FOR YOUR REFERENCE

Specifications

D IP100H
• Power supply requirement:
Icom BP-271, BP-272 battery pack or
BP-273 battery case
• Current drain:
Less than 150 mA average
( Tx: 100 mA, Rx: 150 mA,
standby: 50 mA)
• Usable temperature range:
–10°C to +60°C (+14°F to +140°F)
• Dimensions: 58(W) × 95(H) × 26.4(D) mm
(2.3(W) × 3.7(H) × 1.0(D) inches)
(projections are not included)
• Weight:
Approximately 205 g (7.2 oz)
(with antenna and BP-271)
• Wireless LAN standard:
IEEE802.11 n/a/b/g
• Authentication and Encryption:
WEP (64/128 bit),
WPA-PSK (TKIP/AES),
WPA2-PSK (TKIP/AES)
• Protocol: TCP/IP
• Communication range:
Frequency band Internal antenna External antenna
2.4 GHz band
90 m (295 ft)
5 GHz band
• Audio codec:
G.711 μ-law (64 kbps)
• Audio output power:
Internal speaker
More than 400 mW
(at 10% distortion into a 16 Ω load)
External speaker
More than 200mW
(at 10% distortion into an 8 Ω load)
• Audio output impedance:
Internal speaker
16 Ω
External speaker
8 Ω
D
• Power supply requirement:
• Charging temperature range:
• Weight:
• Dimensions:
D
• Power supply requirement:
• Charging temperature range:
• Weight:
• Dimensions:
(Approximate)
160 m (525 ft)
190 m (623 ft)
7-3
BC-202
desktop charger
12 to 16 V DC or the specified Icom
power adapter
0˚C to +40˚C (+32˚F to +104˚F)
Approximately 104 g; 3.7 oz
(without power adapter)
88(W) × 72.6(H) × 46.5(D) mm
(3.5(W) × 2.9(H) × 1.8(D) inches)
(projections are not included)
BC-211 -
multi charger
12 to 16 V DC or the specified Icom
power adapter
10˚C to +40˚C (+50˚F to +104˚F)
Approximately 1200 g; 2.6 lb
(without power adapter)
303.2(W) × 78.2(H) × 179.7(D) mm
(11.9(W) × 3.1(D) × 7.1(H) inches)
(projections are not included)
