Pellet Stove P965 THERMO
UK
INSTRUCTIONS FOR THE USER
UK

Advertisement

Table of Contents
loading

Related Manuals for Piazzetta P965 Thermo

Summary of Contents for Piazzetta P965 Thermo

  • Page 1 Pellet Stove P965 THERMO INSTRUCTIONS FOR THE USER...
  • Page 2 In line with its policy of constant product improvement and renewal, the manufacturer may make changes without notice. This document is the property of Gruppo Piazzetta S.p.A.; no part of it may be disclosed to third parties without the written permission of Gruppo Piazzetta S.p.A. All rights reserved by Gruppo Piazzetta S.p.A.

  • Page 3: Table Of Contents

    CONTENTS DT2010187-00 Heading Page Code txt GENERAL RULES DT2010493-01 General recommendations DT2010491-01 Electrical connection DT2010495-00 Basic safety rules DT2010492-00 Safety distances DT2010494-01 FEATURES AND TECHNICAL DATA DT2010805-00 Features DT2010806-00 Technical data DT2010807-00 Dimensions DT2031191-00 Description of the appliance DT2010808-00 Control panel DT2010814-00 DT2010518-00 Programming the timer thermostat...

  • Page 4: General Rules

    GENERAL RULES GENERAL RECOMMENDATIONS DT2010491-01 Use only regulation wood pellets (refer to section Tell children of the possible dangers when the stove entitled “Fuel”). is in operation and the precautions they must take. Ensure that there is sufficient ventilation in the Keep all elements made of combustible or flamma- room of installation when the stove is lit.

  • Page 5: Basic Safety Rules

    GENERAL RULES BASIC SAFETY RULES DT2010492-00 Under no circumstances use fuels other than Under no circumstances remove the protective pellets. grille inside the pellet hopper. Do not use the appliance as an incinerator or use During operation do not close the valves on any liquid fuels to operate the stove or to revive any the radiators;...

  • Page 6: Features And Technical Data

    • Moisture content approx. < 8 % • Apparent density 650 kg/m • Ash residue approx. < 0.5 % U.M. P965 Thermo 16.5 / 6 Rated heat output (max/min) 14 / 5 Heat output of fluid (water) kg/h 4 / 1.5 Hourly consumption (max/min) >...

  • Page 7: Dimensions

    FEATURES AND TECHNICAL DATA DIMENSIONS P965 THERMO (cm) DT2031191-00 KEY: S = Temperature/pressure relief valve 3/4” R = System return 3/4” M = System delivery 3/4”...

  • Page 8: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE DT2010808-00 The pellet stove P965 THERMO, with enamelled steel cladding and majolica front panels offers an excellent heat output. This thermal efficiency has enabled the manufacturer to think of this product as a boiler for the heating circuit water.

  • Page 9: Control Panel

    FEATURES AND TECHNICAL DATA CONTROL PANEL DT2010814-00 SET button ON-OFF button Used to select the functions: Used to: - water temperature setting - ignite and shutdown - parameter change confirmation - exit from programming. - access to timer thermostat programming. ON 3 52°C S DT2031192-00...

  • Page 10: Use

    PROGRAMMING THE TIMER THERMOSTAT DT2010499-00 Codes appear in the upper part of the display during Clock programming, timer thermostat programming, which indicate the fun- setting the day of the week. ction being programmed. To help the User recognise the various codes, the functions are listed below with a description of the type of setting that must be pro- grammed.

  • Page 11: Programming The Clock

    PROGRAMMING THE CLOCK DT2010500-00 The stove leaves the factory with the clock already set. All that needs to be done, therefore, is to check that the time is precise or if any change is needed because of summer time. Correct time setting is necessary to be able to use all the functions where time is involved.

  • Page 12: Using The Stove With The Timer Thermostat

    USING THE STOVE WITH THE TIMER THERMOSTAT DT2010499-00 AUTOMATIC MODE OF OPERATION Example: Operation in the automatic mode is obtained by using Setting of 2 weekly cycles with different water tempera- the timer thermostat. ture and different daily activation. The timer thermostat offers the possibility of program- 1st cycle: 18.00 - 22.00 Water temp.: 65°...
  • Page 13 Setting the day Activate as follows: • To set the day of the week press button 2 • To activate (...ON) or deactivate (...OF) the set day operation status, press button 1 Proceed step by step from Monday to Sunday •...

  • Page 14: Setting - Display

    2nd CYCLE If you do not want to continue with programming the 2nd cycle • Press the ON/OFF button to exit from program- ming. Otherwise repeat the procedure of the 1st cycle Table of codes and functions. starting from: Setting the time band of the 1st cycle (see page 12).

  • Page 15: Setting The Water Temperature

    The display of certain data during operation may be set on the bottom row: Room temperature “A” blinking Actual time Boiler water temperature “H” blinking Water temperature set point “S” blinking Activate as follows: • Keep button 5 pressed for more than five se- conds until the writing 04 appears Select the function as follows:...

  • Page 16: Ignition

    Setting the room thermostat If the “room thermostat” is installed, it measures the room temperature and provides information for modu- lating the heat output (Flame) of the stove in relation to the set temperature. If a higher temperature than room temperature is set on the external thermostat, the stove operates at the set power (Example ON 3).

  • Page 17: Shutdown

    Several ignition procedures are necessary Ignition after long periods of inactivity (seasonal) the first time the pellet hopper is filled. The pellets must fill the whole chute down to the Check that all the extraordinary maintenance firebox. procedures have been carried out, see the section “EXTRAORDINARY MAINTENANCE”.

  • Page 18: Maintenance

    MAINTENANCE ROUTINE MAINTENANCE DT2010508-00 Maintenance is to be considered compulsory All maintenance work (cleaning, any replace- for correct and efficient stove operation. If ments, etc.) must be carried when the flame is maintenance is not carried out with the re- fully extinguished, the stove completely cold commended frequency, stove performance and the power cable and plug disconnected...

  • Page 19: Cleaning The Flue System

    MAINTENANCE CLEANING THE FLUE SYSTEM (MONTHLY) DT2010092-03 Until you have got reasonably used to the operating conditions of the stove, we recommend that this main- tenance be carried out on a monthly basis. Remove the plug from the Tee and clean the pipes. If necessary, particularly on the first few occasions, we recommend calling in a qualified technician.

  • Page 20: Cleaning The Baffle Plate

    MAINTENANCE CLEANING THE BAFFLE PLATE (ONCE EVERY TWO MONTHS) DT2010812-00 Once a day and every time before lighting, clean the grate area as follows: • draw out the grate (3) from its seat; • remove the ash and any encrustation that may have formed, taking particular care to clear any clogged slits, which can be done using a sharp pointed tool;...

  • Page 21: Scheduled Maintenance

    • Check the water system seals and all the wear in general, you must contact a Piazzetta elements for leaks and for wear and if necessary re- After-Sales Service Centre or a qualified place them.

  • Page 22: Fuel

    This “customisation” of stove settings must Diameter approx. 6- 6.5mm Net heat value approx.: 5 kWh/kg be carried out at a Gruppo Piazzetta S.p.A. Moisture content approx.: < 8 % Service Centre or by specially qualified per- Residual ash approx.: <...

  • Page 23: Troubleshooting

    Some of the problems indicated below may be resolved by following the instructions. Call the Gruppo Piazzetta Service Centre only after having carefully read the instructions. All work must be carried out when the appliance is cold and disconnected from the electricity sup- ply (pull out the plug).
  • Page 24 The thermostats could have tripped; check and reset. In accordance with the standard EN 60335-1, it is compulsory to contact a Gruppo Piazzetta Ser- vice Centre or authorised technicians after two resets.
  • Page 25 The thermostats could have tripped; check and reset. In accordance with the standard EN 60335-1, it is compulsory to contact a Gruppo Piazzetta Service Centre or authorised technicians after two resets. Faulty electronic board. Contact your nearest Service Centre.
  • Page 26 TROUBLESHOOTING Problem Cause Remedy Leaks in the water circuit. System malfunction. Damaged safety valves. Contact your nearest Service Centre or a quali- Incorrect system pressure Leaps in pressure of the fied technician. mains water supply. Failed operation of the expansion tank. If the temperature of the water flowing into the Set water temperature has heating system exceeds the set value, the stove...
  • Page 27 The thermostats could have tripped; check and reset. In accordance with the standard EN 60335-1, it is compulsory to contact a Gruppo Piazzetta Service Centre or authorised technicians after two resets.. Check the water circuit. The appliance does not manage to disperse Water circuit malfunction.
  • Page 28 Via Montello, 22 31011 Casella d’Asolo (TV) - ITALY Tel. +39.04235271 - Fax +39.042355178 http://www.piazzetta.it e-mail: infopiazzetta@ piazzetta.it...
