Altronix eBridge16CR Installation Manual page 4

Single IP camera shown with composite video option:
Fig. 2
Back of Unit
Front of Unit
NVR Network
Video Server
(Head End
Equipment)
Up to
100m
Ethernet Switch
Fig. 3
Back of Unit
Front of Unit
Up to
100m
NVR Network
Up to
Video Server
100m
Up to
(Head End
100m
Equipment)
Ethernet Switch
- 4 -
Up to
100m
eBridge1CT
eBridge1CT Composite Composite
Input: 12VDC/275mA, 24VDC/110mA,
Video Cable Video Cable
16VAC/375mA, 24VAC/200mA.
Blue LED Coax link status.
RJ45 LEDs Yellow - Speed To Monitor To Monitor
Green - Activity
Green LED Power
Z1409
IP Camera
(external power
required).
Up to
Comp. Video
500m
Cable
Up to 100m
Coax
Structured Cable
Composite Video Cable
Up to Up to Up to
500m 500m 500m
eBridge1CT
eBridge1CT
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Z1409
IP Camera
(external power
required).
Up to
Comp. Video
500m
Cable
Up to 100m
IP Camera
Hybrid w/Sloc Technology
(external power required).
Up to
500m
Coax
Structured Cable
eBridge16CR
