1- Place unit at the desired location and secure with mounting screws
(not included) (Fig. 16a and Fig. 16b, pg. 9).
Fig. 16a Fig. 16b
Mechanical Drawing and Dimensions :
(H x W x D approx.)
9.5" x 7.32" x 4.92" (241.3mm x 185.9mm x 125mm)
Notes:
Altronix is not responsible for any typographical errors.
