ADJ Comscan LeD User Instructions page 7

Comscan LED
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller's faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 9 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode:
This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Tap the MENU button until
ENTER.
2.
Press ENTER then press and hold MENU for 3 seconds to cofirm.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Show Mode:
In this mode you can choose 1 of 12 show modes to
run.
1. Tap the MENU button until
ENTER.
2.
Tap the UP or DOWN buttons until you find your desired show,
and press ENTER then press and hold MENU for 3 seconds to
con firm. See page 9 for more info.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Comscan LED
Blackout Blackout the unit
1. Synchronous Strobe
Function 2. Two light Strobe
3. Sound Strobe
Sound/Strobe
Mode
(LED OFF)
American DJ - www.americandj.com - Comscan LED Instruction Manual Page 13
®
Operation
"SOUN" is displayed, and press
"SHND" is displayed, and press
UC3 Control
Show Select Gobo Select
(show0-12) (8+open)
Chase Gobo
(LED ON) (LED blinking)
Comscan LED
Channel Value
1 0 - 255
2 0 - 255
3
0 - 7
8 - 15
16 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
4
0 - 7
8 - 14
15 - 21
22 - 28
29 - 25
36 - 42
43 - 49
50 - 56
57 - 63
64 - 71
72 - 78
79 - 85
86 - 92
93 - 99
100 - 106
107 - 113
114 - 120
121 - 127
128 - 255 GOBO WHEEL ROTATION SLOW - FAST
5 0 - 255
American DJ - www.americandj.com - Comscan LED Instruction Manual Page 14
®
DMX Values & Traits
Function
PAN
TILT
STROBE
BLACKOUT
OPEN
STROBING SLOW - FAST
OPEN
SLOW OPEN - FAST CLOSE
OPEN
FAST OPEN - SLOW CLOSE
OPEN
RANDOM STROBE
OPEN
GOBO WHEEL
OPEN
GOBO 1
GOBO 2
GOBO 3
GOBO 4
GOBO 5
GOBO 6
GOBO 7
GOBO 8
OPEN SHAKE
GOBO 1 SHAKE
GOBO 2 SHAKE
GOBO 3 SHAKE
GOBO 4 SHAKE
GOBO 5 SHAKE
GOBO 6 SHAKE
GOBO 7 SHAKE
GOBO 8 SHAKE
MASTER DIMMER 0% - 100%
