds to the object print size.
build sample
dEMO
KEY CHAIN
STAR VASE
3 Select one of the
samples.
Unload filament
DA VINCI 1 0
UTILITIES
SETTINGS
INFO
1 Choose "UTILITIES"
and press "OK" to
continue.
3
Upon completion of the heating of machine, please remove filament and cartridge locker.
uTILITIES
CHANGE FILAMENT
HOME AXES
JOG MODE
Choose "CHANGE FILAMENT"
2
and press "OK".
LOADING
PLEASE WAIT
Please wait for
5
completion of
filament loading.
DA VINCI 1 0
UTILITIES
SETTINGS
INFO
Choose "UTILITIES"
1
and press "OK" to
continue.
START BUILDING
no
yes
4
Select "YES" and press
"OK" to start printing.
uTILITIES
CHANGE FILAMENT
HOME AXES
JOG MODE
Choose "CHANGE FILAMENT"
2
and press "OK".
CHANGE FILAMENT
LOAD FILAMENT
UNLOAD FILAMENT
Choose "LOAD FILAMENT"
3
and press "OK".
CHECK FILAMENT
OUT FROM NOZZLE
BACK TO RETRYV
OK TO RETURN
Check filament comes out from
6
the nozzle and press "OK" to go
back to main menu.
UTILITIES
JOG MODE
auto CALIBRATe
BUILD SAMPLE
Choose "BUILD
2
SAMPLE" and press
"OK" to continue.
5
After printing is complete, power off the
printer. Once the da Vinci has cooled use
a damp cloth to clean the heated bed.
CHANGE FILAMENT
LOAD FILAMENT
UNLOAD FILAMENT
Choose "UNLOAD FILAMENT"
3
and press "OK".
ENG
