D e t a i l s
D e t a i l s
To choose PPPoE as the accessing protocol of the internet, please select PPPoE from the
Internet Access menu. The following web page will be shown.
Available settings are explained as follows:
Item
PPPoE Client Mode
ISP Access Setup
Vigor2920 Series User's Guide
Option Number – Type a number for such function.
Note
detailed settings in WAN>>Interface Access will be
overwritten.
DataType – Choose the type (ASCII or Hex) for the data to
be stored.
Data – Type the content of the data to be processed by the
function of DHCP option.
P a g e f o r P P P o E i n
P a g e f o r P P P o E i n
Description
Click Enable for activating this function. If you click Disable,
this function will be closed and all the settings that you
adjusted in this page will be invalid.
Enter your allocated username, password and authentication
parameters according to the information provided by your ISP.
Username – Type in the username provided by ISP in this
field.
Password – Type in the password provided by ISP in this
field.
Index (1-15) in Schedule Setup - You can type in four sets of
:
If you choose to configure option 61 here, the
W A N 1 / W A N 2
W A N 1 / W A N 2
128
