Operation - ADJ Comscan LeD User Instructions

Comscan LED
TEST
- This function will run a self test program.
1. Tap the MENU button until "TEST" is displayed, press ENTER.
2. The fixture will now run a self test.
TEMP
- With this function you can check the temperature
of the fixture.
1. Tap the MENU button until "TEMP" is displayed, press ENTER.
2. The temperature of the fixture will now be displayed. Press
MENU to exit.
FHRS
- With this function you can display the running time
of the fixture.
1. Tap the MENU button until "FHRS" is displayed, press
ENTER.
2. The running time of the fixture will now be displayed. Press
MENU to exit.
VER
- With this function you can display the version soft-
ware of the fixture.
1. Tap the MENU button until "VER" is displayed, press ENTER.
2. The software version will now be displayed. Press MENU to
exit.
American DJ - www.americandj.com - Comscan LED Instruction Manual Page 11
®
System Menu Comscan LED
Operating Modes: The Comscan LED can operate in three dif-
ferent modes. In each mode you can run the fixture as a stand
alone fixture or in a master/slave confiugration. This next section
will detail the differences in the operating modes.
• Sound Active mode -
The fixture will react to sound, chasing through the built-in programs.
• Show mode -
Choose 1 of 12 show modes to run.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller such as the Elation
Designer.
Master-Slave Operation
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The first unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit find your desired show and set that show by
pressiing the ENTER button.
3. On the slave units
played, and Press ENTER.
4. The slave units will now follow the Master unit.
Universal DMX Control:
universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Comscan LED is a five DMX channel DMX fixture. See
page 14 for a detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
American DJ
™
This function will allow you to link up to 16
tap the MENU button until "SLMD" is dis-
This function allows you to use a Elation
- www.americandj.com - Comscan LED Instruction Manual Page 12
®

Operation

Show
®
®
