XX138-10-01
MODEL SVFT-UPM-1 OUTDOOR
PARAPET MOUNT FOR SURVEYORVFT
CAMERA DOME SYSTEMS
Copyright © 2005 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Surveyor is a trademark of Vicon Industries Inc.
Teflon is a registered trademark of E.I. duPont de Nemours & Co.
Molykote is a registered trademark of Dow Corning.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489-566300 WEB:
www.vicon-cctv.com
Vicon part number 8009-8138-10-01
Section 3 Rev 1005
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vicon SurveyorVFT SVFT-UPM-1
Summary of Contents for Vicon SurveyorVFT SVFT-UPM-1
- Page 1 Copyright © 2005 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. Surveyor is a trademark of Vicon Industries Inc. Teflon is a registered trademark of E.I. duPont de Nemours & Co.
-
Page 5: Installation
Introduction The information in this manual covers the installation, operation, and maintenance of the SVFT-UPM-1 Parapet Mount. This unit should only be installed by a qualified technician using approved materials in accordance with national, state, and local codes. Read these instructions through completely before attempting installation. - Page 6 TABLE 1 MOUNTING KIT COMPONENTS Item No. Component Quantity Function Wall bracket Secures parapet mount to mounting surface Wall bracket cover Secures parapet mount in wall bracket Support bracket Secures bottom wall bracket Closes off bottom of mount but allows cabling to be routed 5/16-18x1 in.
- Page 7 Before beginning installation of the parapet mount, run all necessary cabling to the location selected for the installation. Cables are routed up through the mount to the dome system. 1. Attach one wall bracket and the support bracket to the parapet surface using appropriate hardware for the material of the parapet.
- Page 8 Figure 1 SVFT-UPM-1 Installation 4 • Installation XX138-10-01 Rev 1005 SVFT-UPM-1 Parapet Mount...
- Page 9 Operation To swivel the mount in from the parapet for access to the dome system, loosen the bolts enough to allow movement. Swing the unit in from the parapet. Tighten the bolts. After servicing or adjustment is complete, loosen the bolts, position the mount, and tighten bolts. Maintenance The SVFT-UPM-1 Parapet Mount requires no maintenance.
-
Page 10: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 11: Technical Information
Technical Information MECHANICAL Load Rating: Accommodates the SurveyorVFT Camera Dome System. Dimensions: Height: 37 in. (940 mm). Width: 27 in. (686 mm). Construction: Mount: aluminum pipe, 1.9 in. (48 mm) O.D. Braces and supports: steel. Hardware: stainless steel. Finish: White paint. ENVIRONMENTAL Wind: Withstands winds up to 80 mph. - Page 12 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office...
