Chapter 2. Hardware Setup

Hardware Setup
This chapter provides you with the information about hardware setup
procedures. While doing the installation, be careful in holding the compo-
nents and follow the installation procedures. For some components, if you
install in the wrong orientation, the components will not work properly.
Use a grounded wrist strap before handling computer components. Static
electricity may damage the components.
TOPICS
Central Processing Unit: CPU
Memory
Power Supply
Back Panel
Connectors
Jumpers
Slots
2-1
Hardware Setup
2
2-2
2-5
2-7
2-8
2-13
2-27
2-28
