Comscan LED
System Menu: When making adjustments you can press
ENTER to confirm your setup or you can wait 8 seconds for
automatic setup. To exit without making any adjustments
press the MENU button.
ADDR -
DMX Address Setting.
1. Tap the either the MENU, UP, or DOWN buttons until "ADDR"
is displayed, press ENTER.
2. The current address will now be displayed and flashing.
Press the UP or DOWN buttons to find your desired address.
Press ENTER to set your desired DMX address.
SLMD -
This will let you set unit as a master or slave in a
master/slave configuration.
1. Tap the MENU button until "SLMD" is displayed, press
ENTER. Either "SL 1" or "SL 2" will be displayed.
2. Tap the UP or DOWN buttons until your desired setting is
displayed, press ENTER to confim.
NOTE: In a Master/Slave configuration you can set one fixture
to Master and then set the next fixture to "SL 2", the fixtures will
now have contrast movement to each other.
SHND: SH 0 - 12
- Show modes 0-12 (Factory programs).
You can run show mode with sound active mode off or on.
1. Tap the MENU button until "SHND" is displayed, press
ENTER.
2. "Sh X" will now be displayed, "X" representing a number
between 0-12. Programs 1-12 are factory programs, while "Sh
0" is random mode. Press the UP or DOWN buttons to find your
desired show and press the ENTER, then press and hold the
MENU button for at least 3 seconds to confirm.
American DJ - www.americandj.com - Comscan LED Instruction Manual Page 9
®
System Menu Comscan LED
SOUN -
1. Tap the MENU button until "SOUN" is displayed, press
ENTER.
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to activate sound active mode, or
"OFF" to deactivate sound active mode.
3. Press ENTER to confirm.
BLND -
1. Tap the MENU button until "BLND" is displayed, press
ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until "Yes"
is displayed, press ENTER to confim. The fixture will now be in
Blackout mode. To deactivate Blackout mode, select "No" and
press Enter.
LED -
turn off after 10 seconds.
1. Tap the MENU button until "LED" is displayed, press ENTER.
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to keep the LED display on at
all times, or "OFF" to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to confirm.
DISP -
1. Tap the MENU button until "DISP" is displayed, press ENTER.
2. Press ENTER to "flip" the display. Press ENTER to "flip" it
again. Press ENTER when you have made your desired setup.
American DJ
Sound Active mode.
Blackout or Stand by mode.
With this function you can have the LED display
This function will reverse the display 180º.
- www.americandj.com - Comscan LED Instruction Manual Page 10
®
