4 . 1 R E C O M M E N D E D C L E A N I N G T I P S
Use a soft clean cotton cloth. DO NOT
1.
Paper towels are abrasive and can scratch surfaces.
Use a mild soap and damp cloth.
DO NOT
2.
coloring of the aluminum and plastics it comes into contact with.
Do not pour water or cleaning solutions on any surface. This could cause electrocution.
3.
Wipe the console and side rails dry after every use.
4.
Brush away any wax deposits from the deck and belt area. This is a common occurrence until
5.
the wax is worked into the belt material.
Be sure to remove any obstructions form the path of the elevation wheels including power cords.
6.
Monthly unplug the treadmill and remove the motor cover. Check for debris and clean with
7.
a dry cloth or small vacuum nozzle.
WARNING
cover has been reinstalled.
This unit weighs 450 pounds. Be sure to have proper assistance to install and move
CAUTION
the unit, to avoid injury to you and the unit.

4.2 DECK AND BELT REPLACEMENT

One of the most common wear and tear items on a treadmill is the Deck and Belt combination.
If these two items are not properly maintained they can cause damage to other components.
This product has been provided with most advanced maintenance free lubricating system on
the market.
Do not run the treadmill while cleaning the belt and deck. This can cause serious
WARNING
injury and can damage the machine.
Maintain the belt and deck by wiping the sides of the belt and deck with a clean cloth. The user
can also wipe under the belt 2 inches on both sides removing any dust or debris.
The deck can be flipped and reinstalled with a new belt by only by an authorized service technician.
Please contact Matrix Fitness Systems for more information.

4.3 ADJUSTING THE BELT

After locating the treadmill in the position it will be used, the belt must be checked for proper
tension and centering. The belt might need to be adjusted after the first two hours of use.
Temperature, humidity, and use cause the belt to stretch at different rates. If the belt starts to
slip when a user is on it be sure to follow the directions below.
use paper towels to clean surfaces on the treadmill.
use ammonia based cleaner. This will cause dis-
Do Not plug the treadmill in until the motor
Locate the two hex head bolts on the rear of the treadmill. The bolts are located at
STEP 1
each end of the frame at the back of the treadmill. These bolts adjust the rear belt roller. Do
not adjust until the treadmill is on. This will prevent over tightening of one side.
The belt should have equal distance on either side between the frame. If the belt is
STEP 2
touching one side, do not start the treadmill. Turn the bolts counter clockwise approximate-
ly one full turn on each side. Manually center the belt by pushing the belt from side to side.
Tighten the bolts the same amount as when the user loosened them approximately one full
turn. Inspect the belt for damage.
While the treadmill is running, at 3 mph, notice the belt position. If it is moving to the
STEP 3
right, tighten, turn clockwise, the right bolt 1/4 turn and loosen the left bolt 1/4 turn. If it
moving to the left, tighten, turn clockwise, the left bolt 1/4 turn and loosen the right bolt 1/4
turn. Repeat Step 3 until the belt remains centered for several minutes.
Check the tension of the belt. The belt should be very snug. When a person walks or
STEP 4
runs on the belt it should not hesitate or slip. If this occurs tighten, turn clockwise, both bolts
1/4 turn. Repeat if necessary.
