MAINTENANCE

1. Any and all part removal or replacement must be performed by a qualified service technician.
2. DO NOT use any equipment that is damaged and or has worn or broken parts.
Use only replacement parts supplied by your country's local MATRIX dealer.
3. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain
important information. If unreadable or missing, contact your MATRIX dealer for a replacement.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to
smooth operating equipment as well as keeping your liability to a
minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance
or repair of any kind is qualified to do so. MATRIX dealers will provide service
and maintenance training at our corporate facility upon request.

WARRANTY

For North America, please visit www.matrixfitness.com for warranty
information along with warranty exclusions and limitations.
PRODUCT SPECIFICATIONS
Max User Weight
Product Weight
Shipping Weight
Overall Dimensions
(L x W x H)*
Max. Harness Loading
* Ensure a minimum clearance width of 0.6 meters (24") for access to and
passage around MATRIX equipment. Please note, 0.91 meters (36") is the
ADA recommended clearance width for individuals in wheelchairs.
181.4 kg / 400 lbs
141.2 kg / 312 lbs
158.2 kg / 349 lbs
193 x 88 x 150 cm /
76" x 34.6" x 59"
136 kg / 300 lbs
MAINTENANCE SCHEDULE
ACTION
Clean entire machine using water and a mild soap
or other Matrix approved solution (cleaning agents
should be alcohol and ammonia free).
Check harness for wear and secure connections.
Remove the front cover. Check for debris and clean
with a dry cloth or small vacuum nozzle.
Lubricate treadmill running deck
RUNNING
DECK
LUBRICATING THE RUNNING BELT
1. Using a T-wrench or Allen wrench, loosen the rear roller bolts
10-15 counter-clockwise turns. This should give
the belt enough slack for you to lift it.
2. Lift the belt as far as you can and squirt the silicone oil in a zigzag
pattern across the entire running deck surface. Use 30-50 ml of
100% silicone oil lubricant. Do not apply the silicone oil on top of
the running belt. Lay the running belt down and then tighten both
rear roller bolts clockwise the same number of turns loosened.
3. Walk on the machine at a comfortable speed for 3 minutes to spread the
silicone and to check the running belt for proper tension and alignment.
4. Wipe any excess oil from the sides with a damp cloth.
FREQUENCY
DAILY
DAILY
MONTHLY
EVERY 3 MONTHS
RUNNING
BELT
