Warning: To reduce a risk of fire or electric shock, do not expose the indoor unit to rain or moisture. Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation.
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage is present, contact the carrier and file a damage claim immediately. If the equipment must be returned to Vicon for repair, follow the instructions in the Shipping Information section of this manual.
Page 6
1/4-in. color camera, PAL version, 23x zoom, high-resolution day/night camera, SVFT-MSH23C 8714-01 variable-speed camera dome, aluminum upper housing with lower acrylic dome, mounting bracket not included 1/4-in.
7. Install the terminal blocks into the Customer Interface Board, swing the board up and latch it into the Housing. Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source. Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and, in severe cases, damage certain components.
Page 9
8. Configure communication and address DIP switches as shown on the label in Figure 2. For a detailed description of DIP switch configuration, refer to the Configuration section of the SurveyorVFT Installation & Operation Manual. 9. Lift the Camera Drive and connect it to the Housing by attaching the Safety Cable Clip to the Latch on the Camera Drive.
Page 10
CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER TERMINAL BLOCK VIDEO NVT (TB4) TB4-1 UTP + Unshielded twisted pair + TB4-2 UTP - Unshielded twisted pair - TB4-3 TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TERMINAL BLOCK ALARM (TB2) TB2-1 Alarm input 1 ALARM 1 TB2-2...
Page 11
CONNECTOR/PIN CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME NUMBER TERMINAL BLOCK POWER (TB1) TB1-1 TB1-2 Neutral TERMINAL BLOCK ALARM (TB2) TB2-1 Alarm input 1 ALARM 1 TB2-2 Ground TB2-3 ALARM 2 Alarm input 2 TB2-4 Ground TB2-5 ALARM 3 Alarm input 3 TB2-6 Ground TB2-7...
Operation When power is applied to the camera, the SVFT-MSH will boot up through a diagnostic routine and view the currently selected scene. Refer to the SurveyorVFT Programming Manual for details on setup and operation. Maintenance The SVFT-MSH Camera Dome requires no scheduled maintenance except for the occasional cleaning of the Lower Dome.
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
Cable Recommendations Coaxial Cable Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms.
Twisted-Pair Cable CAUTION: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. Materials Use a pure copper stranded conductor with or without a tin plating to obtain a low DC resistance. Do not use cable with either a steel or an aluminum stranded conductor because these do not transfer signals effectively for long distances.
Technical Information ELECTRICAL (SurveyorVFT Camera Drive only) Drive Type: Electrical motorized pan and tilt, electronic control. Camera Types: Units available in color and day/night (NTSC/ PAL) formats and a variety of zoom and feature capabilities. Input Voltage: 18 - 32 VAC. Maximum Wire Distance for Power Cable: See Table 7.
Page 17
Radio Frequency Emission Rating: FCC Class A. OPERATIONAL (SurveyorVFT Camera Drive only) Video Pan View: 360°. Video Tilt View: -2.5° (-2.5° above horizon) to 92.5° (-2.5° past vertical). Pan Speed: Variable, 0.1 - 360°/ sec (120°/ sec in 18X version). Autopan Speed: Variable, 0.1 - 42°/ sec, enable/disable.
Page 18
Screen Titling Capabilities: Programmable for camera, preset, sector, relay and alarms. Camera: 1 for each. Preset: 79 maximum. Sector: 16 maximum (not on 18X). Alarm: 4 maximum. Individual type date and time enable/disable; 20 characters maximum. Selectable position. Three text sizes for top two lines.
Page 19
MECHANICAL (SVFT-MSH Housing only) Application: Indoor or outdoor in warm climates. Mounting: Ceiling or Wall mounting with separately purchased Mounting Brackets. See Table 3. Cable Access: 1.09 in (28 mm) hole size utilizing provided 0.75 in (19 mm) Liquid Tight Fitting. Mounting Pattern: Two four (4)-hole patterns on each mount sized to accommodate provided 3/8 in.
Page 20
Figure 3 Dimensions ENVIRONMENTAL Operating Temperature Range: 32 to 110°F (0 to 43°C). Operating Humidity Range: 100% relative humidity. Storage Temperature Range: -40° to 150° F (-40° to 65° C). Storage Humidity Range: Up to 90% relative, noncondensing. Ingress Protection: EN60529, IP 65 rated.
