- Page 1 Apollo/Shadowhawk u s e r m a n u a l...
- Page 2 System Manual...
- Page 3 PREMIO System Manual Copyright is a registered trademark of Premio Computer, Inc. All PREMIO other brands and product names are trademarks or registered trademarks of their respective companies. © 1997 by Premio Computer, Inc. All rights reserved. Printed in Taiwan.
-
Page 4: Table Of Contents
Contents GETTING STARTED ...1 Setting Up ...2 Switches and Indicators...3 UPGRADING ...5 Opening the System Unit ...6 Installing an Expansion Card ...7 Installing Memory ...8 Installing a SIMM ...8 Removing a SIMM...9 Installing a DIMM ...9 Removing a DIMM ...10 Installing a Hard Drive...11 GETTING HELP...12 Troubleshooting ...12... - Page 5 PREMIO System Manual Warranty Service... 15 Technical Support... 15 PREMIO on the Internet... 15 APPENDIX ...16 Limited 3-Year Warranty... 16 FCC Standards ... 18 Important Safety Instructions ... 19...
-
Page 6: Getting Started
Getting Started Your PREMIO a mid-tower or desktop system unit a keyboard a mouse Add your choice of monitor, and your system is ready to use. Mid-tower system Keyboard Desktop system Keyboard ® system consists of three components: System Unit Mouse System Unit Mouse... -
Page 7: Setting Up
PREMIO System Manual Setting Up To set up your the mouse, the keyboard, and any additional components you want to use to the system unit. Follow these easy steps: Power Connector Mouse Connector Keyboard Connector USB Connector Serial-1 Connector Serial-2 Connector Parallel Connector Video Connector Sound Card Connectors... -
Page 8: Switches And Indicators
Switches and Indicators The system unit’s front panel provides access to the CD-ROM and floppy drives, and to the system’s switches and indicator lights. The illustration below shows a mid-tower system. If you have a desktop system, turn to the illustration on the next page. Mid-tower system CD ROM Drive Floppy Drive... - Page 9 PREMIO System Manual Desktop system Reset Button Hard Drive Indicator Power Indicator The reset button restarts the system. The hard drive indicator lights when the hard drive is in use. The power indicator lights when the system is on. The power switch turns the system on and off. The CD-ROM drive reads information on CDs.
-
Page 10: Upgrading
Upgrading You can upgrade your Expansion cards More memory An additional hard drive To install an upgrade, you must open the system unit. Before proceeding, read the important cautionary note below. Then follow the steps on the next page. Caution! Static discharge can cause permanent damage to internal electronic components of your computer. -
Page 11: Opening The System Unit
PREMIO System Manual Opening the System Unit Note Opening the system unit could affect your warranty. Check with the dealer where you purchased your system before opening the system unit. To open the system unit, follow these steps Mid-tower system Desktop system Turn off the system and unplug the power cord. -
Page 12: Installing An Expansion Card
Installing an Expansion Card To install an expansion card, open the system unit as described use. Save the screw to secure the expansion card. Installing an Expansion Card on the previous page. Then follow these steps: Remove the screw securing the slot bracket cover for the expansion slot you want to Insert the expansion card... -
Page 13: Installing Memory
PREMIO System Manual Installing Memory Note For details on memory configuration, including the placement and type of memory to use in your system, refer to the motherboard user’s manual that came with your system. Follow these general guidelines when adding memory: Use only the same type of memory throughout. -
Page 14: Removing A Simm
Removing a SIMM To remove a SIMM, follow these steps: Press the holding clips on both sides of the SIMM outward to release it. Tilt the SIMM to a 45° angle. Pull the SIMM up and out of the socket. Installing a DIMM To install a DIMM, follow these steps: Installing Memory... -
Page 15: Removing A Dimm
PREMIO System Manual Removing a DIMM To remove a DIMM, follow these steps: Push down and out on the plastic clips at either end to release them. Pull the DIMM up and out of the socket. -
Page 16: Installing A Hard Drive
Installing a Hard Drive To install a hard drive in your system, follow these steps: Mid-tower system Desktop system Disconnect the hard drive cable and power connector. Remove the two screws securing the drive bay. Slide the bay toward the rear of the system unit to remove it. -
Page 17: Getting Help
Getting Help Troubleshooting Your PREMIO free performance. If you have a problem with your system, first check the information in this section for a quick solution. Monitor Does Not Work If your monitor appears not to be working properly: Check that the monitor’s power cable is securely attached to the monitor and to an outlet that is receiving power. -
Page 18: Keyboard Does Not Work
Keyboard Does Not Work If the NumLock indicator in the upper right corner of the keyboard does not light when the system powers up, or the keyboard does not work: Check that the keyboard cable is securely attached to the system unit’s keyboard connector. -
Page 19: System Unit Problems
PREMIO System Manual System Unit Problems The fan inside the system unit should make a low, steady sound when operating properly. If the fan is totally silent: Check that the system power cord is securely attached to the back of the system unit and to a power outlet. Verify that the outlet has power. -
Page 20: Warranty Service
Note To obtain warranty service, you must provide proof of purchase, including the purchase date. Technical Support You can contact address: Premio Computer, Inc. 918 Radecki Court City of Industry, CA 91748 Telephone: 800-568-6388 Fax: 626-839-3191 Email: support@premiopc.com... -
Page 21: Appendix
(hereinafter “Product”) to be free from defects in material and workmanship for a period of three (3) years from the date of original purchase from Premio Computer, Inc. or a Premio Computer, Inc. authorized reseller. This warranty does not cover monitor and LCD panels, nor third-party hardware and software which has a separate manufacturer’s warranty. - Page 22 PREMIO COMPUTER, INC.'S SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT AS STATED ABOVE. IN NO EVENT WILL PREMIO COMPUTER, INC. BE LIABLE TO THE CUSTOMER OR ANY THIRD PARTY FOR ANY DAMEAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT.
-
Page 23: Fcc Standards
FCC Standards The FCC (Federal Communications Commission) restricts the amount of radiation and radio frequency emissions from computing equipment. This equipment generates and uses radio frequency energy and if not installed and used properly in strict accordance with the operation instructions, reference manuals, and the service manual, may cause interference to radio or television reception. -
Page 24: Important Safety Instructions
Important Safety Instructions These instructions are provided by Underwriters Laboratories, Inc. Read all of these instructions and save them for later reference. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. - Page 25 12. Except as explained elsewhere in this manual, don't attempt to service this product yourself. Opening and removing those covers that are marked “Do Not Remove” may expose you to dangerous voltage points or other risks. Refer all servicing on those compartments to service personnel.
