- Page 1 Vinci 1.0 Pro User Manual Product Safety Product Description Printer screen menu, functions and messages Functional operations and descriptions Print Support Details Product Model: da Vinci 1.0 Professional...
-
Page 2: Product Safety
Vinci 1.0 Pro The purpose of this user manual is to help users understand and use the da Vinci 1.0 Professional 3D printer correctly. It contains the operating instructions, maintenance information and application skills of the da Vinci 1.0 Professional 3D printer. -
Page 3: Product Description
Vinci 1.0 Pro Product Description Product Overview Cartridge Slot Auto Feed System Function Key DA VINCI 1.0 Pro. 1 UTILITIES SETTINGS INFO Control Panel Extruder Module USB Port Print Bed Power Switch Power Socket Levelness of the Print Bed may be susceptible to vibration during transportation, which may influence print quality. -
Page 4: Important Safety Notes
Vinci 1.0 Pro Product Description Note: Please removal all fixed materials before turning on the printer to prevent the Open the box machine from damage Open the box and Remove all fixing tapes and Use the grip to take... -
Page 5: Display And Control Panel
Vinci 1.0 Pro Notes and Description for Use of Maintenance Tools • The following tools can be used only in an environment with guidance or monitoring by adult. Do not allow children to obtain maintenance tools in unfamiliar situations in order to avoid danger. - Page 6 Vinci 1.0 Pro Printer screen menu, functions and messages UTILITIES Installation and removal of filament, calibration of the printing bed and printing settings, including: ◆ CHANGE CART ◆ HOME AXES ◆ Z OFFSET ◆ JOG MODE ◆ CALIBRATE ◆ BUILD SAMPLE ◆...
-
Page 7: Jog Mode
Vinci 1.0 Pro JOG MODE Manually adjust the movement of X/Y/Z Axis for printer maintenance. How to move the extruder: JOG MODE UTILITIES X-AXIS [ OK ] >> EXIT X-AXIS Z OFFSET ■ [ － ] 001mm ] [ ＋ ]... -
Page 8: Change Nozzle
Vinci 1.0 Pro Select the built-in sample to be printed BUILD SAMPLE DEMO KEY CHAIN HEART Select "YES" and press "OK" KEY CHAIN START BUILDING? After completion of print, take off the print product.The print bed patch is reusable,replace the patch when it is worn out. -
Page 9: Printer Maintenance
Vinci 1.0 Pro Printer screen menu, functions and messages UTILITIES BUILD SAMPLE Printer Maintenance CHANGE NOZZLE CLEAN NOZZLE ● UTILITIES > CLEAN NOZZLE Regular cleaning of the print nozzle facilitates to not only extending service life of the printer, but also improves print quality. - Page 10 Vinci 1.0 Pro SETTINGS The basic settings of the machine, functions, selection and adjustment of printing values, including: ◆ USER FILAMENT ◆ BUZZER ◆ AUTO HEAT ◆ LANGUAGE ◆ ENERGY SAVE ◆ RESTORE DEFAULT Pro. 1 UTILITIES SETTINGS INFO...
-
Page 11: Energy Save
Vinci 1.0 Pro ENERGY SAVE LED luminaries are installed in the printing chamber. To save energy consumed, the lighting will go off after idling for 3 minutes (shown as 03M on the display) by default. SETTINGS ENERGY SAVE [ 03M ]... -
Page 12: Monitor Mode
Vinci 1.0 Pro CARTRIDGE STATS Show the remaining amount of filament (such as “REMAINING” for length information), volume of spool, color of filament and material information. Press to skip the page and press “OK” to exit. INFO CARTRIDGE STATS... - Page 13 Vinci 1.0 Pro Functional operations and descriptions Install and Load Filament UTILITIES > CHANGE CART > LOAD FILAMENT ● Install Filament Cartridge from XYZprinting ● Install Compatible filament * Print quality cannot be guaranteed if filaments from other brands are used instead.
-
Page 14: Unloading Filament
Vinci 1.0 Pro Functional operations and descriptions Unloading Filament ● UTILITIES > CHANGE CART > UNLOAD FILAMENT In unloading filament, activating the filament unloading function on the control panel of the printer 1. Wait for the extruder to heat up to operating temperature and unload the filament. -
Page 15: Print Bed Adjustment
Vinci 1.0 Pro Functional operations and descriptions Print Bed Adjustment Before first printing, please calibrate the bed to guarantee an appropriate levelness of the bed for printing. ● UTILITIES > CALIBRATE After the printer is heated up to an appro-... - Page 16 Vinci 1.0 Pro Print Transfer print file through computer software "XYZware Pro" Connect the printer and the computer with USB cable and install "XYZware Pro" in the computer to transfer print file. Import .stl, .3w files Convert to .3w file Save .stl file...
- Page 17 Vinci 1.0 Pro Print WiFi Connection The printer supports Wi-Fi connection printing. Install “XYZware Pro”, and activate Wi-Fi setting of the printer in accordance with the following instruction to switch the printer to wireless control mode, such that the print file may be subsequently transferred wirelessly.
- Page 18 Vinci 1.0 Pro Print WiFi Connection Please enter printer name (either English or numeric name), press "Scan" function to obtain wireless base station information with dropdown menu, and select the name of the wireless network you desire to connect.
- Page 19 Vinci 1.0 Pro Print From A Mobile Application 1.The mobile device needs to support wireless printing. 2.Install XYZprinting App from Android or iOS system. User Category Information Gallery My Upload Printer About Main screen Upload the To remote Printer...
- Page 20 Vinci 1.0 Pro ● Step Open the Play Store from your Android browser or Please register an account at XYZprinting official App store of iOS system to search "XYZgallery" and website before logging in. download the application to your device.
-
Page 21: Support Details
Vinci 1.0 Pro Support Details As the printer encounters issues, please refer to the following troubleshooting instruction to fix the issues. If the issue cannot be removed, please contact customer service center Error message and Action In the event of problems, related service code will be shown on the printer screen and/or software interface. Please refer to the description table of the service code for preliminary examination. - Page 22 Vinci 1.0 Pro Support Details Error Status Recommended Process Ways Try again after current task is completed, and examine the information Printer is busy displayed on screen of the printer Firmware of the printer Check internet connection / Update firmware later...
