Pellet Stove
P960 - P961
INSTRUCTIONS FOR INSTALLATION,
USE AND MAINTENANCE
Please read this entire manual before installation and use of this
pellet fuel-burning room heater. Failure to follow these instructions
could result in property damage, bodily injiury or even death.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
Save these Instructions.
