Specifications - Icom IC-F40GT Service Manual

SECTION 1
Measurement method
Frequency coverage
Type of emission
Number of conventional channels
Power supply requirement
Current drain (approx.)
Frequency error
Usable temperature range
Dimensions (proj. not included)
Weight (with BP-210)
RF output power
Modulation system
Maximum permissible deviation
Spurious emissions
Adjacent channel power
Audio frequency response
Audio hormonic distortion
FM hum and noise (typical)
Residual modulation (typical)
Limitting charact of modulator
Ext. microphone connector
Receive system
Intermediate frequencies
Sensitivity (typical)
Squelch sencitivity (at threshold) (typical)
Adjcent channel selectivity (typical)
Spurious response
Intermoduration (typical)
FM hum and noise (typical)
Hum and noise (typical)
Audio output power (at 7.2 V DC)
External SP connector
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

USA
EIA-152-C/204D
400.000–430.000 MHz [L-band]
450.000–490.000 MHz [MH-band]
480.000–512.000 MHz [H-band]
W/N: 16K0F3E [25 kHz; Wide]/8K50F3E [12.5 kHz; Narrow]
M/N: 14K0F3E [20 kHz; Middle]/8K50F3E [12.5 kHz; Narrow]
32 ch
7.2 V DC (negative ground; supplied battery pack)
TX at High
Rx max. audio
stand-by
±2.5 ppm
–30˚C to +60˚C (–22˚F to +140˚F)
× ×
54(W) 139(H)
420 g; 14.8 oz
4 W / 2 W / 1 W (High/Low2/Low1)
Variable reactance frequency modulation
±5.0 kHz [Wide], ±4.0 kHz [Middle], ±2.5 kHz [Narrow]
73 dB typical
70 dB [Wide/Middle], 60 dB [Narrow]
+2 dB to –8 dB of 6 dB/octarve
range from 300 Hz to 3000 Hz [Wide/Middle]/2550 Hz [Narrow]
3% typical at 1 kHz, 40% deviation
46 dB [Wide], 40 dB [Narrow]
——
60–100% of max. deviation
9-pin multi connector/2.2 kΩ
Double-conversion superheterodyne system
1st: 47.25 MHz, 2nd: 450 kHz
0.25 µV at 12 dB SINAD
0.25 µV
73 dB [Wide/Middle], 63 dB [Narrow]
70 dB
74 dB
46 dB [Wide], 40 dB [Narrow]
——
500 mW typical at 5% distortion with a 8 Ω load
600 mW typical at 5% distortion with a 6 Ω load
9-pin multi connector/8 Ω
1 - 1
TIA-603 or ETS 300 086 (GEN)
400.000–430.000 MHz [L-band]
440.000–480.000 MHz [ML-band]
480.000–520.000 MHz [H-band]
2.0 A
300 mA
95 mA (typical)
±1.5 kHz
–25˚C to +55˚C (–13˚F to +131˚F)
×
38(D) mm; 2 1 ⁄ (W) 5 15 ⁄ (H)
8 32
0.25 µW
——
45 dB [Wide/Middle], 43 dB [Narrow]
–4 dBµV (emf) at 20 dB SINAD
–4 dBµV (emf)
70 dB
——
45 dB [Wide/Middle], 43 dB [Narrow]
GEN/EUR
×
1 1 ⁄ (D) inch
2
