Back Panel

The Back Panel provides the following connectors:
Mouse
Keyboard
USB

Mouse Connector

The mainboard provides a standard PS/2
for attaching a PS/2
connector.
6
4
2
PS/2 Mouse (6-pin Female)
Parallel
COM A
®
mouse. You can plug a PS/2
PIN
5
1
2
3
3
1
4
5
6
COM B
L-out L-in
®
mouse mini DIN connector
®
mouse directly into this
Pin Definition
SIGNAL
Mouse DATA
NC
GND
VCC
Mouse Clock
NC
2-9
Hardware Setup
Midi/Joystick
MIC
DESCRIPTION
Mouse DATA
No connection
Ground
+5V
Mouse clock
No connection
