Matrix MX-T3x Owner's Manual
Commercial series
Hide thumbs
Also See for MX-T3x:
- Owner's manual (27 pages) ,
- Service manual (61 pages) ,
- Owner's manual (27 pages)
Subscribe to Our Youtube Channel
Related Manuals for Matrix MX-T3x
Summary of Contents for Matrix MX-T3x
- Page 1 COMMERCIAL SERIES TREADMILL O W N E R ’ S M A N U A L 06'_Treadmills_M.indd 1 7/18/06 4:00:02 PM...
- Page 2 06'_Treadmills_M.indd 2 7/18/06 4:00:02 PM...
-
Page 3: Table Of Contents
Operating Level Based Programs ....................5.4 Heart Rate Control ........................5.5 Fit Test ........................... 5.6 Engineering Mode ........................5.7 Manager Screen Descriptions / Details ..................5.8 Using CSAFE ........................... CHAPTER 6: MX-T3x / MX-T3xi TREADMILL SPECIFICATIONS, PARTS & ASSEMBLY GUIDES 6.1 Model Specifications ........................ 6.2 Fasteners and Assembly Tools ....................6.3 Assembly Steps ........................CHAPTER 7: MX-T5x TREADMILL SPECIFICATIONS, PARTS & ASSEMBLY GUIDES 7.1 Model Specifications ........................ 7.2 Fasteners and Assembly Tools .................... - Page 4 06'_Treadmills_M.indd 4 7/18/06 4:00:02 PM...
-
Page 5: Before Getting Started
This Treadmill is intended for commercial use. To ensure your safety and protect the equipment, read all instructions before operating the MATRIX ucts to instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the equipment. treadmill. When using an electrical product, basic precautions should always be followed It is recommended that all users of Matrix Fitness Systems exercise equip- ment be informed of the following information prior to its use. including the following: DANGER: To reduce the risk of electric shock: Always unplug this equipment 1.2 PROPER USAGE from the electrical outlet immediately after using and before cleaning. -
Page 6: Electrical Requirements
2.3 CHECK FOR DAMAGED PARTS Do not modify the plug provided with the product if it will not fit the outlet; have a proper outlet installed by a qualified technician. DO NOT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems. 120v UNITS MAINTAIN LABELS AND NAMEPLATES. Do not remove labels for any reason. The Matrix MX-T3x, MX-T3xi and MX-T5x 120 treadmill is for use on a nomi- They contain important information. If unreadable or missing, contact Matrix nal 120-volt circuit and has a non-looped grounding plug. Make sure that Fitness Systems for a replacement. the 110V treadmill is connected to an outlet, NEMA 5-20R, having the same configuration as the plug. No adapter should be used with this product. MAINTAIN ALL EqUIPMENT Preventative maintenance is the key to smooth operating equipment, as well as keeping the users liability to a minimum. -
Page 7: Adjusting The Belt
CHAPTER 2: P CHAPTER 3: S reventative aintenance erial umber ocation 3.1 MX-T3x & T3xi TREADMILL 2.4 ADJUSTING THE BELT After placing the treadmill in the position it will be used, the belt must be checked for proper tension and centering. The belt might need to be adjusted after the first two hours of use. Temperature, humidity, and use cause the belt to stretch at different rates. If the belt starts to slip when a user is on it, be sure to follow the directions below. Locate the two hex head bolts on the rear of the treadmill. STEP 1 The bolts are located at each end of the frame at the back of the treadmill. These bolts adjust the rear belt roller. Do not... -
Page 8: T3X & T3Xi Console Description
CHAPTER 4: mX-t3 / mX-t3 verlay escription rograming ngineering 4.1 MX-T3x CONSOLE DESCRIPTION MX-T3xi CONSOLE DESCRIPTION The MATRIX treadmill is inspected before it is packaged. It is shipped in The MATRIX treadmill is inspected before it is packaged. It is shipped in four pieces: the base, the upright console supports, the handlebar and four pieces: the base, the upright console supports, the handlebar and the console. Carefully unpack the unit and dispose of the box material. -
Page 9: Manual Operation
CHAPTER 4: mX-t3 / mX-t3 verlay escription rograming ngineering 4.4 HEART RATE CONTROL 4.2 MANUAL OPERATION Follow these easy Steps to enter into the Heart Rate Program. MATRIX design makes using the programs as easy as one touch of a button. TARGET HR: qUICK START Press the “QUICK START” key and the LED will show “3”, “2”, “1”, “GO!”. 1) Choose the “TARGET HR” using the program qUICK-KEYS, then press SELECT. The treadmill will start running from the lowest incline and 0.5 mph, with the 2) Choose the “TARGET HART RATE” using the SPEED -/+, then press SELECT. default time counting down from 20 minutes. 3) Choose your HR CONTROL MODE using the SPEED or INCLINE KEYS: - If SPEED -/+ is pressed the console will display “Speed HR Control, MANUAL MODE allows you to enter desired time, level and weight. press - or + to set Max Speed, then press SELECT”. -
Page 10: Fit Test
MEN’S OUTPUT TABLE FOR TEST #1 AND #2 FIT TEST allows you to measure your fitness based on a program designed EXCELLENT GOOD AVERAGE FAIR POOR specifically for your Matrix Treadmill. The test takes 5 minutes and is based on your heart rate. User should keep hands on contact heart rate graps. 15-19 56 ~ 61 52 ~57 48 ~ 51 42 - Follow these easy steps to enter in the Fit Test Program. -
Page 11: Engineering Mode
CHAPTER 4: mX-t3 / mX-t3 verlay escription rograming ngineering 4.6 ENGINEERING MODE 4.7 MANAGER SCREEN DESCRIPTIONS / DETAILS Below is a list of the MX-T3x functions for each engineering screen. Exceptions Engineering screens allow the viewing and editing of variables that would will be noted in the description for each engineering screens: be necessary for a club operator/manager to customize. Unless otherwise noted, engineering screens consist of the initial screen, the editing or LOW SPEED LEARN MODE (EDIT) action screen, and the saving screen. The initial screen displays the vari- This variable controls the low limit for the speed of the treadmill. -
Page 12: Mx-T3Xi Manager Screen Descriptions / Details
90:00:00 10:00 90:00:00 set weight 20:00 10:00 90:00:00 total time KPH:80/MPH:150 KPH:22/MPH:50 KPH:180/MPH:400 HIGH ELEvATION LEARN MODE (EDIT) total dist Matrix T3x Matrix T3x JOHNSON T8000 This variable controls the the high limit for the elevation of the tread mill. version language UNIT (EDIT) user speed Changes from Standard (Miles) to Metric (Kilometers). user time English English Holland Product Test Unit change will force unit dependent variables to revert to their default values. -
Page 13: T5X Console Description
CHAPTER 5: mX-t5 verlay escription rograming ngineering 5.1 CONSOLE DESCRIPTION 5.2 MANUAL OPERATION MATRIX design makes using the programs as easy as one touch of a button. qUICK START Start pedaling and press qUICK START to begin workout. MANUAL MODE allows you to enter desired time, level and weight. TIME DISTANCE STEP 1 Select MANUAL program button on left of panel. ELEVATION SPEED Press SELECT or wait 5 seconds. RANDOM MANUAL KEYPAD Selecting START will start program. QUICK FIT TEST ROLLING START SELECT CLEAR PAUSE INTERVALS... -
Page 14: Operating Level Based Programs
CHAPTER 5: mX-t5 verlay escription rograming ngineering 5.4 HEART RATE CONTROL 5.3 OPERATING LEvEL BASED PROGRAMS Your MATRIX treadmill offers versatile programs to keep the usere motivated. The follow- For your convenience, MATRIX Treadmills come standard with digital contact ing instructions will guide you through simple steps to select INTERVALS, ROLLING, and heat rate sensors and are POLAR telemetry compatible. RANDOM programs. Locate the metal sensors on the handrail of the treadmill. Notice there are two separate pieces of metal on each grip. You must be making contact on both STEP 1 Select the PROGRAM button on left of panel. pieces of each grip to get an accurate heart rate reading. You can grab these Press SELECT or wait 5 seconds. sensors in any program to view your current heart rate. Selecting START will start program. Heart Rate Program STEP 2 Select TIME by using the UP or DOWN arrow keys. Follow these easy Steps to enter into the Heart Rate Program. Press SELECT or wait 5 seconds. Select START will start program. STEP 1 Select the TARGET HR program button. -
Page 15: Fit Test
32 ~ 36 23 ~ 31 17 ~ 22 17 - 5.5 FIT TEST FIT TEST allows you to measure your fitness based on a program designed specifically for your Matrix Treadmill. The test takes 5 minutes and is based on your heart rate. User should keep hands on contact heart rate WOMEN’S OUTPUT TABLE FOR TEST #1 AND #2 graps. EXCELLENT GOOD... -
Page 16: Engineering Mode
CHAPTER 5: mX-t5 verlay escription rograming ngineering 5.7 MANAGER SCREENS EXCEPTIONS/DETAILS 5.6 ENGINEERING MODE Below is a list of functions for each Manager Setting. Exceptions will be noted in Manager screens allow the viewing and editing of variables that would be the description for each manager setting: necessary for a club operator/manager to customize. Unless otherwise noted manager screens consist of the initial screen, the editing or action screen and P0 MAXIMUM TIME (EDIT) the saving screen. The initial screen displays the variable type and in most This variable controls the program maximum time. -
Page 17: Using Csafe
CHAPTER 5: mX-t5 verlay escription rograming ngineering 5.8 USING CSAFE Matrix is the leader in entertainment availability. On the back of the console P10 DEFAULT CHANNEL (EDIT) are three RJ45 receptacles. They are marked CSAFE IN, CSAFE OUT, and Controls the default channel for enterainment CSAFE compativle devices. ENTERTAINMENT. This variable is editable. Numeric entry is active. Use the csafe in to plug in an csafe device using the RJ45 connector csafe P11 DEFAULT vOLUME (EDIT) out allows csafe products to be daisy chained together from one unit to the Controls the default channel for enterainment CSAFE compativle devices. next. The connection is as follows; This variable is editable. -
Page 18: Model Specifications
CHAPTER 6: MX-T3 / T3 reaDmill pecifications arts ssembly uiDes 6.1 MX-T3 MX-T3 MODEL SPECIFICATIONS SPECIFICATIONS Foot Print inches = 85” x 34” x 55” cm = 216 x 87 x 140 Weight 350 lbs Max User Weight 400 lbs = 181 kg Belt Type Habisat Frame Construction... -
Page 19: Fasteners And Assembly Tools
CHAPTER 6: MX-T3 / T3 reaDmill pecifications arts ssembly uiDes 6.2 MX-T3 MX-T3 MODEL REqUIRED FASTENERS & ASSEMBLEY TOOLS PART # SKETCH DESCRIPTION NOTES 8mm ALLEN WRENCH 10mm ALLEN WRENCH #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ] FLAT WASHER 30x2.0L SOCKET HEAD CAP SCREW M10 x 25 SOCKET HEAD CAP SCREW M8 x 30 BUTTON HEAD MACHINE SCREW M5 x 12L... -
Page 20: Assembly Steps
CHAPTER 6: MX-T3 / T3 reaDmill pecifications arts ssembly uiDes 6.3 MX-T3 MX-T3 MODEL ASSEMBLY STEPS ATTENTION • After installation is completed, the treadmill will need to be calibrated by using the AUTO-CHECK function. If this is not done, the treadmill's speed and incline values may be incorrect and damage the treadmill. Do not stand on the belt when performing the AUTO-CHECK function. ASSEMBLY INSTRUCTIONS • Please make sure that the power plug is not plugged into the wall outlet while completing the following procedure. To ensure correct assembly of the treadmill, carefully read and follow these steps: STEP 1 STEP 2 Remove the motor cover. Pull out the console cable and route it through Connect the console cables from the console set to the motor control the Right console mast. Place the right console mast and then the left board cables. Secure the console set with 2 screws (Z52) on each side. - Page 21 CHAPTER 6: MX-T3 / T3 reaDmill pecifications arts ssembly uiDes 6.4 MX-T3 MX-T3 MODEL ASSEMBLY STEPS STEP 3 STEP 4 FINAL ASSEMBLY AUTO CHECK • Press and hold both incline “UP” and speed “DOWN“ buttons simultaneously for 3 seconds .Then the “ENGINEERING MODE” is shown onto the console. • Press the incline “UP” button to find the “AUTO CHECK” screen. • Press the incline “START” button and then, the treadmill will run the auto check function automatically. This will take around 3 minutes to run. • After auto check is complete “AUTO CHECK OK” will show on the console. Then, press EMERGENCY STOP key to back to initial starting screen. 06'_Treadmills_M.indd 21 7/18/06 4:00:08 PM...
-
Page 22: Model Specifications
CHAPTER 7: MX-T5 reaDmill pecifications arts ssembly uiDes 7.1 MX-T5 MODEL SPECIFICATIONS SPECIFICATIONS HEART RATE Product Name Foot Print inches = 85” x 35” x 62” cm = 215.9 x 88.7 x Telemetry 157.5 Contact Heart Rate Weight 450 lbs 204 kg ENTERTAINMENT READY Max User Weight... -
Page 23: Fasteners And Assembly Tools
CHAPTER 7: MX-T5 reaDmill pecifications arts ssembly uiDes 7.2 MX-T5 MODEL REqUIRED FASTENERS & ASSEMBLEY TOOLS PART # SKETCH DESCRIPTION NOTES 5mm ALLEN WRENCH ALLEN WRENCH [ #8 x 168 ] ALLEN WRENCH [ #5 x 172 ] #2 PHILLIPS SCREW DRIVER [ 4.5 x 50 ] FLAT HEAD MACHINE SCREW (M8 x 20L) FLAT HEAD MACHINE SCREW (M8 x 25L) SOCKET HEAD CAP SCREW (M8 x 15L) -
Page 24: Assembly Steps
CHAPTER 7: MX-T5 reaDmill pecifications arts ssembly uiDes 7.3 MX-T5 MODEL ASSEMBLY STEPS STEP 1 STEP 2 06'_Treadmills_M.indd 24 7/18/06 4:00:09 PM... - Page 25 CHAPTER 7: MX-T5 reaDmill pecifications arts ssembly uiDes 7.3 MX-T5 MODEL ASSEMBLY STEPS STEP 3 FINAL ASSEMBLY 06'_Treadmills_M.indd 25 7/18/06 4:00:10 PM...
- Page 26 06'_Treadmills_M.indd 26 7/18/06 4:00:10 PM...
- Page 27 MATR IX FI TN E SS SYST E MS CO R P. 1 6 1 0 LA N D MAR K DR I VE C O TTAG E GR OV E W I 5 35 27 U S A w w w.
