2. Click Setup link of WAN. Make sure the QoS Control on the left corner is checked. And
select BOTH in Direction.
3. Set Inbound/Outbound bandwidth.
Note: The rate of outbound/inbound must be smaller than the real bandwidth to
ensure correct calculation of QoS. It is suggested to set the bandwidth value for
inbound/outbound as 80% - 85% of physical network speed provided by ISP to
maximize the QoS performance.
4. Return to previous page. Type the Name of Index Class 1 by clicking Edit link. Type the
name "E-mail" for Class 1.
