Chapter 1

Mainboard Specification

CPU
Supports Socket A (Socket-462) for AMD
processor
Supports 800MHz up to 1.8GHz (Athlon™ XP 2200+) processor
Chipset
VIA KT333 chipset
®
- FSB @200/266 MHz
- AGP 4X and PCI Advanced high performance memory controller
VIA VT8235 chipset
®
- Integrated Direct Sound AC97 audio
- Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller
- ACPI
- Integrated USB 2.0 controller
Clock Generator
100/133 MHz clocks are supported.
Main Memory
Supports six memory banks using three 184-pin DDR DIMMs
Supports a maximum memory size up to 3GB
Supports 2.5V DDR SDRAM DIMM
Slots
One AGP slot
- AGP (Accelerated Graphics Port) specification compliant
- Supports AGP 2.0 1x/2x/4x
Five 32-bit PCI bus slots (support 3.3v/5v PCI bus interface)
One CNR (Communication Network Riser) slot
On-Board IDE
An IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA133/100/66/33 operation modes
Can connect up to four IDE devices
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
Athlon™/Athlon™ XP /Duron™
®
1-2
