Inter-LAN Routing
After finishing all the settings here, please click OK to save the configuration.
To configure LAN 1 ~ LAN 4, or IP Routed Subnet, simply click Details Page to open the
settings page.
D e t a i l s
D e t a i l s
LAN1 is the default configuration for basic host connection.
Available settings are explained as follows:
Item
Network Configuration
DHCP Server
Configuration
Vigor2920 Series User's Guide
Check the box to link two or more different subnets (LAN
and LAN).
P a g e f o r L A N 1
P a g e f o r L A N 1
Description
IP Address - Type in IP address for connecting to a local
private network (Default: 192.168.1.1).
Subnet Mask - Type in an address code that determines the
size of the network. (Default: 255.255.255.0/ 24)
RIP Protocol Control - Disable deactivates the RIP protocol.
It will lead to a stoppage of the exchange of routing
information between routers. (Default) Enable can activate the
RIP protocol.
DHCP stands for Dynamic Host Configuration Protocol. The
router by factory default acts a DHCP server for your network
so it automatically dispatch related IP settings to any local user
configured as a DHCP client. It is highly recommended that
you leave the router enabled as a DHCP server if you do not
have a DHCP server for your network.
Enable Server - Let the router assign IP address to every host
in the LAN.
Disable Server –If your LAN has another DHCP server,
please click it to disable the DHCP server of this device.
However, If you LAN does not have any DHCP server, you
