XYZ Printing da Vinci 1.0 Product Manual page 2

Product Manual
Filament Slot
Remove the
packaging supports
USB Port
Power Switch
Power Connector
Overview
This guide provides details on how to start off your da Vinci 1.0 3D printer in the right direction. Before you can
begin printing, there are some easy procedures you need to become familiar with:
● How to open the box safely
● How to load filament
● Getting to know XYZware software
．User Quick Guide
．Glue Stick
．Installation Disc
Important Safety Instruction
●
Do not place the printer in humid or dusty environments such as bathrooms and high traffic areas.
●
Do not place the printer on a rickety surface and/or inclined position. Printer may fall down or tumble
and it may cause serious injury.
●
Do not reach inside the printer while in operation. Printer reaches high temperatures and includes
moving parts that can cause injury.
．Cartridge Locker
．Filament Cartridge
．Decorative Plate x2
PRINTING
． Scraper
． Copper Brush
． Cleaning Wire x5
ENG
Key Pad
Display Panel
Extruder Module
Z-Axis Rod
Access Door
Heated Bed
Remove the
heated bed fixing
screws and
printing module
fixers
．USB Cable
．Power Cord
