Back Panel; Mouse Connector - Premio Computer Athena system System Manual

Chapter 2

Back Panel

The Back Panel provides the following connectors:
Mouse
Keyboard USB
Mouse Connector: JKBMS1
The mainboard provides a standard PS/2
attaching a PS/2
connector. The connector location and pin assignments are as follows:
6
4
2
PS/2 Mouse (6-pin Female)
Parallel
COM A
®
mouse. You can plug a PS/2
5
3
1
COM B
®
mouse mini DIN connector for
®
Pin Definition
PIN SIGNAL
1 Mouse DATA
2 NC
3 GND
4 VCC
5 Mouse Clock
6 NC
2-8
Midi/Joystick
L-out L-in MIC
mouse directly into this
DESCRIPTION
Mouse DATA
No connection
Ground
+5V
Mouse clock
No connection
